    With Apple's new Lightning connector on the iPhone 5 dropping to just eight contact pins from the 30 pins seen in the original dock connector and gaining the ability to be inserted in either orientation, many have wondered just how Apple has been able to maintain most of the functions of the original dock connector. Others have wondered why Apple simply didn't shift to micro-USB, an existing standard in a comparable form factor.

    Developer Rainer Brockerhoff has been examining Lightning's technical features and over the weekend outlined his thinking on how the "adaptive" nature of the Lightning connector highlighted by Apple during the technology's introduction at the iPhone 5 media event has enabled flexible functionality with a minimum of pins. Brockerhoff notes that the Lightning connector appears able to sense what kinds of devices are being connected and to use chips embedded in the cable to assign pin functionalities appropriate for each situation.
    Double Helix Cables has now shared with AppleInsider a mapping of the pins on the two sides of the Lightning connector, demonstrating that this adaptive assignment of pin functions is required for the reversible nature of the plug.
    [​IMG]


    Mapping of pins in Apple's new Lightning connector
    The adaptive nature of the Lightning connector may explain to some degree the rather high cost of cables and adapters for the new standard, as the $29 and $39 adapters for connecting 30-pin dock accessories to Lightning-equipped devices are required to contain hardware capable of working with the dynamically assigned pin functions. In addition, the adaptive nature indicates that the same Lightning interface could evolve over time to support new technologies within existing hardware.
