Indesign and TOC - Alignment Question

Discussion in 'Design and Graphics' started by kitki83, Dec 10, 2007.

  1. kitki83 macrumors 6502a

    Joined:
    Mar 31, 2004
    Location:
    Los Angeles
    #1
    [​IMG]

    What I want to do is tell TOC options to place the page number to the edge of the text box. Then TOC will just add the dots as many to fulfill the space between page title and page number.

    Thank you

  2. ac6789 macrumors member

    Joined:
    Jun 28, 2007
    #2
    You need to set your tabs and set the "Leader". To open up the tab palette, hit apple+shift+T or go to "Type" --> "Tabs"

    Set a tab to a right justified tab then on the ruler that you see in the Tab palette, position it where you need it. Put in your leader character in the approprate field and you're done.

    If you did this correctly, if you hit "tab" on your keyboard, the cursor should jump to the right side of the text box with a string of "." right behind it.


    Attached Files:

  3. tobefirst macrumors 68040

    tobefirst

    Joined:
    Jan 24, 2005
    Location:
    St. Louis, MO
    #3
    In the TOC dialog box, make sure that "More Options" are shown, and you want to place ^t in the "Between Entry and Number" box. Then you can specify a stylesheet that has the type of tabs ac6789 is talking about, or adjusting the kind of tabs and leaders after creating the table of contents, if you'd rather.

    INSIDE the TOC dialog box, however, make sure you have the ^t, which inserts the tab needed to make this work.

  4. kitki83 thread starter macrumors 6502a

    Joined:
    Mar 31, 2004
    Location:
    Los Angeles
