Shaun Collier

macrumors newbie
Original poster
May 29, 2020
6
1
Hi I have just updated to 10.15.5 hoping to fix the bug where my external display would not wake when my 2019 Macbook Pro 16 inch woke from sleep. However after installing the update I have had 5 crashes in 1 hour and my laptop no longer recognises my external display, or TV. I have pasted one of the crashes reports below, any one else experiencing this, its extremely frustrating.


panic(cpu 3 caller 0xffffff800a64aa3a): Kernel trap at 0xffffff7f8e8ac7e4, type 13=general protection, registers:


CR0: 0x000000008001003b, CR2: 0x000070000c2a24a0, CR3: 0x000000001eb8d000, CR4: 0x00000000003626e0


RAX: 0x683d8787e4580029, RBX: 0xffffff803e924400, RCX: 0x0000000000000003, RDX: 0x0000000000000008


RSP: 0xffffff923396bd90, RBP: 0xffffff923396bdf0, RSI: 0x00000000deadbeef, RDI: 0xdeadbeefdeadbeef


R8: 0x0000000000000001, R9: 0xffffff7f8ea3c6bd, R10: 0xffffff7f8eab5708, R11: 0xffffff803916d000


R12: 0xffffff804014f5a0, R13: 0xffffff805306af20, R14: 0xffffff923396bd90, R15: 0x00000000e00002d8


RFL: 0x0000000000010282, RIP: 0xffffff7f8e8ac7e4, CS: 0x0000000000000008, SS: 0x0000000000000010


Fault CR2: 0x000070000c2a24a0, Error code: 0x0000000000000000, Fault CPU: 0x3, PL: 0, VF: 0





Backtrace (CPU 3), Frame : Return Address


0xffffff800a352a20 : 0xffffff800a51f5cd


0xffffff800a352a70 : 0xffffff800a658b05


0xffffff800a352ab0 : 0xffffff800a64a68e


0xffffff800a352b00 : 0xffffff800a4c5a40


0xffffff800a352b20 : 0xffffff800a51ec97


0xffffff800a352c20 : 0xffffff800a51f087


0xffffff800a352c70 : 0xffffff800acc27ec


0xffffff800a352ce0 : 0xffffff800a64aa3a


0xffffff800a352e60 : 0xffffff800a64a738


0xffffff800a352eb0 : 0xffffff800a4c5a40


0xffffff800a352ed0 : 0xffffff7f8e8ac7e4


0xffffff923396bdf0 : 0xffffff7f8e8d5f86


0xffffff923396be20 : 0xffffff800ac33409


0xffffff923396be90 : 0xffffff800ac33329


0xffffff923396bec0 : 0xffffff800a561565


0xffffff923396bf40 : 0xffffff800a561091


0xffffff923396bfa0 : 0xffffff800a4c513e


Kernel Extensions in backtrace:


com.apple.kext.AMDRadeonX6000Framebuffer(3.0.9)[E9880F7F-25D3-340E-9F59-0FB58854EF20]@0xffffff7f8e8a7000->0xffffff7f8ecd8fff


dependency: com.apple.iokit.IOACPIFamily(1.4)[0A7D7382-66FE-391B-9F93-97A996256C25]@0xffffff7f8af09000


dependency: com.apple.iokit.IOPCIFamily(2.9)[3C56BB73-D149-3E84-A2EB-DF806779B96C]@0xffffff7f8af12000


dependency: com.apple.iokit.IOGraphicsFamily(576.1)[B1C0006F-E1F5-37D9-9548-5F918E92B422]@0xffffff7f8e1bf000


dependency: com.apple.AppleGraphicsDeviceControl(5.2.4)[CD6E2942-2A23-3CE8-9BCA-D5A772667EB8]@0xffffff7f8e2f1000





BSD process name corresponding to current thread: kernel_task


Boot args: chunklist-security-epoch=0 -chunklist-no-rev2-dev





Mac OS version:


19F96





Kernel version:


Darwin Kernel Version 19.5.0: Thu Apr 30 18:25:59 PDT 2020; root:xnu-6153.121.1~7/RELEASE_X86_64


Kernel UUID: 7B7F06EE-1B75-345E-B898-2FD4FEC20F0D


Kernel slide: 0x000000000a200000


Kernel text base: 0xffffff800a400000


__HIB text base: 0xffffff800a300000


System model name: MacBookPro16,1 (Mac-E1008331FDC96864)


System shutdown begun: NO





System uptime in nanoseconds: 350560923627


last loaded kext at 349942342585: |SCSITaskUserClient 422.120.3 (addr 0xffffff7f8dddf000, size 45056)


loaded kexts:


|SCSITaskUserClient 422.120.3


>AudioAUUC 1.70


>usb.!UHostBillboardDevice 1.0


>usb.realtek8153patcher 5.0.0


@kext.AMDRadeonX6000 3.0.9


@kext.AMDRadeonServiceManager 3.0.9


>!AGraphicsDevicePolicy 5.2.4


@fileutil 20.036.15


@AGDCPluginDisplayMetrics 5.2.4


>!AHV 1


|IOUserEthernet 1.0.1


|IO!BSerialManager 7.0.5f6


>pmtelemetry 1


>!AUpstreamUserClient 3.6.8


>AGPM 111.4.4


>X86PlatformShim 1.0.0


>!APlatformEnabler 2.7.0d0


@Dont_Steal_Mac_OS_X 7.0.0


>!A!IKBLGraphics 14.0.6


>AGDCBacklightControl 5.2.4


>!AThunderboltIP 3.1.4


>!ABacklight 180.3


>BridgeAudioCommunication 6.70.7


>ACPI_SMC_PlatformPlugin 1.0.0


>!A!ISlowAdaptiveClocking 4.0.0


>!AFIVRDriver 4.1.0


>!AMuxControl2 5.2.4


>!ATopCaseHIDEventDriver 3430.1


>!AHIDALSService 1


>!ABridgeAudio!C 6.70.7


>!AGFXHDA 100.1.428


>!A!ICFLGraphicsFramebuffer 14.0.6


>!AMCCSControl 1.14


>!AAVEBridge 6.1


>!A!IPCHPMC 2.0.1


@filesystems.autofs 3.0


>BCMWLANFirmware4355.Hashstore 1


>BCMWLANFirmware4364.Hashstore 1


>BCMWLANFirmware4377.Hashstore 1


>!ABCMWLANBusInterfacePCIe 1


>!AFileSystemDriver 3.0.1


@filesystems.hfs.kext 522.100.5


@BootCache 40


@!AFSCompression.!AFSCompressionTypeDataless 1.0.0d1


@!AFSCompression.!AFSCompressionTypeZlib 1.0.0


>!AVirtIO 1.0


@filesystems.apfs 1412.120.2


@private.KextAudit 1.0


>!ASmartBatteryManager 161.0.0


>!AACPIButtons 6.1


>!ASMBIOS 2.1


>!AACPIEC 6.1


>!AAPIC 1.7


$!AImage4 1


@nke.applicationfirewall 303


$TMSafetyNet 8


@!ASystemPolicy 2.0.0


|EndpointSecurity 1


>usb.cdc.acm 5.0.0


>usb.serial 6.0.0


>!UAudio 323.1


>usb.!UHub 1.2


@kext.AMDRadeonX6100HWLibs 1.0


>!A!BHIDKeyboard 209


@kext.AMDRadeonX6000HWServices 3.0.9


|IOAVB!F 850.1


>!ASSE 1.0


@kext.AMDRadeonX6000Framebuffer 3.0.9


@!AGPUWrangler 5.2.4


>!AHDA!C 283.15


|IOHDA!F 283.15


>!ABacklightExpert 1.1.0


>IOPlatformPluginLegacy 1.0.0


>!AActuatorDriver 3440.1


@kext.AMDSupport 3.0.9


|IOSlowAdaptiveClocking!F 1.0.0


>!AGraphicsControl 5.2.4


>!AThunderboltEDMSink 4.2.3


>!AThunderboltDPOutAdapter 6.2.6


>!AHIDKeyboard 209


>!AHS!BDriver 3430.1


>IO!BHIDDriver 7.0.5f6


>!AMultitouchDriver 3440.1


>!AInputDeviceSupport 3440.8


|IONDRVSupport 576.1


>!ASMBusPCI 1.0.14d1


|IO!BHost!CUARTTransport 7.0.5f6


|IO!BHost!CTransport 7.0.5f6


>!A!ILpssUARTv1 3.0.60


>!A!ILpssUARTCommon 3.0.60


>!AOnboardSerial 1.0


@!AGraphicsDeviceControl 5.2.4


|IOAccelerator!F2 438.5.4


>!ASMBus!C 1.0.18d1


|IOGraphics!F 576.1


>X86PlatformPlugin 1.0.0


>IOPlatformPlugin!F 6.0.0d8


@plugin.IOgPTPPlugin 840.3


|IOEthernetAVB!C 1.1.0


@kext.triggers 1.0


>usb.cdc.ecm 5.0.0


>usb.cdc.ncm 5.0.0


>usb.IOUSBHostHIDDevice 1.2


>usb.cdc 5.0.0


>usb.networking 5.0.0


>usb.!UHostCompositeDevice 1.2


>!ABCMWLANCore 1.0.0


>mDNSOffloadUserClient 1.0.1b8


>IOImageLoader 1.0.0


|IO80211!FV2 1200.12.2b1


>corecapture 1.0.4


|IOSkywalk!F 1


|IOSurface 269.11


@filesystems.hfs.encodings.kext 1


|IOAudio!F 300.2


@vecLib.kext 1.2.0


|IOSerial!F 11


>!AXsanScheme 3


>usb.!UVHCIBCE 1.2


>usb.!UVHCI 1.2


>usb.!UVHCICommonBCE 1.0


>usb.!UVHCICommon 1.0


>!AEffaceableNOR 1.0


|IOBufferCopy!C 1.1.0


|IOBufferCopyEngine!F 1


|IONVMe!F 2.1.0


>!AThunderboltPCIDownAdapter 2.5.4


>!AThunderboltDPInAdapter 6.2.6


>!AThunderboltDPAdapter!F 6.2.6


>!AHPM 3.4.4


>!A!ILpssI2C!C 3.0.60


>!A!ILpssDmac 3.0.60


>!A!ILpssI2C 3.0.60


>!AThunderboltNHI 5.8.6


|IOThunderbolt!F 7.6.1


>usb.!UXHCIPCI 1.2


>usb.!UXHCI 1.2


>usb.!UHostPacketFilter 1.0


|IOUSB!F 900.4.2


>!AEFINVRAM 2.1


>!AEFIRuntime 2.1


>!ASMCRTC 1.0


|IOSMBus!F 1.1


|IOHID!F 2.0.0


$quarantine 4


$sandbox 300.0


@Kext.!AMatch 1.0.0d1


>!AKeyStore 2


>!UTDM 489.120.1


|IOSCSIBlockCommandsDevice 422.120.3


>!ACredentialManager 1.0


>KernelRelayHost 1


>!ASEPManager 1.0.1


>IOSlaveProcessor 1


>!AFDEKeyStore 28.30


>!AEffaceable!S 1.0


>!AMobileFileIntegrity 1.0.5


@kext.CoreTrust 1


|CoreAnalytics!F 1


|IOTimeSync!F 840.3


|IONetworking!F 3.4


>DiskImages 493.0.0


|IO!B!F 7.0.5f6


|IO!BPacketLogger 7.0.5f6


|IOUSBMass!SDriver 157.121.1


|IOSCSIArchitectureModel!F 422.120.3


|IO!S!F 2.1


|IOUSBHost!F 1.2


>usb.!UCommon 1.0


>!UHostMergeProperties 1.2


>!ABusPower!C 1.0


|IOReport!F 47


>!AACPIPlatform 6.1


>!ASMC 3.1.9


>watchdog 1


|IOPCI!F 2.9


|IOACPI!F 1.4


@kec.pthread 1


@kec.corecrypto 1.0


@kec.Libm 1


tommiy

macrumors 6502
Dec 11, 2015
412
127
Try this thread. Unfortunately this is Apple bug related which has now been running for an extended period of time. The work arounds in that thread may assist.


Shaun Collier

macrumors newbie
Original poster
May 29, 2020
6
1
Its weird as I didn't have any issues with my external display before I updated (other than not waking from sleep every now and then) now I can't even use an external display!


Cervontez

macrumors newbie
Jul 20, 2018
25
18
I am having the same thing. Note that I have an early 2019 MacBook Pro, Vega 20, with 3 monitors. I upgraded from Mojave today thinking everything should be fine. Everything works but crashes 10 minutes into the screen saver. I have had 10+ crashes this evening. I cannot let it idle too long.

I updated my wife's 2018 MacBook Pro and she has no issues. Hers is connected to 2 monitors. Im thinking its a Vega issue since hers doesn't have it.

I have tried resetting PRAM and SMC, Combo update, Safe mode, etc. and this issue is still present. When the crash happens, there will be a split second where the fans goes what appears to be at full speed right before the crash. At this point the power button has to be pressed to get it back up. Every time there is a crash that MacBook is HOT.

I installed Amphetamine to keep the system active and I've been crash free for about an hour. I should of stayed on Mojave and may downgrade back to it.


decisions

macrumors regular
Sep 30, 2019
212
582
2018 MBP here. Since upgrading my MBP has been running extremely hot almost all the time. 10.15.4 was fine. Anyone else?


tommiy

macrumors 6502
Dec 11, 2015
412
127
If you downgrade let us know how you go. There are indications here on the apple communities 19 pages that the firmware upgrade that has been happening with each Catalina minor update also results in unresponsive monitors when you downgrade. The down grade will not change back to the earlier firmware.


Shaun Collier

macrumors newbie
Original poster
May 29, 2020
6
1
Going to try a fresh clean install of 15.5.4 to see if it works, hopefully the firmware upgrade isn't the issue


tommiy

macrumors 6502
Dec 11, 2015
412
127
I hope for you it works. Many others have tried but as per here have now given up. Seems once the firmware is updated the problem persists with earlier versions. The Apple Community forums have 3 or 4 threads surround sleep wake failure especially on 16 inch MACs. New installs have not been helping at all and they are reverting to returning the MAC for refunds as Apple have not resolved the issue in months. Here is one but you can find a number wth many more than 7 pages on the Apple Forum.


spaceballl

macrumors 68030
Nov 2, 2003
2,902
300
San Francisco, CA
Hi. I came here to create my own post, but then I saw this one, and I figured I would just pile one. My 16" MacBook Pro on Catalina is the most unstable Mac I have ever owned. I definitely had all of the wake from sleep issues, kernel panics, etc. The primary way I use this laptop is attached to an external monitor, and it rarely works. Sometimes the monitor turns on. Sometimes it doesn't. Sometimes it kernel panics. I've tried different USB-C hubs, thinking that was the issue. Nope. I was hoping that the most recent Catalina update would fix the problem. Nope. Just getting worse. I have to use my Chromebook now, as that one works plugged into an external monitor. I'm so annoyed. If anyone from Apple is reading this, I can drop off my laptop in Cupertino. I live nearby. I don't need it, since it's so useless right now. Plz return it once these bugs are fixed. So annoying that my $3K MacBook Pro can't even use an external monitor properly, but my Pixelbook works great.


Shaun Collier

macrumors newbie
Original poster
May 29, 2020
6
1
I hope for you it works. Many others have tried but as per here have now given up. Seems once the firmware is updated the problem persists with earlier versions. The Apple Community forums have 3 or 4 threads surround sleep wake failure especially on 16 inch MACs. New installs have not been helping at all and they are reverting to returning the MAC for refunds as Apple have not resolved the issue in months. Here is one but you can find a number wth many more than 7 pages on the Apple Forum.
Does anyone know how to get the 10.15.4 or 10.15.1 .app install file, i can only find the .dmg versions and they don't allow you to make a bootable usb drive?


Shaun Collier

macrumors newbie
Original poster
May 29, 2020
6
1
Does anyone know how to get the 10.15.4 or 10.15.1 .app install file, i can only find the .dmg versions and they don't allow you to make a bootable usb drive?
UPDATE: After a full weekend of trouble shooting, I was able to downgrade to 10.15.4 from a clean installer, and it DID NOT FIX THE ISSUSE, my 2019 16inch Macbook Pro still does not recognised my external display via my T3 USB C HUB with Display port and HDMI (Hyper Drive unit). This must mean that its due to the graphics card firmware update that was mentioned by @tommiy. I have tried a 2nd IXTEND T3 USB C HUB and that does not work either, however a cheap Chinese straight HDMI to USB C adapter with nothing else IS WORKING. Note that all of the usb C hubs do work perfectly with my machine before the 10.15.5 update and they all still work perfectly with my 2018 Macbook Air running Mojave

Last edited:

tommiy

macrumors 6502
Dec 11, 2015
412
127
Sorry to hear that. That same thread pointed to has a potential solution around needing to wait at least 30 minutes and eventually the screen may show up and work. Thanks for feedback that once you update the firmware there is no going back.


kristof46

macrumors member
Jul 19, 2015
81
6
Kernel Panics started to show on 10.15.4. Disabled power nap works until they released 10.15.5. Most users inform that problem still exists and what is worse you can fix it with power nap on/off. I know it is frustrating. I also had kernel panic on previous Mac. Now I have new one with 10.15.3 on board and I won't go anywhere until it will be safe. But if we want them to work hard on this we have to call them or send feedback.


WR1010

macrumors newbie
Jun 4, 2020
1
0
I'm getting a crash and kernel panic whenever my 2019 16" MBP goes into sleep mode IF an external monitor is connected AND the lid is closed. This happens since upgrading from 10.15.3 to 10.15.5.
Super frustrating, and disappointing that test coverage of macOS releases is apparently so bad.

Is there any indication that 10.15.6 BETA solves this problem?


mdriftmeyer

macrumors 68040
Feb 2, 2004
3,857
2,070
Pacific Northwest
UPDATE: After a full weekend of trouble shooting, I was able to downgrade to 10.15.4 from a clean installer, and it DID NOT FIX THE ISSUSE, my 2019 16inch Macbook Pro still does not recognised my external display via my T3 USB C HUB with Display port and HDMI (Hyper Drive unit). This must mean that its due to the graphics card firmware update that was mentioned by @tommiy. I have tried a 2nd IXTEND T3 USB C HUB and that does not work either, however a cheap Chinese straight HDMI to USB C adapter with nothing else IS WORKING. Note that all of the usb C hubs do work perfectly with my machine before the 10.15.5 update and they all still work perfectly with my 2018 Macbook Air running Mojave

Who makes the Hub?


fulo

macrumors newbie
Jun 5, 2020
7
2
To join the discussion: I'm facing exactly the same problems with my 16" i9, 2019)
Since quite a long time, my Mac didn't wake up here and then, when my external display (EIZO CX7210) ist connected. But that was maybe one a week and only when I connected the display to my Thunderbolt 3 dock. As I connected the USB-C -> Display Port cable directly to the MBP, this problem disappeared.

Then, maybe 1 to 2 months ago, the Error with the Sleeping transition

panic(cpu 0 caller 0xffffff800b29169c): Sleep transition timed out after 180 seconds while calling power state change callbacks. Suspected bundle: com.apple.iokit.IOGraphicsFamily. Thread 0x1512c.

started to occur. First sporadically, maybe every fourth or fifth time, the Mac went to sleep. During the last weeks it got worse and worse. With the latest minor update of 10.15.5 it's a pure disaster. Nearly every time the Mac goes to sleep, I have to hardreset the device, as the screen remains black. Sometimes I can still hear Spotify playing music, but I can't return to the OS from the black screen, no matter if I open the (usually closed) MBP or not.

Additionally, my Mac sometimes reboots with this error. This happens maybe once a week. I don't know if there is any context between the two :

`panic(cpu 4 caller 0xffffff7f861a0ad5): userspace watchdog timeout: no successful checkins from com.apple.WindowServer in 120 seconds
service returned not alive with context : is_alive_func returned unhealthy : WindowServer initialization not complete (post IOKitWaitQuiet)
service: com.apple.logd, total successful checkins since wake (9000 seconds ago): 901, last successful checkin: 0 seconds ago
service: com.apple.WindowServer, total successful checkins since wake (9000 seconds ago): 889, last successful checkin: 120 seconds ago

What I tried to solve the problem:

  • Use different connections to the external display: USB-C to Displayport, USB-C to HDMI, connected directly to the MBP or via the TB Dock. I tried a Displayport -> Displayport from the DP Port of my dock to the display. I tried different Thunderbolt docks (legato thunderbolt 3 and call digit TS+)
  • Use the Mac without external display. With this approach, it got much better, nevertheless the errors still occurred, but much less frequently.
  • Set up another admin user
  • Reset NVRAM, PRAM, SMC
  • Make a clean install on another partition
  • Install Windows 10 under Bootcamp (here I had no issues, what makes me quite confident, that it is NOT a hardware issue)
  • Made a clean install of my whole system, after deleting the complete hard disk and its partitions.
  • Had a call with the apple support. (in between all these approaches)
I'm getting really frustrated. I'd like to send it to apple to exclude, that it is really a hardware issue, but I can't and won't do without my Mac for 3 to 4 weeks, as I', convinced, that it's a software bug, as these problems mainly occur with the 16" MBP, but also with other devices. And as it got worse with the last updates.

I'm really looking back 20 years ago, when a Mac was a stable and reliable system. This status get's lost more and more in small steps.


tommiy

macrumors 6502
Dec 11, 2015
412
127
Its not you, its your Mac OS. Unfortunately there is a thread on apple community here thats about 300 messages long and with about 30k views all trying to resolve the same problem. Its really not you, its just your Mac. And if not the external display then there is a 500 odd message thread on the kernel panics.


kave

macrumors 6502a
Oct 31, 2012
567
308
Sweden
Three times now since 10.15.5 with my 16MPP kernel panic when wake from sleep. External display connected.


kave

macrumors 6502a
Oct 31, 2012
567
308
Sweden
And now my 16" have crashed again after I left it for 45 minutes. Without external display. I am going 10.15.6B2


Enricot

macrumors newbie
Jun 24, 2020
1
0
I wish I knew about this. Last night I let the system Upgrade run. 2017 Mac book pro.

this morning I wake up and it’s off. Turn it on and says it’ll take 42 minutes. Ok I wait and thn the fan was going at 100%and external monitor would not work.

went to Apple site they said it’s the motherboard or battery to replace. Hundreds of euro.

now the laptop keeps restarting, spinga fan and turns off.every 10s
do not upgrade.


Attachments

  • 9E0C02DC-D68B-4727-8EF9-A9182996D520.jpeg
    301.7 KB · Views: 1,732

Luke Slymen

macrumors newbie
Jun 25, 2020
6
1
I have a 2019 i9 27" iMac, since the 10.15.5 update I get a kernel panic every time I walk away from the machine for more than 15 minutes. I've been working with Apple, they collected a bunch of diagnostics and are supposed to get back to me next week.


muppix

macrumors newbie
Nov 25, 2011
2
0
Douglas, Isle of Man
Came here via Google while debugging kernel panics related to external Thunderbolt 3 Display / CalDigit TS3+ hub. High-end 2020 13" MacBook Pro, 4 TB disk / 2.3 GHz i7 / 32 GB memory, Catalina 10.15.6.

Most expensive paperweight I ever bought, praying somebody has an update.

Register on MacRumors! This sidebar will go away, and you'll see fewer ads.
