- Thread starter Dal123
- Start date
- Sort by reaction score
Starting tags (of any HTML kind) are like <body>, <p>, <div>
Ending tags close it, </body>, </p>, </div>
That CSS needs to be inside a style tag, which is in the head tag. Also, the id attribute should always be unique, you currently have two div tags that have the same id name.
HTML:
<html>
<head>
...
<style type="text/css">
#slideshow {
width : 160px;
height : 160px;
padding : 10px;
}
</style>
...
</head>
<body>
...
<div id="slideShow">Loading...</div>
<div id="slideshow"></div>
...
</body>
</html>That site is generally one of the easier reading ones. Another one I see recommended sometimes is HTML Dog. I don't have any general books, just some for PHP and AJAX. I just casually learned online and by looking at other people's code.
Nope, just been a hobbyist for about 8 years now. Completely self taught, but I do have a background in software programming so this web stuff is pretty easy for me. I always joke that my first web site was created using MS Word because I saw it had a save as HTML option. It created absolutely horrible code though, but didn't realize it at the time. I pretty much just hand code everything now. I do more server side stuff now anyway so there's no visual editors for all that.
Well, on occasion I'll work for money, but it's a rare thing for me. I do it for fun as my real job is a bit more serious.
Loading this slideshow is pretty hard. I have managed to copy and paste the code into the site.
I am now managing to get the slideshow to load (however it is not with my pictures) I would like to know how to insert my pictures? There is also a thing where I roll my mouse over it pauses the slideshow, also a big pause comes up. I don't like this and would like to remove it.
Also which is very worrying, I have a logo at the top, this used to be visible, now it is not visible in 'design' view. When I preview in browser it still comes up. I am very very confused now.
I understand that this slideshow has quite a bit of fiddling behind it. I have gone through w3schools.com to try to learn, however there is not too much that explains this sort of thing in javascript. Also the Google Ajax Feed API does not give much information on the bits behind it.
I am now managing to get the slideshow to load (however it is not with my pictures) I would like to know how to insert my pictures? There is also a thing where I roll my mouse over it pauses the slideshow, also a big pause comes up. I don't like this and would like to remove it.
Also which is very worrying, I have a logo at the top, this used to be visible, now it is not visible in 'design' view. When I preview in browser it still comes up. I am very very confused now.
I understand that this slideshow has quite a bit of fiddling behind it. I have gone through w3schools.com to try to learn, however there is not too much that explains this sort of thing in javascript. Also the Google Ajax Feed API does not give much information on the bits behind it.
HTML:
[CODE]<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
<title>Untitled Document</title>
<meta http-equiv="Content-Type" content="text/html; charset=iso-8859-1" />
</head>
<table width="100%" border="0">
<!--DWLayoutTable-->
<tr>
<td width="100%" height="96" valign="top"><div align="center"><img src="Images/Logo-Website.gif" width="900" height="101" /></div></td>
<td width="1"></td>
</tr>
<tr>
<td height="12"></td>
<td></td>
</tr><tr><td height="3"></td><td><img src="spacer.gif" alt="" width="1" height="1" /></td></tr>
</table>
<p> </p>
<p> </p>
<table width="100%" border="0">
<tr> </tr>
</table>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=utf-8"/>
<title>Google AJAX Feed API - AJAX Slide Show Sample</title>
<script src="http://www.google.com/jsapi"
type="text/javascript"></script>
<script src="http://www.google.com/uds/solutions/slideshow/gfslideshow.js"
type="text/javascript"></script>
<style type="text/css">
.gss a img {border : none;}
.gss {
width: 288px;
height: 216px;
color: #dddddd;
background-color: #000000;
padding: 8px;
}
</style>
<script type="text/javascript">
function load() {
var samples = "http://dlc0421.googlepages.com/gfss.rss";
var options = {
displayTime: 2000,
transistionTime: 600,
linkTarget : google.feeds.LINK_TARGET_BLANK
};
new GFslideShow(samples, "slideshow", options);
}
google.load("feeds", "1");
google.setOnLoadCallback(load);
</script>
</head>
<body>
<div id="body">
<div class="gss" id="slideshow">Loading...</div>
</div>
</body>
</html>
</body>
</html>[/CODE]Let's first take care of the HTML issues you've got going on. The page has two heads
as in two head tag areas. A HTML page should only have one and will come right after the opening HTML tag. To help you out I took your HTML and fixed the HTML validation issues. I recommend comparing mine with yours see how the HTML should be laid out in terms of the HTML, head, and body tags.
So start with that and see if it starts to help, then we'll add some of your pictures. I'll have to look up this script to see how you add images ayways.
as in two head tag areas. A HTML page should only have one and will come right after the opening HTML tag. To help you out I took your HTML and fixed the HTML validation issues. I recommend comparing mine with yours see how the HTML should be laid out in terms of the HTML, head, and body tags.So start with that and see if it starts to help, then we'll add some of your pictures. I'll have to look up this script to see how you add images ayways.
HTML:
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
<meta http-equiv="Content-Type" content="text/html; charset=utf-8"/>
<title>Google AJAX Feed API - AJAX Slide Show Sample</title>
<script src="http://www.google.com/jsapi"
type="text/javascript"></script>
<script src="http://www.google.com/uds/solutions/slideshow/gfslideshow.js"
type="text/javascript"></script>
<style type="text/css">
.gss a img {border : none;}
.gss {
width: 288px;
height: 216px;
color: #dddddd;
background-color: #000000;
padding: 8px;
}
</style>
<script type="text/javascript">
function load() {
var samples = "http://dlc0421.googlepages.com/gfss.rss";
var options = {
displayTime: 2000,
transistionTime: 600,
linkTarget : google.feeds.LINK_TARGET_BLANK
};
new GFslideShow(samples, "slideshow", options);
}
google.load("feeds", "1");
google.setOnLoadCallback(load);
</script>
</head>
<body>
<table width="100%" border="0">
<!--DWLayoutTable-->
<tr>
<td width="100%" height="96" valign="top"><div align="center"><img src="Images/Logo-Website.gif" width="900" height="101" alt="logo" /></div></td>
<td width="1"></td>
</tr>
<tr>
<td height="12"></td>
<td></td>
</tr>
<tr>
<td height="3"></td><td><img src="spacer.gif" alt="" width="1" height="1" /></td>
</tr>
</table>
<div id="body">
<div class="gss" id="slideshow">Loading...</div>
</div>
</body>
</html>External Source Code.
Ok I have been learning a bit on JavaScript. WOW.
I have noticed that this slideshow loads a java script code to this
http://www.google.com/uds/solutions/slideshow/gfslideshow.js
In there is this impressive code that loads the slideshow:
Ok I have been learning a bit on JavaScript. WOW
.I have noticed that this slideshow loads a java script code to this
http://www.google.com/uds/solutions/slideshow/gfslideshow.js
In there is this impressive code that loads the slideshow:
PHP:
/**
* Copyright (c) 2008 Google Inc.
*
* You are free to copy and use this sample.
* License can be found here: http://code.google.com/apis/ajaxsearch/faq/#license
*/
/**
* @fileoverview A slideshow control based on the AJAX Feed API.
* @author dcollison@google.com (Derek Collison)
*/
/**
* GFslideshow
* @param {String} photoFeed The feed URL.
* @param {String|Object} container Either the id string or the element itself.
* @param {Object} options Options map.
* @constructor
*/
function GFslideShow(photoFeed, container, options) {
this.feedUrl = null;
this.directEntries = null;
if (typeof photoFeed == 'string') {
this.feedUrl = photoFeed;
} else if (photoFeed && photoFeed.length && photoFeed.length > 1) {
this.directEntries = photoFeed;
} else {
throw "invalid argument: photoFeed";
}
if (typeof container == "string") {
container = document.getElementById(container);
}
this.container = container;
this.parseOptions(options);
this.setup();
}
// Thumbnail size preferences.
GFslideShow.THUMBNAILS_SMALL = "small";
GFslideShow.THUMBNAILS_MEDIUM = "medium";
GFslideShow.THUMBNAILS_LARGE = "large";
// Thumbnail tag names and namespaces.
// MediaRSS.
GFslideShow.MRSS_THUMBNAIL_TAG = "thumbnail";
GFslideShow.MRSS_THUMBNAIL_NS = "http://search.yahoo.com/mrss/";
// iTunes.
GFslideShow.ITMS_THUMBNAIL_TAG = "coverArt";
GFslideShow.ITMS_THUMBNAIL_NS = "http://phobos.apple.com/rss/1.0/modules/itms/";
// MediaRSS is default.
GFslideShow.DEFAULT_THUMBNAIL_TAG = GFslideShow.MRSS_THUMBNAIL_TAG;
GFslideShow.DEFAULT_THUMBNAIL_NS = GFslideShow.MRSS_THUMBNAIL_NS;
// Default display timings, all in milliseconds.
GFslideShow.DEFAULT_DISPLAY_TIME = 3000;
GFslideShow.DEFAULT_TRANSISTION_TIME = 1000;
GFslideShow.DEFAULT_TRANSISTION_STEP = 40;
GFslideShow.DEFAULT_PAUSE_PNG = google.loader.ServiceBase +
"/solutions/slideshow/pause.png";
GFslideShow.DEFAULT_PLAY_PNG = google.loader.ServiceBase +
"/solutions/slideshow/play.png";
// Full Control Setting
GFslideShow.FC_PAUSE_PNG = {
small : google.loader.ServiceBase + "/solutions/slideshow/btn_pause_small.png",
big : google.loader.ServiceBase + "/solutions/slideshow/btn_pause.png"
};
GFslideShow.FC_PLAY_PNG = {
small : google.loader.ServiceBase + "/solutions/slideshow/btn_play_small.png",
big : google.loader.ServiceBase + "/solutions/slideshow/btn_play.png"
};
GFslideShow.FC_PREV_PNG = {
small : google.loader.ServiceBase + "/solutions/slideshow/btn_prev_small.png",
big : google.loader.ServiceBase + "/solutions/slideshow/btn_prev.png"
};
GFslideShow.FC_NEXT_PNG = {
small : google.loader.ServiceBase + "/solutions/slideshow/btn_next_small.png",
big : google.loader.ServiceBase + "/solutions/slideshow/btn_next.png"
};
GFslideShow.DEFAULT_FC_FADEOUT_TIME = 5000;
GFslideShow.DEFAULT_FC_OPACITY = 0.65;
/**
* Setup default option map and apply overrides from constructor.
* @param {Object} options Options map.
* @private
*/
GFslideShow.prototype.parseOptions = function(options) {
var maxEntries;
if (google != undefined && google.feeds != undefined) {
maxEntries = google.feeds.Feed.MAX_ENTRIES;
} else {
maxEntries = 20;
}
// Default Options
this.options = {
numResults : maxEntries,
scaleImages : false,
thumbnailTag : GFslideShow.DEFAULT_THUMBNAIL_TAG,
thumbnailNamespace : GFslideShow.DEFAULT_THUMBNAIL_NS,
thumbnailSize : GFslideShow.THUMBNAILS_LARGE,
linkTarget : null,
displayTime : GFslideShow.DEFAULT_DISPLAY_TIME,
transitionTime : GFslideShow.DEFAULT_TRANSISTION_TIME,
transitionStep : GFslideShow.DEFAULT_TRANSISTION_STEP,
pauseOnHover : true,
pauseImage : GFslideShow.DEFAULT_PAUSE_PNG,
pauseStateCallback : null,
scalePauseImage : true,
autoCleanup : true,
thumbnailUrlResolver : null,
transitionCallback : null,
transitionAnimationCallback : null,
feedLoadCallback : null,
feedProcessedCallback : null,
imageClickCallback : null,
centerBias : { topBias : 0, leftBias : 0 },
pauseCenterBias : { topBias : 0, leftBias : 0 },
fullControlPanel : false,
fullControlPanelCursor : false,
fullControlPanelFadeOutTime : GFslideShow.DEFAULT_FC_FADEOUT_TIME,
fullControlPanelPlayCallback : null,
fullControlPanelSmallIcons : false,
maintainAspectRatio : true
};
if (options) {
for (o in this.options) {
if (typeof options[o] != "undefined") {
this.options[o] = options[o];
}
}
}
// Override strange options
if (this.options.displayTime < 100) {
this.options.displayTime = 100;
}
// Calculated
var ts = (this.options.transitionTime / this.options.transitionStep);
this.delta = Math.min(1, (1.0/ts));
// Flag to start
this.started = false;
};
/**
* Basic setup.
* @private
*/
GFslideShow.prototype.setup = function() {
if (this.container == null) return;
// Browser fun.
if (window.ActiveXObject) {
this.ie = this[window.XMLHttpRequest ? 'ie7' : 'ie6'] = true;
} else if (window.opera) {
this.opera = true;
} else if (document.childNodes && !document.all && !navigator.taintEnabled) {
this.safari = true;
if (navigator.userAgent.indexOf('iPhone') > 0) {
this.iphone = true;
}
} else if (document.getBoxObjectFor != null) {
this.gecko = true;
}
// Feeds..
if (this.feedUrl) {
this.feed = new google.feeds.Feed(this.feedUrl);
this.feed.setResultFormat(google.feeds.Feed.MIXED_FORMAT);
this.feed.setNumEntries(this.options.numResults);
this.feed.load(this.bind(this.feedLoaded));
} else if (this.directEntries) {
this.feedLoaded(this.directEntries);
}
};
/**
* Add new entries to the existing ones. Only useful in direct entry mode.
* @param {Object} newEntries the additional entries Array.
*/
GFslideShow.prototype.addEntries = function(newEntries) {
this.processEntries(newEntries);
if (!this.thumb_timer) {
this.processThumbs();
}
};
/**
* Helper method to bind this instance correctly.
* @param {Object} method function/method to bind.
* @return {Function}
* @private
*/
GFslideShow.prototype.bind = function(method) {
var self = this;
var opt_args = [].slice.call(arguments, 1);
return function() {
var args = opt_args.concat([].slice.call(arguments));
return method.apply(self, args);
}
};
/**
* Process mouseover event.
* @param {Event} e Optional passed in event.
* @private
*/
GFslideShow.prototype.mouseOver = function(e) {
var event = e || window.event;
var relatedTarget = event.relatedTarget || event.fromElement;
while(relatedTarget != null) {
if (relatedTarget == this.container) {
return;
}
relatedTarget = relatedTarget.parentNode;
}
if (this.options.fullControlPanel) {
if (this.options.pauseOnHover && !this.display_paused) {
this.pauseOrPlayFullControl();
}
this.fadeInFullControl();
} else {
this.display_paused = true;
if (this.pauseImage) {
this.pauseImage.style.visibility = "visible";
}
}
if (this.options.pauseStateCallback) {
this.options.pauseStateCallback(this.display_paused);
}
};
/**
* Process mouseout event.
* @param {Event} e Optional passed in event.
* @private
*/
GFslideShow.prototype.mouseOut = function(e) {
var event = e || window.event;
var relatedTarget = event.relatedTarget || event.toElement;
while(relatedTarget != null) {
if (relatedTarget == this.container) {
return;
}
relatedTarget = relatedTarget.parentNode;
}
if (this.options.fullControlPanel) {
this.fadeOutFullControl();
this.container.onmousemove = null;
if (this.options.pauseOnHover && this.display_paused) {
this.pauseOrPlayFullControl();
}
} else {
this.display_paused = false;
if (this.pauseImage) {
this.pauseImage.style.visibility = "hidden";
}
}
if (this.options.pauseStateCallback) {
this.options.pauseStateCallback(this.display_paused);
}
if (this.display_timer == null && this.transition_timer == null) {
// restart.
this.displayNextPhoto();
}
};
GFslideShow.prototype.operaClickAndCallout = function() {
var entry = this.entries[this.photo_index];
var tmpLink = this.createLink(entry.link);
tmpLink.click();
};
/**
* Programatic pause action.
*/
GFslideShow.prototype.pause = function(opt_suppressPauseImage) {
var pi = this.pauseImage;
if (opt_suppressPauseImage) {
this.pauseImage = null;
}
this.pauseAndCallout();
this.pauseImage = pi;
};
/**
* Programatic resume action.
*/
GFslideShow.prototype.resume = function() {
this.resumeSlideShow();
};
/**
* Process pause action and associated user callout.
* @private
*/
GFslideShow.prototype.pauseAndCallout = function() {
this.display_paused = true;
if (this.pauseImage) {
this.pauseImage.style.visibility = "visible";
}
// for some reason a mouseout happens
// when we click and swap divs...
this.container.onmouseout = null;
if (this.options.imageClickCallback) {
this.options.imageClickCallback(this.entries[this.photo_index]);
}
};
/**
* Resume the slideshow after a pause action.
*/
GFslideShow.prototype.resumeSlideShow = function() {
if (this.options.pauseOnHover || this.options.fullControlPanel) {
this.container.onmouseover = this.bind(this.mouseOver);
this.container.onmouseout = this.bind(this.mouseOut);
}
this.display_paused = false;
if (this.pauseImage) {
this.pauseImage.style.visibility = "hidden";
}
if (this.display_timer == null && this.transition_timer == null) {
// restart.
this.displayNextPhoto();
}
};
/**
* Helper method to properly clear a node and its children.
* @param {Object} node Node to clear.
* @private
*/
GFslideShow.prototype.clearNode = function(node) {
if (node == null) return;
var child;
while (child = node.firstChild) {
node.removeChild(child);
}
};
/**
* Setup our own subcontainer to the user supplied container.
* @private
*/
GFslideShow.prototype.createSubContainer = function() {
var div = document.createElement("div");
div.style.width = "100%";
div.style.height = "100%";
div.style.position = "relative";
div.style.overflow = "hidden";
this.clearNode(this.container);
this.container.appendChild(div);
// Hold onto our sub-container.
this.container = div;
};
/**
* Select the appropriate thumbnail url from the array of thumbnails provided
* based on options.
* @param {Array} thumbNodes Array of thumbnails urls.
* @private
*/
GFslideShow.prototype.grabThumb = function(thumbNodes) {
var ti = 0;
if (thumbNodes.length > 1) {
// Use size hint.
if (this.options.thumbnailSize == GFslideShow.THUMBNAILS_LARGE) {
ti = thumbNodes.length - 1;
} else if (this.options.thumbnailSize == GFslideShow.THUMBNAILS_MEDIUM) {
ti = Math.floor(thumbNodes.length / 2);
}
}
var node = thumbNodes[ti];
var thumb = null;
var thumb = node.getAttribute("url");
if (!thumb) {
thumb = node.firstChild.nodeValue;
}
return thumb;
};
/**
* Process the thumbs and create appropriate images. These can be done in
* chunks.
* @param {Number} opt_chunk optional chunk size to process.
* @param {Number} opt_timeout optional timeout for next chunk.
* @private
*/
GFslideShow.prototype.processThumbs = function(opt_chunk, opt_timeout) {
this.thumb_timer = null;
var start = this.thumbs_index;
var num = this.entries.length;
var chunk = opt_chunk || 4;
if (num > (start + chunk)) {
num = (start + chunk);
// schedule next batch.
var cb = this.bind(this.processThumbs);
var to = opt_timeout || Math.round(this.options.displayTime / 4);
this.thumb_timer = window.setTimeout(cb, to);
}
for (var i = start; i < num; i++) {
var thumbUrl = this.entries[i].thumbUrl;
var image = this.createImage(thumbUrl);
this.images.push(image);
if (this.options.linkTarget) {
if (!this.opera) {
var link = this.createLink(this.entries[i].link);
link.appendChild(image);
this.container.appendChild(link);
} else { // Opera Hack
image.onclick = this.bind(this.operaClickAndCallout);
image.style.cursor = 'pointer';
this.container.appendChild(image);
}
} else {
this.container.appendChild(image);
}
if (image.complete) {
// We are already loaded and we have size dimensions.
this.imageLoaded(image);
} else {
// We need to wait for the image to load..
image.onerror = this.bind(this.imageError, image);
image.onload = this.bind(this.imageLoaded, image);
}
this.thumbs_index++;
}
};
/**
* Process and setup the entries
* @param {Object} entries Entries array.
* @private
*/
GFslideShow.prototype.processEntries = function(entries) {
for (var i = 0; i < entries.length; i++) {
var thumbUrl = null;
if (this.options.thumbnailUrlResolver) {
thumbUrl = this.options.thumbnailUrlResolver(entries[i]);
} else {
var thumbNodes = google.feeds.getElementsByTagNameNS(
entries[i].xmlNode,
this.options.thumbnailNamespace,
this.options.thumbnailTag);
if (thumbNodes && thumbNodes.length > 0) {
thumbUrl = this.grabThumb(thumbNodes);
}
}
if (thumbUrl) {
entries[i].thumbUrl = thumbUrl;
this.entries.push(entries[i]);
}
}
};
/**
* Callback associated with the AJAX Feed api after load.
* @param {Object} result Loaded result.
* @private
*/
GFslideShow.prototype.feedLoaded = function(result) {
if (this.options.feedLoadCallback) {
this.options.feedLoadCallback(result);
}
if ((this.feedUrl && result.error) ||
(this.directEntries && this.directEntries.length == 0) ) {
if (!this.options.feedLoadCallback) {
this.container.innerHTML = "<center>feed could not be loaded.</center>";
}
return;
}
this.createSubContainer();
if (this.container.offsetWidth) {
// snapshot.
this.width = this.container.offsetWidth;
this.height = this.container.offsetHeight;
}
this.createPauseImage();
this.images = [];
this.entries = [];
this.thumbs_index = 0;
var entries;
if (this.feedUrl) {
entries = result.feed.entries;
} else {
entries = this.directEntries;
}
// Process the entries.
this.processEntries(entries);
if (this.options.feedProcessedCallback) {
this.options.feedProcessedCallback(result);
}
// Enable full panel control mode.
if (this.options.fullControlPanel && this.entries.length > 0) {
this.createFullControlPanel();
}
// Attach mouse handlers if applicable for pausing.
if ((this.options.pauseOnHover || this.options.fullControlPanel) &&
this.entries.length > 0) {
this.container.onmouseover = this.bind(this.mouseOver);
this.container.onmouseout = this.bind(this.mouseOut);
}
if (this.options.imageClickCallback) {
this.container.onclick = this.bind(this.pauseAndCallout);
}
// Seed with first image and quick timeout for next chunk.
this.processThumbs(1, 100+(Math.random()*100));
};
/**
* Callback asscoiated with an image load.
* @param {Element} image Image instance that was loaded.
* @private
*/
GFslideShow.prototype.imageLoaded = function(image) {
image.__gfloaded = true;
this.adjustImage(image);
// Once the first image is loaded, begin the slideshow..
if (!this.started) {
for (var i = 0; i < this.images.length; i++) {
if (image == this.images[i]) {
this.beginSlideShow(i);
}
break;
}
}
};
/**
* Callback asscoiated with an image load error.
* @param {Element} image Image instance that was loaded.
* @private
*/
GFslideShow.prototype.imageError = function(image) {
image.__gferror = true;
};
/**
* Adjust the image to the container after load. Will scale and center.
* @param {Element} image Image instance that needs adjusting.
* @private
*/
GFslideShow.prototype.adjustImage = function(image) {
// Scale if requested.
if (this.options.scaleImages) {
if (this.options.maintainAspectRatio) {
this.scaleImage(image);
} else {
image.style.height = this.height + "px";
image.style.width = this.width + "px";
}
}
// Center the image.
this.centerImage(image);
};
/**
* Scale the image appropriately to fit in the container.
* @param {Element} image Image instance that needs scaling.
* @private
*/
PHP:
GFslideShow.prototype.scaleImage = function(image, opt_width, opt_height) {
// These change when the first one is set, so we need to remember them.
var width = opt_width || this.width;
var height = opt_height || this.height;
var imgW = image.offsetWidth;
var imgH = image.offsetHeight;
if (imgW <= 0 || imgH <= 0) return;
var scaleH = height / imgH;
var scaleW = width / imgW;
if (scaleH < scaleW) {
image.style.height = height + "px";
image.style.width = Math.round(imgW * scaleH) + "px";
} else {
image.style.width = width + "px";
image.style.height = Math.round(imgH * scaleW) + "px";
}
};
/**
* Center the image appropriately within the container.
* @param {Element} image Image instance.
* @private
*/
GFslideShow.prototype.centerImage = function(image) {
var oh = this.height - image.offsetHeight;
var ow = this.width - image.offsetWidth;
// Don't assume these are zero..
image.style.top = "0px";
image.style.left = "0px";
// center the image
if (oh > 0) {
var ah = Math.round(oh/2);
image.style.top = image.offsetTop + ah +
this.options.centerBias.topBias + "px";
}
if (ow > 0) {
var aw = Math.round(ow/2);
image.style.left = image.offsetLeft + aw +
this.options.centerBias.leftBias + "px";
}
};
/**
* Create a link element.
* @param {String} href Href attribute for the element.
* @return {Element} Link element.
* @private
*/
GFslideShow.prototype.createLink = function(href) {
var link = document.createElement('a');
link.setAttribute('href', href);
if (this.options.linkTarget) {
link.setAttribute('target', this.options.linkTarget);
}
return link;
};
/**
* Create an image element.
* @param {String} src Source attribute for the image element.
* @private
*/
GFslideShow.prototype.createImage = function(src) {
var image = document.createElement("img");
image.style.position = "absolute";
image.setAttribute("src", src);
this.setOpacity(image, 0);
return image;
};
/**
* Properly adjust the pause image if need be.
* @param {Element} image Image representing pause state.
* @private
*/
GFslideShow.prototype.adjustPauseImage = function(image) {
if (this.options.scalePauseImage) {
var height = Math.round(this.height * 0.33);
var width = Math.round(this.width * 0.33);
this.scaleImage(image, width, height);
}
this.placePauseImage(image);
};
/**
* Properly place the pause image for overlay on a pause state.
* @param {Element} image Image representing pause state.
* @private
*/
GFslideShow.prototype.placePauseImage = function(image) {
var oh = this.height - image.offsetHeight;
var ow = this.width - image.offsetWidth;
// Don't assume these are zero..
image.style.top = "0px";
image.style.left = "0px";
// center the image
if (oh > 0) {
var off = Math.round(this.height * 0.10);
if (off < 15) off = 10;
var ah = this.height - (image.offsetHeight + off);
if (ah < 0) ah = 0;
image.style.top = image.offsetTop + ah +
this.options.pauseCenterBias.topBias + "px";
}
if (ow > 0) {
var aw = Math.round(ow/2);
image.style.left = image.offsetLeft + aw +
this.options.pauseCenterBias.leftBias + "px";
}
};
/**
* Properly create the alpha transparent version of the pause image.
* @param {Element} image Image representing pause state.
* @private
*/
GFslideShow.prototype.createAlphaPauseImage = function(image) {
// Work with offscreen version first to get the correct sizes and offsets..
this.adjustPauseImage(image);
var imgW = image.offsetWidth;
var imgH = image.offsetHeight;
var imgT = image.style.top;
var imgL = image.style.left;
// Now create real one.
var element = null;
if (this.ie) {
var src = this.options.pauseImage;
element = document.createElement("div");
element.style.filter = "progid:DXImageTransform.Microsoft." +
"AlphaImageLoader(src='" + src + "', sizingMethod='scale')";
element.style.position = "absolute";
element.style.width = imgW + "px";
element.style.height = imgH + "px";
element.style.left = imgL;
element.style.top = imgT;
} else {
element = image;
element.style.opacity = "";
}
element.style.visibility = "hidden";
element.style.zIndex = 222;
if (element != image) {
this.container.appendChild(element);
this.container.removeChild(image);
}
this.pauseImage = element;
};
/**
* Callback asscoiated with the pause image load.
* @param {Element} image Pause image instance that was loaded.
* @private
*/
GFslideShow.prototype.pauseImageLoaded = function(image) {
this.createAlphaPauseImage(image);
};
/**
* Create the pause image element.
* @param {String} src Source attribute for the pause image element.
* @private
*/
GFslideShow.prototype.createPauseImage = function(src) {
if (!this.options.pauseOnHover) return;
var pauseOff = this.createImage(this.options.pauseImage);
this.container.appendChild(pauseOff);
if (pauseOff.complete) {
this.createAlphaPauseImage(pauseOff);
} else {
pauseOff.onload = this.bind(this.pauseImageLoaded, pauseOff);
}
};
/**
* Create the fullControlPanel setup.
* @private
*/
GFslideShow.prototype.createFullControlPanel = function() {
var h = (this.options.fullControlPanelSmallIcons?25:45);
if (this.options.fullControlPanelCursor) h += 10;
var padTop = (this.options.fullControlPanelSmallIcons?5:10);
var padBottom = 5;
var div = document.createElement('div');
div.style.backgroundColor = '#000000';
div.style.height = h + 'px';
div.style.top = (this.height - (h+padBottom+padTop)) + 'px';
div.style.width = '100%';
div.style.zIndex = '222';
div.style.position = 'relative';
div.style.textAlign = 'center';
div.style.direction = 'ltr';
div.style.paddingTop = padTop + 'px';
div.style.paddingBottom = padBottom + 'px';
var iconSize = this.options.fullControlPanelSmallIcons?'small':'big';
var handCursor = this.ie?'hand':'pointer';
var pause = document.createElement("img");
pause.src = GFslideShow.FC_PAUSE_PNG[iconSize];
pause.style.cursor = handCursor;
var next = document.createElement("img");
next.src = GFslideShow.FC_NEXT_PNG[iconSize];
next.style.cursor = handCursor;
var prev = document.createElement("img");
prev.src = GFslideShow.FC_PREV_PNG[iconSize];
prev.style.cursor = handCursor;
pause.style.marginLeft = '5px';
pause.style.marginRight = '5px';
div.appendChild(prev);
div.appendChild(pause);
div.appendChild(next);
var cursor = null;
if (this.options.fullControlPanelCursor) {
cursor = document.createElement('div');
cursor.style.height = '1.3em';
cursor.style.fontSize = '11px';
cursor.style.color = '#bbbbbb';
div.appendChild(cursor);
}
// Hold onto the ui elements..
this.fc = {};
this.fc.container = div;
this.fc.pause = pause;
this.fc.next = next;
this.fc.prev = prev;
this.fc.cursor = cursor;
next.onclick = this.bind(this.goForward);
prev.onclick = this.bind(this.goBackward);
pause.onclick = this.bind(this.pauseOrPlayClick);
this.fc.container.style.visibility = "hidden";
this.container.appendChild(div);
};
/**
* Clear the transition timer. Used to prevent leaks.
* @private
*/
GFslideShow.prototype.clearTransitionTimer = function() {
if (this.transition_timer) {
clearInterval(this.transition_timer);
this.transition_timer = null;
}
};
/**
* Sets the transition timer for fadeout.
* @private
*/
GFslideShow.prototype.setTransitionTimer = function() {
this.clearTransitionTimer();
this.lastTick = GFslideShow.timeNow();
var cb = this.bind(this.transitionAnimation);
this.transition_timer = window.setInterval(cb, this.options.transitionStep);
};
/**
* Clear the display timer. Used to prevent leaks.
* @private
*/
GFslideShow.prototype.clearDisplayTimer = function() {
if (this.display_timer) {
clearTimeout(this.display_timer);
this.display_timer = null;
}
};
/**
* Sets the display timer.
* @private
*/
GFslideShow.prototype.setDisplayTimer = function() {
if (this.display_timer) return;
var cb = this.bind(this.displayNextPhoto);
this.display_timer = window.setTimeout(cb, this.options.displayTime);
};
/**
* Clear the thumb timer. Used to prevent leaks.
* @private
*/
GFslideShow.prototype.clearThumbTimer = function() {
if (this.thumb_timer) {
clearTimeout(this.thumb_timer);
this.thumb_timer = null;
}
};
/**
* Displays the slideshow, starting at the corresponding index.
* @param {Number} index Index of image to start with.
* @private
*/
GFslideShow.prototype.beginSlideShow = function(index) {
this.photo_index = index;
this.next = this.images[this.photo_index];
this.snapToNextPhoto();
this.started = true;
};
/**
* Class helper method for the time now in milliseconds
* @private
*/
GFslideShow.timeNow = function() {
var d = new Date();
return d.getTime();
};
/**
* Move to the next photo.
*/
GFslideShow.prototype.goForward = function() {
this.finishTransition();
this.setNextPhoto();
this.snapToNextPhoto();
this.clearFullControlTimeoutTimer();
};
/**
* Move to the previous photo.
*/
GFslideShow.prototype.goBackward = function() {
this.finishTransition();
this.setPreviousPhoto();
this.snapToNextPhoto();
this.clearFullControlTimeoutTimer();
};
/**
* Goto the specified indexed photo.
*/
GFslideShow.prototype.gotoIndex = function(index) {
if (index == this.photo_index) {
return;
}
this.clearTransitionTimer();
this.setPhotoIndex(index);
this.snapToNextPhoto();
this.clearFullControlTimeoutTimer();
}
/**
* Handle mouse clicks on the pause or play button.
*/
GFslideShow.prototype.pauseOrPlayClick = function() {
// Trap a play click if we have a callout registered.
if (this.options.fullControlPanelPlayCallback && this.display_paused) {
// for some reason a mouseout happens
// when we click and swap divs...
this.container.onmouseover = null;
this.container.onmouseout = null;
this.options.fullControlPanelPlayCallback(this.entries[this.photo_index]);
this.fadeOutFullControl();
} else {
this.pauseOrPlayFullControl();
}
}
/**
* Toggle Pause or Play in FullControl Mode.
*/
GFslideShow.prototype.pauseOrPlayFullControl = function() {
// todo, pause callout?
var iconSize = this.options.fullControlPanelSmallIcons?'small':'big';
if (this.display_paused) {
this.display_paused = false;
this.fc.pause.src = GFslideShow.FC_PAUSE_PNG[iconSize];
if (this.display_timer == null && this.transition_timer == null) {
// restart.
this.displayNextPhoto();
}
} else {
this.display_paused = true;
this.fc.pause.src = GFslideShow.FC_PLAY_PNG[iconSize];
}
};
/**
* monitors mouse motion inside the container while fullcontrol panel is
* active.
* @private
*/
GFslideShow.prototype.fullControlMotion = function() {
var op = this.fc.container.opacity;
if (op < GFslideShow.DEFAULT_FC_OPACITY) {
this.container.onmousemove = null;
this.clearFullControlTimeoutTimer();
this.fadeInFullControl();
} else {
this.setFullControlTimeoutTimer();
}
}
/**
* Clears the timeout timer itself.
* @private
*/
GFslideShow.prototype.clearFullControlTimeoutTimer = function() {
if (!this.fc) {
return;
}
if (this.fc.timeout) {
clearTimeout(this.fc.timeout);
this.fc.timeout = null;
}
}
/**
* Set up the timeout timer itself.
* @private
*/
GFslideShow.prototype.setFullControlTimeoutTimer = function() {
if (this.fc.timeout) {
clearTimeout(this.fc.timeout);
this.fc.timeout = null;
}
if (this.options.fullControlPanelFadeOutTime > 0) {
var cb = this.bind(this.fadeOutFullControl);
this.fc.timeout = setTimeout(cb, this.options.fullControlPanelFadeOutTime);
}
}
/**
* Set up a timeout to fadeout the control if no mouse activity.
* @private
*/
GFslideShow.prototype.setFullControlTimeout = function() {
this.container.onmousemove = this.bind(this.fullControlMotion);
this.setFullControlTimeoutTimer();
}
/**
* Begin fading in of the FullControl.
*/
GFslideShow.prototype.fadeInFullControl = function() {
this.setOpacity(this.fc.container, 0);
var cb = this.bind(this.fadeInFullControlAnimation);
this.setFullControlFadeTimer(cb);
}
/**
* Fade in animation for the FullControl
*/
GFslideShow.prototype.fadeInFullControlAnimation = function() {
var op = this.fc.container.opacity;
op += 0.075; // Approximation
op = Math.min(GFslideShow.DEFAULT_FC_OPACITY, op);
this.setOpacity(this.fc.container, op);
if (op >= GFslideShow.DEFAULT_FC_OPACITY) {
this.setFullControlFadeTimer();
this.setFullControlTimeout();
}
}
/**
* Begin fading out of the FullControl.
*/
GFslideShow.prototype.fadeOutFullControl = function() {
var cb = this.bind(this.fadeOutFullControlAnimation);
this.setFullControlFadeTimer(cb);
}
/**
* Fade out animation for the FullControl
*/
GFslideShow.prototype.fadeOutFullControlAnimation = function() {
var op = this.fc.container.opacity;
op -= 0.075;
this.setOpacity(this.fc.container, op);
if (op <= 0) {
this.setFullControlFadeTimer();
}
}
/**
* Set the fade timer, clearing previous ones.
* @param {Object} opt_callback function/method to bind timer to.
* @private
*/
GFslideShow.prototype.setFullControlFadeTimer = function(opt_callback) {
if (this.fc.fade_timer) {
clearInterval(this.fc.fade_timer);
this.fc.fade_timer = null;
}
if (opt_callback) {
this.fc.fade_timer = window.setInterval(opt_callback, 40);
}
}
/**
* Transition animation to next photo. Cleanup when finished.
* @private
*/
GFslideShow.prototype.transitionAnimation = function() {
if (this.current && this.next) {
var delta = this.delta;
var ts = this.options.transitionStep;
var now = GFslideShow.timeNow();
var tick = now - this.lastTick;
this.lastTick = now;
delta *= (tick/ts);
if (delta < 0) return;
var cur_op = this.current.opacity - delta;
var next_op = this.next.opacity + delta;
this.setOpacity(this.current, cur_op);
this.setOpacity(this.next, next_op);
if (this.options.transitionAnimationCallback) {
this.options.transitionAnimationCallback(this.next.opacity);
}
PHP:
// Still more to go?
if (cur_op > 0) {
return;
}
}
// Finished transition.
this.finishTransition();
};
/**
* Select the next photo to display. This takes into account different load
* times for images and bad links, etc.
* @private
*/
GFslideShow.prototype.setNextPhoto = function() {
if (this.images.length == 0) {
return;
}
var ci = this.photo_index;
var done = false;
while (!done) {
// wrap
if (++this.photo_index >= this.images.length) {
this.photo_index = 0;
}
var image = this.images[this.photo_index];
if (image && image.__gfloaded) {
this.next = image;
done = true;
} else {
// Image not loaded for some reason, skip it. But don't loop forever.
if (this.photo_index == ci) {
this.next = this.images[0];
done = true;
}
}
}
};
/**
* Select the previous photo to display. This takes into account different load
* times for images and bad links, etc.
* @private
*/
GFslideShow.prototype.setPreviousPhoto = function() {
var ci = this.photo_index;
var done = false;
while (!done && this.images.length != 0) {
if (--this.photo_index < 0) {
this.photo_index = this.images.length-1;
}
var image = this.images[this.photo_index];
if (image && image.__gfloaded) {
this.next = image;
done = true;
} else {
// Image not loaded for some reason, skip it. But don't loop forever.
if (this.photo_index == ci) {
this.next = this.images[0];
done = true;
}
}
}
};
/**
* Select the photo index to display.
* @private
*/
GFslideShow.prototype.setPhotoIndex = function(index) {
if (index < 0 || index >= this.images.length) {
return;
}
var image = this.images[index];
if (image && image.__gfloaded) {
this.next = image;
this.photo_index = index;
}
};
/**
* Clears the pause events, prevents leaks.
* @private
*/
GFslideShow.prototype.clearPauseEvents = function() {
this.container.onmouseover = null;
this.container.onmouseout = null;
};
/**
* Cleanup when we notice we have been removed or replaced. Try to be
* as GC friendly as possible.
* @private
*/
GFslideShow.prototype.cleanup = function() {
// Try to be gc friendly.
this.clearTransitionTimer();
this.clearDisplayTimer();
this.clearThumbTimer();
this.clearPauseEvents();
this.clearNode(this.container);
this.container = null;
};
/**
* Display the next appropriate photo if we can. Also determine if we
* need to start transition animation if applicable.
* @private
*/
GFslideShow.prototype.displayNextPhoto = function() {
this.display_timer = null;
if (!this.started) {
return false;
}
// Just return if we are in a paused state.
if (this.display_paused) return;
// See if we have been orphaned and cleanup if needed.
if ((!this.container || !this.container.parentNode) &&
this.options.autoCleanup) {
this.cleanup();
return;
}
this.setNextPhoto();
this.beginTransition();
};
/**
* Helper method to snap to next photo
* @private
*/
GFslideShow.prototype.snapToNextPhoto = function() {
this.setOpacity(this.next, 1);
this.setOpacity(this.current, 0);
this.current = this.next;
this.setDisplayTimer();
if (this.options.transitionCallback) {
this.options.transitionCallback(this.entries[this.photo_index],
this.options.transitionTime);
}
if (this.options.fullControlPanel && this.options.fullControlPanelCursor) {
var index = (this.photo_index+1) + ' / ' + this.images.length;
this.fc.cursor.innerHTML = index;
}
}
/**
* Helper method to start transition to next selected photo.
* Takes into account transition parameters.
* @private
*/
GFslideShow.prototype.beginTransition = function() {
if (!this.current || !this.next || (this.current == this.next)) {
// Skip if we are missing something or trying to transition to
// ourselves.
this.setDisplayTimer();
return;
}
if (this.options.transitionTime >= this.options.transitionStep) {
this.setTransitionTimer();
} else {
this.snapToNextPhoto();
}
};
/**
* Helper method to finish the transition to next selected photo.
* @private
*/
GFslideShow.prototype.finishTransition = function() {
this.clearTransitionTimer();
this.snapToNextPhoto();
};
/**
* Helper method to set opacity for images.. Also takes into account
* visibility in general.
* @param {Element} image Image element.
* @param {Number} opacity alpha level.
* @private
*/
GFslideShow.prototype.setOpacity = function(image, opacity) {
if (image == null) return;
opacity = Math.max(0, Math.min(1, opacity));
if (opacity == 0) {
if (image.style.visibility != "hidden") {
image.style.visibility = "hidden";
}
} else {
if (image.style.visibility != "visible") {
image.style.visibility = "visible";
}
}
if (this.ie) image.style.filter = "alpha(opacity=" + opacity*100 + ")";
image.style.opacity = image.opacity = opacity;
};
HTML:
<title>Google AJAX Feed API - AJAX Slide Show Sample</title>
<script src="http://www.google.com/jsapi"
type="text/javascript"></script>
<script src="http://www.google.com/uds/solutions/slideshow/gfslideshow.js"
type="text/javascript"></script>
<style type="text/css">
.gss a img {border : none;}
.gss {
width: 288px;
height: 216px;
color: #dddddd;
background-color: #000000;
padding: 8px;
}
</style>
<script type="text/javascript">
function load() {
var samples = "http://dlc0421.googlepages.com/gfss.rss";
var options = {
displayTime: 2000,
transistionTime: 600,
linkTarget : google.feeds.LINK_TARGET_BLANK
};
new GFslideShow(samples, "slideshow", options);
}
google.load("feeds", "1");
google.setOnLoadCallback(load);
</script>
</head>
<body>
<div id="body">
<div class="gss" id="slideshow">Loading...</div>
</div>
</body>
</html>
</body>
</html>
