2016 MBP to 2009 iMac (as monitor) in Target Display Mode

Discussion in 'MacBook Pro' started by frippdesign, Nov 16, 2016.

  1. frippdesign macrumors newbie

    Joined:
    Oct 19, 2016
    #1
    Hey all, I just received my new MBP, its awesome and I love it. However I'm trying to connect it to my late 2009 iMac 27" using the Belkin mini display port > Thunderbolt 2 > USB-C. The cable worked great with my 2011 MBP as soon as it was plugged in it went into Target Display Mode and was able to use as a second monitor. It will currently not work on the 2016 MBP. Does anyone know if this is possible on the new machine? Has anyone else encountered this?

    Perhaps it is the Mini DP > Thunderbolt. I found a Mini DP direct to USB-C on amazon I was thinking of trying.

  2. wlossw macrumors 65816

    wlossw

    Joined:
    May 9, 2012
    Location:
    Montreal, Quebec, Canada
    #2
    Yeah, i think the problem is that you are using the thunderbolt adapter. Thunderbolt 1/2 and mini display port are the same shape, but not the same signal. Previous macbook pros supported display port and thunderbolt on the same ports. I think you want to go from usb c to display port.

    See here:

    "The Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter doesn't support connections to these devices:

    • Apple DisplayPort display
    • DisplayPort devices or accessories, such as Mini DisplayPort to HDMI or Mini DisplayPort to VGA adapters
    • 4K Mini DisplayPort displays that don’t have Thunderbolt"

    https://support.apple.com/en-ca/HT207266

  3. frippdesign thread starter macrumors newbie

    Joined:
    Oct 19, 2016
    #3
    Thank you! Do you think this guy will do the trick? https://www.amazon.com/gp/product/B017TZTNBK/ref=ox_sc_sfl_title_1?ie=UTF8&psc=1&smid=A105NRR7VYZXED

  4. wlossw macrumors 65816

    wlossw

    Joined:
    May 9, 2012
    Location:
    Montreal, Quebec, Canada
    #4
  5. Kinggyking macrumors newbie

    Kinggyking

    Joined:
    Sep 12, 2013
    Location:
    Kent, UK
    #5
  6. frippdesign thread starter macrumors newbie

    Joined:
    Oct 19, 2016
    #6
    Yes it did! Apologies for the delay, the item was in and out of stock and I wanted the grey so it took a little while to arrive. I plugged everything in and pressed CMD + F4 on the iMac keyboard, got a black screen while they connected and was in business. Thanks for your help @wlossw !!

  7. Kinggyking macrumors newbie

    Kinggyking

    Joined:
    Sep 12, 2013
    Location:
    Kent, UK
    #7
    Hi,

    Thats great to hear, so what cables and adaptors did you use?

    Many thanks

  8. frippdesign thread starter macrumors newbie

    Joined:
    Oct 19, 2016
    #8
    Belkin Thunderbolt to lightning cable and the above referenced mini display port > USB C

  9. sosnooly macrumors newbie

    Joined:
    Aug 1, 2013
    #9
    Sorry for deadposting, but could you please provide a link to the valid Thunderbolt to lightning cable?

    Thanks.

  10. hogsdill macrumors member

    Joined:
    Oct 22, 2007
    #10
    I would like to know as well. I'm in a similar situation.

  11. EugW, Mar 30, 2018
    Last edited: Mar 30, 2018

    EugW macrumors 601

    EugW

    Joined:
    Jun 18, 2017
    #11
  12. hogsdill macrumors member

    Joined:
    Oct 22, 2007
    #12
    Thanks for the quick response. I will give that adapter a shot.

  13. hogsdill macrumors member

    Joined:
    Oct 22, 2007
    #13
    Just a quick update... the Monoprice adapter worked for me.
