Today at the 2016 NAB Show, CalDigit announced four new storage products utilizing the latest Thunderbolt 3 and USB 3.1 Type-C technologies.

The first is the CalDigit T8, a Thunderbolt 3 RAID 0, 1, 5, 6, and JBOD storage solution with 8-bays offering capacities up to 48TB with 3.5" HDDs and 8TB with SSDs. The device's dual Thunderbolt 3 ports deliver up to 40Gb/s bandwidth, while dual USB-C ports work with Type-C computers like the 12-inch Retina MacBook.


The new T8 features speeds of up to 1440MB/s with SSDs, two fans for cooling and a full-size DisplayPort connector on the back of the unit that enables users to connect a 4K monitor at 60Hz to the storage device. CalDigit has not released pricing for the T8 yet, but it will be available in late 2016.

The second is the CalDigit U6, a 6-bay USB 3.1 Type-C RAID 0, 5, 6, 10 and JBOD storage solution that features USB 3.1 for up to 10Gb/s throughput. Like the T8, the U6 has a USB-C connector that is compatible with any PC, Mac, or Chrome computer with Type-C ports. The U6 will start at $1,399 MSRP for the 12TB version in late 2016.

Likewise, the CalDigit AV Pro 2 is a new single-drive storage solution featuring USB 3.1 Type-C for connectivity with the 12-inch Retina MacBook and other Type-C computers. The successor to the original AV Pro features capacities up to 6TB and 1TB with SSDs, and speeds of up to 200MB/s with 3.5" HDDs or 430MB/s with SSDs.

Meanwhile, the T4 RAID will be upgraded with Thunderbolt 3 later in 2016. Pricing for the AV Pro 2 and T4 RAID has not been announced.

Apple is widely expected to release its first Mac notebooks with Thunderbolt 3 later this year. Unlike Thunderbolt 2, the technology functions over a USB-C port, meaning that the next-generation Skylake-based MacBook Pro, and possibly the MacBook Air if not discontinued, should be equipped with both Thunderbolt 3 and USB-C.

Article Link: CalDigit Announces New Thunderbolt 3 and USB-C Storage Devices


nutmac

macrumors 603
Mar 30, 2004
5,255
4,769
If CalDigit still insists on not selling diskless versions, no thanks.

Comment

g4cube

macrumors 6502a
Apr 22, 2003
760
13
Why only 1440 MB/sec for 8 x SSD config?

LaCie's 12big announcement indicates 2400MB/sec for 12 x HDD config

Thunderbolt should permit faster performance for that CalDigit SSD configuration.

  • Like
Reactions: djbuddha
Comment

JustThinkin'

macrumors 6502
Oct 21, 2014
418
289
[doublepost=1461025927][/doublepost]
Why only 1440 MB/sec for 8 x SSD config?

LaCie's 12big announcement indicates 2400MB/sec for 12 x HDD config

Thunderbolt should permit faster performance for that CalDigit SSD configuration.
Based on my experience with a few previous-generation multi-disk storage enclosures, I'd guess it's the the controller. In other words, the RAID chip(set) that the SATA (or other interface) disks connect to. Some of them will only allow perhaps 200MB/s per connected disk, which is fine for HDDs but extremely limiting for SSDs.

In fact, these may have controllers that are no better than the previous generation, because as you can see the numbers work out to about the same performance.

Comment

JustThinkin'

macrumors 6502
Oct 21, 2014
418
289
Not sure what external RAID solution you're looking at that includes 48TB for $1,800. Caldigit's 4 bay solution with 4 TB of storage is already $900.

Naturally this is the cost for the storage media alone. If you include the enclosures you might be looking at under $4000 vs. over $16000. The SSDs are still a very bad value unless your application gains some significant advantages from using them. CalDigit prices may be a little higher for their pre-configured solutions, but you get the idea.

Comment

Marx55

macrumors 68000
Jan 1, 2005
1,802
631
Bring portable and desktop SSD without RAID (single drive). RAID increases the risk of losing data if one disk or the controller fails. On the other hand, mechanical disks are the past.

Comment

steve123

macrumors 6502
Aug 26, 2007
316
122
Bring portable and desktop SSD without RAID (single drive). RAID increases the risk of losing data if one disk or the controller fails. On the other hand, mechanical disks are the past.

Huh? As I understand it, RAID is intented to reduce the risk of sk of data loss.

Comment

theluggage

macrumors 603
Jul 29, 2011
5,391
4,481
Huh? As I understand it, RAID is intented to reduce the risk of sk of data loss.

Not really.

There are lots of different RAID configurations (levels) that offer different trade-offs between data safety, speed and cost (number of disks for a given capacity)

However, the focus of RAID was always on increasing performance - arguably, the levels with parity or mirroring do little more than compensate for the risk of adding more points of failure. There's also a huge hole (now pretty much accepted I think) in any calculations you do based on 'mean time between failures' stats that assumes all events are independent: drives of the same age, model - maybe even the same batch - running in the same environment on the same controller have a tendency to fail in clusters...

Certainly for most small-scale uses, a single SSD will perform far better than a small HD RAID setup, and a SSD RAID with mirroring or parity - needing 2-3 times the number of SSDs - will be a huge price to pay for data security that comes with a lot of loopholes. I'm sure any use cases for SSD RAID will quickly die out as PCIe or other fast interfaces take over from SATA and other interfaces designed for 'spinning rust'.

  • Like
Reactions: cerberusss
