Yeah, but a marginal increase in cost for a better GPU would be trivial, and considering prices of PowerMac or PowerBook, consumers likely be willing to pay a bit more and get a better product. But anyway, that is all in the past now.
Got a tip for us?
Let us know
Become a MacRumors Supporter for $50/year with no ads, ability to filter front page stories, and private forums.
G5 Quad - 32GB possible?
- Thread starter Joshuarocks
- Start date
- Sort by reaction score
Yeah, but a marginal increase in cost for a better GPU would be trivial, and considering prices of PowerMac or PowerBook, consumers likely be willing to pay a bit more and get a better product. But anyway, that is all in the past now.
Amethyst1
macrumors G3
Maybe my words with regards to the 5200 were a bit harsh (I'm not usually a friend of hyperbole, so take them as irony if you wish 😉) but it is, indeed, not a very impressive GPU for more than one reason and it makes no sense to me at all that the supposedly inferior iBook got a more powerful, Core Image-capable GPU for its final refresh, even if it was limited by 32 MB VRAM and just a VGA output.
So I ended up with
Code:
\ comment
" "(0000000000000000800000000000000100000000800000000000000180000000F00000000000000280000000F00000000000000380000000F00000000000000480000000F00000000000000580000000F00000000000000580000000F0000000)" encode-bytes " reg" property
" "(8000000080000000FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF)" encode-bytes " bank-sizes" property
boot sd0:,\\:tbxiin /ramsc and used
Code:
setenv boot-device sd0:,\\:tbxi
reset-allthat did the trick.
For Linux, I put the ram extend commands in ofboot.b for Debian, OpenSUSE and Gentoo, which is thus loaded automatically in the boot picker.
Same difference all in all
BTW it is very likely that one is able to edit the erroneously reported "PC2-3200U-288" values (they actually run at PC2-4200 speed afaik) by changing " dimm-speeds", presumably by hex dumping the its values using " dimm-speeds" get-active-property then .s and <whatever is returned> dump as you indicated, and then change them all to the value that corresponds to PC2-4200U-444
Thanks again sasho648!
Cheers,
Last edited:
I wonder if the OF hack could be used for the iMac G5 iSight to get the stick to display in ASP, or on other macs, e.g. the G5 DC with e.g. 1Gb sticks to boot to OF and then only 2Gb sticks manually inserted? Or the regular iMac G5, which has two DDR slots so 1Gb + 2Gb? Same for the PB G4 DSLD (2 PC2-4200 slots), even though there are reports that G4s can't address more than 2Gb (which must be a firmware or possibly OpenFirmware limitation as 4Gb falls within 32 bits, if it's an OpenFirmware limitation there's hope)
Last edited:
B S Magnet
macrumors 603
Sorry I meant to have the PC2-5300 stick show up in ASP on the iMac G5 iSight, as the 4Gb stick will not show up there, unless this has been fixed?
B S Magnet
macrumors 603
I honestly have no idea. At the end of the day, just having 4GB work on them, even if ASP “misses” them, would seem to be good enough, yes?
For me by all means, however the devil is in the details for some people, and it was a simple fix on the Quad 🙂
Last edited:
Amethyst1
macrumors G3
See the cosmetic ASP fix for the iMac G5 iSight there:
On a similar note, has anyone ever tried more than 2Gb on the DLSD? Or are G4 macs forever doomed to 2Gb tops?
I was also wondering about Intel macs, anyone ever tried 4Gb sticks on the mini 1,1/2,1? Would rEFIt/rEFInd/OCLP have any in-depth control of hardware/firmware settings such as under OpenFirmware to enable such a mod as we did on the G5?
I was also wondering about Intel macs, anyone ever tried 4Gb sticks on the mini 1,1/2,1? Would rEFIt/rEFInd/OCLP have any in-depth control of hardware/firmware settings such as under OpenFirmware to enable such a mod as we did on the G5?
B S Magnet
macrumors 603
There have been folks who’ve tried to test different scenarios with the DLSD, but those tests were halted when their DLSD’s logic board failed (not related to said testing). The work to get >2GB on DLSDs to show up after booting is, far as I can suss, incomplete and not definitive.
Not tried 2Gb PC-2700 DDR1 DIMMS (they are hard to find) but have been meaning to, however it probably wouldn't be 8Gb total as you would still need a pair of 1Gb DIMMS to boot to OF and apply the reg hack from there, so it would be 7Gb, which would already be something!
One other option would be to buy 2Gb DDR SO-DIMMS and DDR1 DIMM adapters
I have an assumption that you can pre-determine the memory configuration in nvram and only then replace the memory sticks with 2gb.
I don't know, we would need to ask a Forth expert; re nvram the best we've been able to do is to load a Forth script from disk that assigns 4Gb sticks (on a Quad) in the reg using setenv (since they are otherwise not recognised). The script uses the following commands (for e.g. a 2x2Gb+6x4Gb configuration):
" "(0000000000000000800000000000000100000000800000000000000280000000F00000000000000380000000F00000000000000480000000F00000000000000580000000F00000000000000680000000F0000000)" encode-bytes " reg" property
" "(8000000080000000FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF)" encode-bytes " bank-sizes" property
(the latter so that the 4Gb DIMMs are recognised in ASP)
So I guess that if one were to use 2x1Gb sticks +2x2Gb sticks on a G5 DP with 4 slots, those commands could then become e.g.:
" "(000000000000000040000000000000010000000040000000000000018000000080000000000000028000000080000000)" encode-bytes " reg" property
" "(40000000400000008000000080000000)" encode-bytes " bank-sizes" property
If anyone knows how whether it is possible to set this in nvram directly? Not sure as the documented options for setenv seem rather limited
Of course, it could also well be that 2Gb sticks are supported out of the box (they are on DDR2 models), but if they aren't, the above would be a start for the course of action to follow
Last edited:
The maximum would be 6Gb on those models using the ramsc script -if it works at all on those machines-, not 7Gb, sorry! Having one myself, if I ever come up with 2Gb sticks, I'll let you know (if it ever falls back to a normal power mode - it regularly has long phases, i.e. weeks - whereby it's stuck on fans blowing at full power - they don't show up in hardware monitor for example when this happens, haven't been able to determine the exact cause, likely ambient temperature related and the northbridge needing repasting, but it regularly and randomly pops out of this mode, often after booting an OSX install DVD)
Last edited:
This is probably possible, however some extra resistors would likely need to be soldered in too - look for empty resistor pads around the DIMM slot pads. You would likely need a reflow station with a heating plate for the ram slots - too many pads for a single soldering iron! Might be easier to get a DP mobo with 8 slots (I have one and am planning to swap my DP's for it, if it ends up never popping out of its full power fan mode even after a repaste - even though it otherwise works fine - my ears can't bear it anymore!)
Last edited:
I bought two G5 june 2004 1.8's a couple days ago, so far they are in transit and I'm just pondering possible modifications
Doq
macrumors 6502a
I doubt it. There's probably a good reason why the slots aren't populated, and if my experience with server and workstation hardware is to be believed, it's because the unpopulated slots are tied to the also unpopulated second processor. Even if you were to populate all the board components to add the slots, odds are the slots won't be recognised due to there being no processor to see them.
You can likely see this in action by populating a DP logic board with only one processor and seeing how much RAM gets detected.
