EF 24-105mm f/4L IS USM compared to non-L primes.

Chris7

macrumors 6502
Original poster
Aug 8, 2008
396
0
Lost in Thought
Hello, beginner here, about to buy a lens.

From what I understand, primes are suppose to be better than zooms. And Canon L-series lenses are suppose to be better than non-L series.

So how do the following non-L primes fare compared to the EF 24-105mm f/4L IS USM (set to f/4) at corresponding focal lengths (particularly with respect to sharpness and chromatic aberrations)?

As lenses generally get sharper stopped down a little, I’d be particularly interested if either of these primes can equal the 24-105mm f/4L, when more open. (Trying to compare two of these lenses using the MTF charts at photozone.com suggested that EF 85mm f/1.8 USM at f/1.8 pretty much equaled the 24-105mm f/4L (at f/4, 70mm), at least in sharpness, but I don't know about CA's.)

EF 50mm f/1.4 USM (at f/2, f/2.8, and f/4)

EF 85mm f/1.8 USM (at f/1.8, f/2, f/2.8, and f/4)

So, in brief, is it possible that I could get equal or better resolution and chromatic aberrations using either of these prime lenses at f/2 or f/2.8 than the 24-105mm f/4L at f/4?


jdavtz

macrumors 6502a
Aug 22, 2005
548
0
Kenya
I can't test it for you (my 50/1.4 is being repaired) but the logical answer to your question would be "yes" because (a) they're prime lenses with fewer optical compromises in their constructions, and (b) they're stopped down from their maximum apertures.

Of course, the resulting picture will look completely different in terms of depth of focus (if there's a foreground and a background), and if you have a 50mm lens you'll never be able to take a photo with a 24mm field of view.


Razeus

macrumors 603
Jul 11, 2008
5,167
1,769
I'll never understand why people put so much thought into lenses that mean little. Just buy the best lens you can afford for the type of shooting you do. Done deal.


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
Ask, and you shall receive:

24-105 f/4L vs. 85 f/1.8 at (105mm vs. 85mm)**:

f/4.0

f/2.8

f/2.0

24-105 f/4L vs. 50 f/1.4 (both at 50mm):

f/4.0

f/2.8

f/2.0

It seems that the 85 is considerably sharper by f/2.8 than the 24-105 is at f/4 (though the zoom is no slouch); the 85 is slightly softer than the zoom at f/2.0, though it's also two stops faster.

The zoom is slightly less sharp than the 50 f/1.4 at f/4.0, but not hugely so (and is actually sharper in the centre of the frame). At f/2.8 and f/2.0, 50 is softer than the zoom at f/4.0 (not surprising). However, I have seen some copies of the 50 f/1.4 which are very sharp wide-open, so there may be some copy-to-copy variation.

The 85 f/1.8 is a terrific lens that is useable wide-open; it also has superb bokeh and extremely fast AF (ring USM, too), and is probably one of Canon's best values for the money (along with the 70-200 f/4L IS). The 50 f/1.4 is a nice prime, and is good at f/2.0 and excellent at f/2.8, but it's not as good a value as the 85, and unless you really need the extra 3 stops (which many people do), a good L zoom like the 24-105 will perform just as well.

So in summary, yes, you will get better sharpness with the 85 f/1.8 over the 24-105 at equivalent f/stops, and you even have better performance at one f/stop faster with the prime; the 50 will not necessarily give you better sharpness at equivalent f/stops, but does offer 3 additional stops of light gathering over the zoom.

** - Note that comparing the 85 to the 24-105 at different focal lengths may skew these results somewhat.


jampat

macrumors 6502a
Mar 17, 2008
682
0
Hello, beginner here, about to buy a lens.

From what I understand, primes are suppose to be better than zooms. And Canon L-series lenses are suppose to be better than non-L series.

So how do the following non-L primes fare compared to the EF 24-105mm f/4L IS USM (set to f/4) at corresponding focal lengths (particularly with respect to sharpness and chromatic aberrations)?

As lenses generally get sharper stopped down a little, I’d be particularly interested if either of these primes can equal the 24-105mm f/4L, when more open. (Trying to compare two of these lenses using the MTF charts at photozone.com suggested that EF 85mm f/1.8 USM at f/1.8 pretty much equaled the 24-105mm f/4L (at f/4, 70mm), but I’m not sure if I’m reading the charts correctly.)

EF 50mm f/1.4 USM (at f/2, f/2.8, and f/4)

EF 85mm f/1.8 USM (at f/1.8, f/2, f/2.8, and f/4)

So, in brief, is it possible that I could get equal or better resolution and chromatic aberrations using either of these prime lenses at f/2 or f/2.8 than the 24-105mm f/4L at f/4?
I have used all three lenses in real life and don't see dramatic sharpness differences (shooting weddings mainly, I haven't looked at the MTF charts). The 85 does not like to auto-focus in dim light. It is noticeably harder than the other two lenses to get it to lock onto a target. Maybe it was just the copy I used, but it stood out in my mind.


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
if that's what the chart says, that's what the chart says.
Precisely. I gave the OP what was asked for.

For my own purposes, any lack of sharpness the primes lose relative to the zoom is meaningless because f/4 is too slow for what I photograph. Even the 50, which is notorious for being soft and "dreamy" at f/1.4, still produces excellent results wide-open. Other people may not need the speed of a fast prime, and an f/4 zoom could suffice. Indeed, a lot of people subscribe to the idea that one should ONLY have f/4 zooms because anything faster than f/4 should be handled by primes.


fridgeymonster3

macrumors 6502
Jan 28, 2008
493
13
Philadelphia
I think the difference between primes and zooms is a matter of preferences and/or what you plan to use each for. I like zooms because when I'm hiking or traveling they over the best versatility, without having to change lenses, IMO. However, I also have a 30 1.4 (sigma) & 50 1.8 that I use. Lens choice is driven by situation, etc. Are you on a FF or crop?

EDIT: FWIW, I'd choose the Sigma 50 1.4 over the Canon 50 1.4. I've used both and liked the Sigma better. I chose the Canon 50 1.8 bc cost at that time forced me to, but if money wasn't an issue I'd have chosen the Sigma 50.


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
I think the difference between primes and zooms is a matter of preferences and/or what you plan to use each for. I like zooms because when I'm hiking or traveling they over the best versatility, without having to change lenses, IMO. However, I also have a 30 1.4 (sigma) & 50 1.8 that I use. Lens choice is driven by situation, etc. Are you on a FF or crop?

EDIT: FWIW, I'd choose the Sigma 50 1.4 over the Canon 50 1.4. I've used both and liked the Sigma better. I chose the Canon 50 1.8 bc cost at that time forced me to, but if money wasn't an issue I'd have chosen the Sigma 50.
I agree. You cannot beat the convenience of a zoom. That said, you cannot beat the IQ and speed of a good prime. You have to decide which is more important for you. If you're shooting landscapes at f/16, there's very little point in buying a fast prime; in that case, I'd be more interested in a zoom with good corner-to-corner sharpness. If you're shooting events in dimly-lighted rooms, you will absolutely need f/2.8 at a bare minimum; here the decision becomes less clear cut. If you're shooting portraits, I see no reason to shoot zooms at all; get the focal lengths you need and enjoy shallow DOF and top notch IQ.


fridgeymonster3

macrumors 6502
Jan 28, 2008
493
13
Philadelphia
If you're shooting portraits, I see no reason to shoot zooms at all; get the focal lengths you need and enjoy shallow DOF and top notch IQ.
That's the exact reason I have a 30 mm & 50 mm. I use them for portraits or sometime family gatherings inside a house where I don't want to bounce flashes all over the place. Maybe a combination of both will be best for the OP?


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
That's the exact reason I have a 30 mm & 50 mm. I use them for portraits or sometime family gatherings inside a house where I don't want to bounce flashes all over the place. Maybe a combination of both will be best for the OP?
Yes; a combination is likely the best strategy. Perhaps a prime or two for the most commonly used focal lengths, and then a zoom for versatility.

Incidentally, if you're having issues with bounced flash bothering people in the room, consider using the black foamie thing. Helps to keep things a little more discreet when using bounced flash.


fridgeymonster3

macrumors 6502
Jan 28, 2008
493
13
Philadelphia
Yes; a combination is likely the best strategy. Perhaps a prime or two for the most commonly used focal lengths, and then a zoom for versatility.

Incidentally, if you're having issues with bounced flash bothering people in the room, consider using the black foamie thing. Helps to keep things a little more discreet when using bounced flash.
Thanks, I'll try that trick. The problem is my wife's family owns this old 1850's farm house that has tiny rooms and ceilings, so even when you lower the power on your flash it still lights up like a christmas tree. But I'll definitely play around with that idea and see how it works.


OreoCookie

macrumors 68030
Apr 14, 2001
2,680
68
Sendai, Japan
Having or not having an L badge on the lens has nothing to do with image quality. The construction of either lenses are based on the same laws of physics after all ;)
Please, people, a red L or a gold ring is not synonymous with good image quality.

Generally, primes have an advantage when it comes to image quality. There are rare exceptions (Nikons 14-24 mm zoom is one of them), but as a rule of thumb, primes deliver better IQ. Especially so if you compare them at the same aperture (if you stop down the aperture by two EV, you are typically close to the optimal performance). This means, the 50 mm or 85 mm are at their sweet spot at f/4 while the 24-105 mm is not. If you compare the lenses at different apertures, the comparison is moot and non-sensical.

In my opinion, you're going about this the wrong way: what kind of lens are you looking for? Are you using a crop camera or a full frame camera?

If you're using a full frame camera and you would like to have a walk-around lens, the 24-105 is indeed a very good choice. If you're using a crop camera, though, the focal length range is not optimal, you have a very significant hole on the wide end. There are other lenses that are optically just as good but more suitable (Tamron's 17-50 mm f/2.8 or Canon's 17-55 mm f/2.8 come to mind).

Primes are a very different animal. I have gotten to like them a lot because I put more thought into my pictures and fast apertures such as f/1.4 are simply addictive. My 30 mm f/1.4 Sigma is constantly on my camera these days. And yes, this is also a superb lens.


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
Having or not having an L badge on the lens has nothing to do with image quality. The construction of either lenses are based on the same laws of physics after all ;)
Please, people, a red L or a gold ring is not synonymous with good image quality.
While I agree that simply having the "L" designation per se does not mean IQ is good, my experience is that it's a pretty good indicator. No one is saying that non-L glass is bad; rather, most of Canon's best lenses have the 'L' designation. That's simply stating a fact.


pdxflint

macrumors 68020
Aug 25, 2006
2,407
14
Oregon coast
What does the "L" refer to in the designation? Once a long time ago I heard someone say it meant "luxury" but that doesn't really sound right to me. Does anyone know? I am aware that the L lenses are almost all built better, and perhaps faster, although not always. There was a 100-300 f/5.6 L zoom lens I remember back in the film days, and it was fairly affordable. There was the 35-350 L, which was solid, but not all that great optically. So, I'm not really sure what the L designation tells the buyer...


toxic

macrumors 68000
Nov 9, 2008
1,664
1
So, in brief, is it possible that I could get equal or better resolution and chromatic aberrations using either of these prime lenses at f/2 or f/2.8 than the 24-105mm f/4L at f/4?
yes. pretty much all non-L primes 50mm and greater will have better resolution and flare resistance. CA varies, since fast lenses give up some in order to be fast and to have better bokeh.

but that shouldn't be your primary concern. do you want a zoom or a prime? pursuing sharpness for the sake of sharpness is pointless.


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
What does the "L" refer to in the designation? Once a long time ago I heard someone say it meant "luxury" but that doesn't really sound right to me. Does anyone know? I am aware that the L lenses are almost all built better, and perhaps faster, although not always. There was a 100-300 f/5.6 L zoom lens I remember back in the film days, and it was fairly affordable. There was the 35-350 L, which was solid, but not all that great optically. So, I'm not really sure what the L designation tells the buyer...
http://www.the-digital-picture.com/Canon-Lenses/Canon-L-Lens-Series.aspx


nutmac

macrumors 601
Mar 30, 2004
4,174
2,068
You cannot beat the convenience of a zoom.
By same token, you cannot beat the low light shooting capability of fast primes.

f/1.4 is 3 stops faster than f/4. When shooting indoor at night time without flash, f/1.4 can get away with ISO 800 (albeit at limited depth of field). With f/4, you will need ISO 6400 to obtain similar shutter speed.

My two cents: You will want both zoom and fast prime lenses (at focal length you need most often).


Ruahrc

macrumors 65816
Jun 9, 2009
1,344
0
From what I understand, primes are suppose to be better than zooms. And Canon L-series lenses are suppose to be better than non-L series.
This notion largely came about 30+ years ago when zooms were first being developed and back then there was a clear quality difference.

Nowadays, the distinction is not so clear. Theoretically, yes- it is easier to optimize the performance of a prime, because there is only one focal length to consider. However, given recent releases like the Nikon 14-24, it's evident that modern lens design coupled with high end production can create zoom lenses that are every bit as good as similar prime lenses. The recently released Nikon 16-35mm f/4 is also another good example. It is competing with even the Zeiss MF primes.

I would even go so far to say that if you're considering modern zooms, there is minimal to no substantive quality difference between zooms and primes, as long as you take price and performance level considerations into account (meaning don't compare the 200/f2 to a 70-300 and say primes are better). It really seems more about the quality of each lens (like consumer vs. pro), and not whether or not it is a zoom or a prime.

Ruahrc


Edge100

macrumors 68000
May 14, 2002
1,557
10
Where am I???
By same token, you cannot beat the low light shooting capability of fast primes.

f/1.4 is 3 stops faster than f/4. When shooting indoor at night time without flash, f/1.4 can get away with ISO 800 (albeit at limited depth of field). With f/4, you will need ISO 6400 to obtain similar shutter speed.

My two cents: You will want both zoom and fast prime lenses (at focal length you need most often).
I 100% agree, which is why I shoot mainly primes now (my only zooms are the 70-200 f/2.8L, which I use for events where my primes dont cut it, and 17-40 f/4L, which I use for landscapes).

For me, IQ and speed trump the convenience of a zoom; I can usually position myself properly so that zooming isn't needed.


scottkifnw

macrumors regular
Jan 17, 2008
217
0
Trophy Club, TX
Nice review and a question please

Excellent review, thank you.

I am interested in this lens as I am going on an Alaska trip (cruise and land tour, including lots of wildlife shots). Is the 70-200 f/4L IS best lens for a Canon 50D in this price range with this zoom focal lengths?

Thanks for your opinion.

sek

Ask, and you shall receive:

24-105 f/4L vs. 85 f/1.8 at (105mm vs. 85mm)**:

f/4.0

f/2.8

f/2.0

24-105 f/4L vs. 50 f/1.4 (both at 50mm):

f/4.0

f/2.8

f/2.0

It seems that the 85 is considerably sharper by f/2.8 than the 24-105 is at f/4 (though the zoom is no slouch); the 85 is slightly softer than the zoom at f/2.0, though it's also two stops faster.

The zoom is slightly less sharp than the 50 f/1.4 at f/4.0, but not hugely so (and is actually sharper in the centre of the frame). At f/2.8 and f/2.0, 50 is softer than the zoom at f/4.0 (not surprising). However, I have seen some copies of the 50 f/1.4 which are very sharp wide-open, so there may be some copy-to-copy variation.

The 85 f/1.8 is a terrific lens that is useable wide-open; it also has superb bokeh and extremely fast AF (ring USM, too), and is probably one of Canon's best values for the money (along with the 70-200 f/4L IS). The 50 f/1.4 is a nice prime, and is good at f/2.0 and excellent at f/2.8, but it's not as good a value as the 85, and unless you really need the extra 3 stops (which many people do), a good L zoom like the 24-105 will perform just as well.

So in summary, yes, you will get better sharpness with the 85 f/1.8 over the 24-105 at equivalent f/stops, and you even have better performance at one f/stop faster with the prime; the 50 will not necessarily give you better sharpness at equivalent f/stops, but does offer 3 additional stops of light gathering over the zoom.

** - Note that comparing the 85 to the 24-105 at different focal lengths may skew these results somewhat.


RHVC59

macrumors 6502
May 10, 2008
397
0
Eugene, Oregon
Excellent review, thank you.

I am interested in this lens as I am going on an Alaska trip (cruise and land tour, including lots of wildlife shots). Is the 70-200 f/4L IS best lens for a Canon 50D in this price range with this zoom focal lengths?

Thanks for your opinion.

sek
As an Alaskan I suggest the fastest lens you can afford. Weather resistance is nice, but the main point to my post isthat your targets move fast, and lighting in not always great... These were both shot with nikor 55-200 f 4-5.6... Wish I had had a little more reach, and a bit faster lens to get a bit better IQ...
Enjoy your trip, and bring your friends, we need a good tourist season :D


Attachments

OreoCookie

macrumors 68030
Apr 14, 2001
2,680
68
Sendai, Japan
While I agree that simply having the "L" designation per se does not mean IQ is good, my experience is that it's a pretty good indicator.
No one is denying that more expensive lenses usually deliver better IQ -- and L glass is usually pricier.

I don't know about the others, but I've read between the lines of the original post that the OP is unsure that non-L lenses can match or beat the image quality of L lenses (any L lens). In particular, this creates a tendency to not consider other lenses that may be very good, e. g. some third-party lenses, or that people prefer to buy L-grade zooms with a suboptimal focal length range instead of lenses that are more suitable to crop sensors. Canon in particular has some lenses that are not L lenses for marchitectural reasons (the 17-55 mm f/2.8 comes to mind).

I don't think that you are among those people who focus on the letter L, but the OP might lean in that direction. This leads to comparisons of apples and oranges (different types of lenses are compared at very different apertures).
This notion largely came about 30+ years ago when zooms were first being developed and back then there was a clear quality difference.
That is correct. However, primes are typically brighter (not the case in the example you've quoted), i. e. they have much larger initial apertures. This is useful regardless of whether the IQ is the same.
