Getting Premiere Pro CS5 To Use CUDA in GTX 570 (MP1,1)

Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
When I run the GPU sniffer is get this;

Code:
MacPro:~ tess$ /Applications/Adobe\ Premiere\ Pro\ CS5/Adobe\ Premiere\ Pro\ CS5.app/Contents/GPUSniffer.app/Contents/MacOS/GPUSniffer
Texture memory: 0
Vendor string:    NVIDIA Corporation
Renderer string:  NVIDIA GeForce GTX 570 OpenGL Engine
Version string:   2.1 NVIDIA-7.33.0

OpenGL version as determined by Extensionator...
OpenGL Version 2.0
Supports shaders!
Supports BGRA -> BGRA Shader
Supports VUYA Shader -> BGRA
Supports UYVY/YUYV ->BGRA Shader
Supports YUV 4:2:0 -> BGRA Shader
Testing for CUDA support...
   Didn't find any devices that support CUDA.
Completed shader test!
Internal return value: 7
When I search around for solutions I get threads from 2011 saying to use older CUDA drivers but when I try that I then get errors:
Code:
Testing for CUDA support...
GPUSniffer(342,0x7fff7d498960) malloc: *** error for object 0x1075000b0: pointer being freed was not allocated
*** set a breakpoint in malloc_error_break to debug
I added the card name "GeForce GTX 570" to the "cuda_supported_cards.txt" anyway but of course I don't get CUDA rendering.

Any solutions not from 2011? :)


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
  • Did you install Cuda drivers?
  • Use Cuda-z to verify it is working.
  • Name must be just like. In system profiler
  • Cuda drivers? You mean that thing from NVidia which places the CUDA Preferences in the System Preferences panel? Yes, I tried an old version and also the newest version: 5.0.45

  • Cuda-Z huh? Mm-kay...

    Code:
    CUDA-Z Report
    =============
    Version: 0.7.184 http://cuda-z.sf.net/
    OS Version: Mac OS X 10.7.5 11G63b
    Driver Version: 7.33.0 295.00.05f03
    Driver Dll Version: 5.0
    Runtime Dll Version: 5.0

    Core Information
    ----------------
    	Name: GeForce GTX 570
    	Compute Capability: 2.0
    	Clock Rate: 1560 MHz
    	PCI Location: 0:8:0
    	Multiprocessors: 15 (480 Cores)
    	Therds Per Multiproc.: 1536
    	Warp Size: 32
    	Regs Per Block: 32768
    	Threads Per Block: 1024
    	Threads Dimensions: 1024 x 1024 x 64
    	Grid Dimensions: 65535 x 65535 x 65535
    	Watchdog Enabled: Yes
    	Integrated GPU: No
    	Concurrent Kernels: Yes
    	Compute Mode: Default

    Memory Information
    ------------------
    	Total Global: 1279.69 MiB
    	Bus Width: 320 bits
    	Clock Rate: 1900 MHz
    	Error Correction: No
    	L2 Cache Size: 48 KiB
    	Shared Per Block: 48 KiB
    	Pitch: 2048 MiB
    	Total Constant: 64 KiB
    	Texture Alignment: 512 B
    	Texture 1D Size: 65536
    	Texture 2D Size: 65536 x 65535
    	Texture 3D Size: 2048 x 2048 x 2048
    	GPU Overlap: Yes
    	Map Host Memory: Yes
    	Unified Addressing: No
    	Async Engine: Yes, Unidirectional

    Performance Information
    -----------------------
    Memory Copy
    	Host Pinned to Device: 2698.87 MiB/s
    	Host Pageable to Device: 1791.86 MiB/s
    	Device to Host Pinned: 3576.71 MiB/s
    	Device to Host Pageable: 1158.553 MiB/s
    	Device to Device: 60.224 GiB/s
    GPU Core Performance
    	Single-precision Float: 1786.06 Gflop/s
    	Double-precision Float: 267.307 Gflop/s
    	32-bit Integer: 767.046 Giop/s
    	24-bit Integer: 766.274 Giop/s

    Generated: Fri May 17 17:44:35 2013
  • System Profiler? I'm not sure what that is. You mean in the "System Information"
    (About This Mac --> More Info --> System Report --> Graphics/Displays)?
    Code:
    NVIDIA GeForce GTX 570:

      Chipset Model:	NVIDIA GeForce GTX 570
      Type:			GPU
      Bus:			PCIe
      Slot:			Slot-1
      PCIe Lane Width:	x16
      VRAM (Total):		1280 MB
      Vendor:		NVIDIA (0x10de)
      Device ID:		0x1086
      Revision ID:		0x00a1
      ROM Revision:		preset 1.0.0
      Displays:

    Acer H233H:
      Resolution:		1920 x 1080 @ 60 Hz
      Pixel Depth:		32-Bit Color (ARGB8888)
      Display Serial No.:	LFS0W0134342
      Main Display:		Yes
      Mirror:		Off
      Online:		Yes
      Rotation:		Supported
      Television:		Yes

Last edited:

nigelbb

macrumors 65816
Dec 22, 2012
1,022
189
I'm on CS6 but this is the contents of my cuda_supported_cards.txt

GeForce GTX 285
GeForce GT 650M
Quadro CX
Quadro FX 4800
Quadro 4000
GeForce GTX 570


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
I'm on CS6 but this is the contents of my cuda_supported_cards.txt

GeForce GTX 285
GeForce GT 650M
Quadro CX
Quadro FX 4800
Quadro 4000
GeForce GTX 570
Yeah, when I follow the steps in the 5 or 6 identical (verbatim) step tutorials for this hack "GeForce GTX 570" is the string I'm supposed to add. I tried that already of course. But according to the same step tutorials adding the name like that only works if the "GPUSniffer" reports that CUDA cores were found. When I run it it says: "Didn't find any devices that support CUDA." as shown in the first post (above).


jasonvp

macrumors 6502a
Jun 29, 2007
604
0
Northern VA
When I run it it says: "Didn't find any devices that support CUDA." as shown in the first post (above).
There's a driver issue of some sort going on here. I dunno what it is, precisely as it's been a while since I've used Premiere Pro on 10.7.x. But, as far as Premiere is concerned, you've done all of the right things. When the GPU Sniffer tells you it sees nothing that supports CUDA, that's the hint that something's up with your drivers.

jas


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
There's a driver issue of some sort going on here. I dunno what it is, precisely as it's been a while since I've used Premiere Pro on 10.7.x. But, as far as Premiere is concerned, you've done all of the right things. When the GPU Sniffer tells you it sees nothing that supports CUDA, that's the hint that something's up with your drivers.
Hmmm, great... I wonder what it could be?

Anyone know a good method, procedure, or starting point for detecting such "driver issues"?



Mine uses Cuda driver 5.0.59 for a GT430, odd
That is odd. I blame the wholly inadequate NVidia support for OS X on their site and apparently in their attitudes. :p



I presume that like me you are running Mountain Lion whereas the OP is running Lion on a Mac Pro 1,1. However the download page for the 10.7.5 295.00.05f03 drivers does link to the newest CUDA driver so I guess that is what should be used http://www.nvidia.co.uk/object/macosx-cuda-5.0.59-driver-uk.html
Thanks I installed it without a hitch. Of course nothing other than the driver version has changed - still all the same problems (retested all).


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
You can follow the steps from this site also. I follow the steps from him to enable cuda in my adobe CS5.5 Production premium. It work and i don't have any problem after that. download the attachment from his site and it will have the steps of what to do. For CS6 and 5.5 is the same method just different folder name.

http://www.vidmuze.com/how-to-enable-gpu-cuda-in-adobe-cs6-for-mac/
Thanks! Yup, that's yet another identical verbatim step tutorial like I followed.

Originally I used TextEdit to modify the file and add "GeForce GTX 570" to the list. I have since restored a TM virgin copy of "Adobe Premiere Pro CS5.app" and used nano (an enhanced free Pico clone) to edit the file. It didn't matter tho.

No change. And I still get the following output from GPUSniffer:

Code:
MacPro:~ tess$ /Applications/Adobe\ Premiere\ Pro\ CS5/Adobe\ Premiere\ Pro\ CS5.app/Contents/GPUSniffer
-bash: /Applications/Adobe Premiere Pro CS5/Adobe Premiere Pro CS5.app/Contents/GPUSniffer: No such file or directory
MacPro:~ tess$ /Applications/Adobe\ Premiere\ Pro\ CS5/Adobe\ Premiere\ Pro\ CS5.app/Contents/GPUSniffer.app/Contents/MacOS/GPUSniffer
Texture memory: 0
Vendor string:    NVIDIA Corporation
Renderer string:  NVIDIA GeForce GTX 570 OpenGL Engine
Version string:   2.1 NVIDIA-7.33.0

OpenGL version as determined by Extensionator...
OpenGL Version 2.0
Supports shaders!
Supports BGRA -> BGRA Shader
Supports VUYA Shader -> BGRA
Supports UYVY/YUYV ->BGRA Shader
Supports YUV 4:2:0 -> BGRA Shader
Testing for CUDA support...
   Didn't find any devices that support CUDA.
Completed shader test!
Internal return value: 7


TheEasterBunny

macrumors 6502
Jan 22, 2013
251
0
Delaware

linuxcooldude

macrumors 68020
Mar 1, 2010
2,471
4,681
I'm on CS6 but this is the contents of my cuda_supported_cards.txt

GeForce GTX 285
GeForce GT 650M
Quadro CX
Quadro FX 4800
Quadro 4000
GeForce GTX 570
I had the same problem, but moved GeForce GTX 570 to the top of the list and it worked.


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
This might be 32/64 bit issue.
What processes or files would I check to find out?


I had the same problem, but moved GeForce GTX 570 to the top of the list and it worked.
I tried it at top, bottom, and middle. I tried with just one 570 "name" in the list and with all the variants I listed above all at once. Nada...

Last edited:

666sheep

macrumors 68040
Dec 7, 2009
3,623
211
Poland
This might be 32/64 bit issue.
And it most likely is.
Tried to turn on MPE on 570 in 1,1 yesterday, no dice. GPUSniffer detects it without problems but says: "Not chosen because it did not match the named list of cards". Exactly the same like in this case: http://forums.adobe.com/message/4424709
Didn't test it in K64 because I got rid of Chameleon for now.

On the other hand, I know that it's possible to enable MPE in K32 with proper EFI32 card. So, my guess would be that 64bit EFI and unflashed cards do need K64, MPE-capable 32bit EFI cards will work with K32.


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
And it most likely is.
Tried to turn on MPE on 570 in 1,1 yesterday, no dice. GPUSniffer detects it without problems but says: "Not chosen because it did not match the named list of cards". Exactly the same like in this case: http://forums.adobe.com/message/4424709
Didn't test it in K64 because I got rid of Chameleon for now.

On the other hand, I know that it's possible to enable MPE in K32 with proper EFI32 card. So, my guess would be that 64bit EFI and unflashed cards do need K64, MPE-capable 32bit EFI cards will work with K32.
Well that sucks nuggets... I chose a 570 over a 680 just to avoid the "64-bit" Kernel issue! Sigh...


MacVidCards

Suspended
Nov 17, 2008
6,096
1,029
Hollywood, CA
And it most likely is.
Tried to turn on MPE on 570 in 1,1 yesterday, no dice. GPUSniffer detects it without problems but says: "Not chosen because it did not match the named list of cards". Exactly the same like in this case: http://forums.adobe.com/message/4424709
Didn't test it in K64 because I got rid of Chameleon for now.

On the other hand, I know that it's possible to enable MPE in K32 with proper EFI32 card. So, my guess would be that 64bit EFI and unflashed cards do need K64, MPE-capable 32bit EFI cards will work with K32.
I do know that we sell a 8800GT in a 1GB size that meets the needs for MPE and we rarely get them returned. SO I have every reasont o believe that they work for the majority of people. So that is why I believe that EFI32 card with sufficient CUDA level and more than 768MB is what is needed on a 1,1.

Sadly the G80 cards, while frequently faster than G92, do not support a new enough version of CUDA.

So Quadro 4600 and 5600 and 8800GTX & Ultra don't work either.


5050

macrumors regular
May 28, 2009
172
2
Well that sucks nuggets... I chose a 570 over a 680 just to avoid the "64-bit" Kernel issue! Sigh...
Any luck getting your MacPro1,1 to recognize the 570? After installing the 690 into my flashed MacPro5,1, I'd love to have a CUDA option for my MacPro2,1.


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
Any luck getting your MacPro1,1 to recognize the 570? After installing the 690 into my flashed MacPro5,1, I'd love to have a CUDA option for my MacPro2,1.
No. I'm being lazy about it. I guess there are walk-thrus and downloadable ROM images but I haven't taken the time to look yet.

If you do post or link up your findings here. When I do I will do the same.


666sheep

macrumors 68040
Dec 7, 2009
3,623
211
Poland
Well that sucks nuggets... I chose a 570 over a 680 just to avoid the "64-bit" Kernel issue! Sigh...
I can now confirm that in K64 mode it works flawlessly with unflashed and EFI64 flashed 570 as well.
Mac Pro 1,1, 10.7.5 booted with 64-bit kernel + latest CUDA, Premiere CS6.

But IDK why GPUSniffer from Pr 5 does not recognize your card... One from CS6 recognizes mine in both kernel modes.

Maybe the answer is here: http://blogs.adobe.com/premierepro/2011/04/adobe-premiere-pro-cs5-5-improvements-in-cuda-processing-and-the-mercury-playback-engine.html

They state that CS5 does not support 570, even in Win (last post): http://forums.creativecow.net/thread/205/875843


Tesselator

macrumors 601
Original poster
Jan 9, 2008
4,601
4
Japan
I can now confirm that in K64 mode it works flawlessly with unflashed and EFI64 flashed 570 as well.
Mac Pro 1,1, 10.7.5 booted with 64-bit kernel + latest CUDA, Premiere CS6.

But IDK why GPUSniffer from Pr 5 does not recognize your card... One from CS6 recognizes mine in both kernel modes.

Maybe the answer is here: http://blogs.adobe.com/premierepro/2011/04/adobe-premiere-pro-cs5-5-improvements-in-cuda-processing-and-the-mercury-playback-engine.html

They state that CS5 does not support 570, even in Win (last post): http://forums.creativecow.net/thread/205/875843

OK, I get it. :( Thanks man! :)
