High Sierra Install Bricked My 4,1 That I had Flashed to 5,1

Discussion in 'Mac Pro' started by Plutonius, Sep 26, 2017.

  1. Plutonius macrumors 604

    Plutonius

    Joined:
    Feb 22, 2003
    Location:
    New Hampshire, USA
    #1
    My early 2009 Mac Pro that was running 10.12 for months without issues, bricked after trying to install 10.13 (I know, I was stupid to update).

    I downloaded High Sierra and the first thing it did in the installation is updated the flash.

    The update went ok and it rebooted fine.

    It then started a 40 minute installation and when I returned, the front panel LED was on, the fans were turning, but I have no power on the USB ports (keyboard / mouse) and nothing on the display. Cycling the power on gives me some noise from the optical drives but nothing else.

    Does anyone have any suggestions or am I'm SOL :(.

  2. brossow macrumors newbie

    brossow

    Joined:
    Dec 7, 2002
    #2
    Similar situation here. Firmware updated, rebooted for the OS upgrade, came back an hour later to find it going through a kernel panic/reboot cycle. Tried reinstalling via recovery and same thing. Now restoring a Time Machine backup to another drive, but this is scary and a bit nauseating.

    Can the firmware be downgraded?

  3. Plutonius thread starter macrumors 604

    Plutonius

    Joined:
    Feb 22, 2003
    Location:
    New Hampshire, USA
    #3
    Is there anything I can do since I have no keyboard / mouse or display now (i.e. I have a time machine backup but the Mac Pro seems to be bricked)

    If you have a 4,1 Mac Pro flashed to a 5,1 , don't upgrade to high sierra.

  4. Squuiid macrumors 65816

    Squuiid

    Joined:
    Oct 31, 2006
    #4
    I upgraded my 4,1 flashed to 5,1 to High Sierra and had zero problems.
    Upgrade worked perfectly. If it makes any difference I have a single SM951 SSD in it.

  5. Plutonius thread starter macrumors 604

    Plutonius

    Joined:
    Feb 22, 2003
    Location:
    New Hampshire, USA
    #5
    Any idea what's happening to mine (no USB / Display). Is part of the installer in the flash update (corrupted) ?

    I think that it should show life with the hard drives removed ?

  6. Squuiid macrumors 65816

    Squuiid

    Joined:
    Oct 31, 2006
    #6
    Remove all PCIe cards except video card.
    If you have a Mac EFI video card put that in instead.
    Then see if the Mac posts.

  7. Plutonius thread starter macrumors 604

    Plutonius

    Joined:
    Feb 22, 2003
    Location:
    New Hampshire, USA
    #7
    Thank you for the suggestions.

    The only PCIe card I have is the video card and it's the sapphire mac version. Just in case, I put the original Radeon video card back in but no difference. Still no keyboard / mouse (USB) or display (i.e. will not boot).

    Do you have any other suggestions ?

    I'm not sure how to recover if it will not boot and the keyboard/mouse and display are not operational ?

  8. YZFNYC macrumors newbie

    YZFNYC

    Joined:
    Oct 5, 2015
    #8
    If you have a dual processor Mac Pro remove one processor boot it with the one. Fans will go full blast but should boot fine. Shutdown and reinstall 2nd processor. Don't forget thermal paste etc. and you should boot up fine. I've used it when all else fails. Worked every time.

  9. macirion macrumors newbie

    Joined:
    Oct 13, 2016
    Location:
    Sun City, AZ
    #9
    --- Post Merged, Sep 26, 2017 ---

    It will work

  10. fastlanephil macrumors 65816

    fastlanephil

    Joined:
    Nov 17, 2007
    #10
    If I do eventually upgrade my 2009 5,1 to High Sierra I’ll be making a bootable FW external HD using Carbon Copy Cloner first.

  11. PowerMac G4 MDD macrumors 68000

    PowerMac G4 MDD

    Joined:
    Jul 13, 2014
    Location:
    At the intersection of Conch and Coral.
    #11
    We

    I am curious if you were able to end up booting properly from another disk. I'm scared that this happens with my own 4,1 [flashed to 5,1].
    --- Post Merged, Sep 26, 2017 ---
    So, I suppose this entails a bricking of the existing boot disk and not a bricking of the machine itself? If so, I should be able to handle it fine. I've had Windows override my entire boot manager, forcing me to restore my main Mac boot disk from a backup of mine which - thank God - hadn't been affected. If the same happens with High Sierra, I can easily do just that.

  12. Synchro3 macrumors 68000

    Synchro3

    Joined:
    Jan 12, 2014
    #12
    No problems here with a Mac Pro 4,1 (flashed to 5,1). Installed it on a Apple PCI-E SSD. Drive is now APFS formatted.


  13. h9826790 macrumors G5

    h9826790

    Joined:
    Apr 3, 2014
    Location:
    Hong Kong
    #13
    Do you plug your keyboard / mouse directly to the front USB 2.0 port of the cMP?

    Did you try a SMC reset?

    As long as you can hear the "don" sound during boot, the firmware is fine.

  14. border terrier macrumors regular

    Joined:
    Feb 6, 2013
    Location:
    England
    #14
    My update went fine too, 2009 4.1 flashed to 5.1 running an internal bay mounted SSD. I reinstalled Sierra first plus did a load of maintenance and updated all the apps that needed updating before the update but then I typically do that before all major updates anyway.

  15. mikeboss macrumors 65816

    mikeboss

    Joined:
    Aug 13, 2009
    Location:
    switzerland
  16. Plutonius thread starter macrumors 604

    Plutonius

    Joined:
    Feb 22, 2003
    Location:
    New Hampshire, USA
    #16
    It has a single processor.

    No difference plugging in the mouse / keyboard in front. No power out of the front USB connector.

    No "don" sound coming out of the computer either. I press the power button and the front LED comes on, the fans turn, and I hear the optical drive spin up (i.e. power but no boot up at all) .

    I followed Apple's instructions on a SMC reset for the Mac Pro, it had no effect.
    1. Shut down the computer.
    2. Unplug the computer’s power cord.
    3. Wait fifteen seconds.
    4. Attach the computer’s power cord.
    5. Wait five seconds, then press the power button to turn on the computer.
    Looking at the instructions for the firmware restoration cd, I just get lots of fast blinking before it turns solid, no sound, and the tray does not open.

    Turn on the computer and continue holding the Power button. The sleep LED will blink rapidly, then slowly, then rapidly (3 quick blinks, 3 slow blinks, 3 quick blinks).

    On Macs that don't have a sleep LED, tones are used instead. Hold down the power button until you hear 3 long tones, then 3 short tones, then 3 long tones.

    On Macs that use a tray-load optical drive, the tray will open to allow the Restoration CD to be inserted.

  17. Theophany macrumors 6502a

    Theophany

    Joined:
    Nov 16, 2008
    Location:
    NW London.
    #17
    I know this isn't helpful, but Apple's attention to detail is incredible. The LED/tones replicate 'SOS' in morse code, which is basically what your machine is saying when it needs a firmware restore.

  18. brossow macrumors newbie

    brossow

    Joined:
    Dec 7, 2002
    #18
    UPDATE: The Time Machine restore (to another drive) worked, so at least I'm up and running again. Going to hold off on trying HS again, at least until I can figure out what's going on. At least the fw update didn't completely bork my system. Fingers crossed for OP, who seems to be far worse off.

  19. Ubernostrum macrumors newbie

    Joined:
    Sep 28, 2017
    #19
    Plutonius,

    I’m seeing the same thing you are only I’m running a MP 2012 5,1 system already. I have upgraded the processors from a 2.4 to 3.3ghz, but I’ve been running that setup just fine for over 3 years.

    Tried all the tricks but when I hold the power button all I get is rapid blinking then solid. Tried taking out one processor to no avail. I’m taking mine in to an Apple Store today and I’ll let you know what they tell me.

    Wost case scenario I’ll have to get a used logic board and stay with Sierra.
