iPhone 6 Plus has a virtual resolution larger than 1080p

Discussion in 'iPhone' started by tonyunreal, Sep 10, 2014.

  1. tonyunreal, Sep 10, 2014
    Last edited: Sep 10, 2014

    tonyunreal macrumors regular

    tonyunreal

    Joined:
    Feb 25, 2010
    #1
    UPDATE :

    On a second thought, it makes sense for Apple to use a virtual resolution and scale it down on the physical screen, just like we could use a 3840 x 2400 desktop on a MacBook Pro with Retina display. Bye-bye pixel perfect.

    Also thanks WorldTravelBro below for point that out, I changed the title a bit to better reflect the situation.

    ORIGINAL POST :

    Hi guys, I'm an app developer, earlier today I was messing around with the GM version of Xcode 6.0 (the tool that we use to developer apps for iOS), I think I found something that is interesting, that the actual resolution of the upcoming iPhone 6 Plus may not be 1080p as Apple has claimed, instead it should be 2208x1242 just like the previous leaks reported.

    Here's a screenshot of the iPhone 6 Plus home screen from the iOS simulator for developers, as you can see the resolution is 2208x1242.

    http://i900.photobucket.com/albums/ac203/tonyunreal/6plus.png

    At first I thought, oh no big deal, they just forgot to update the simulator to the real resolution. But wait, its actually not that hard to tell whether its real or not, we just need to look at the size of the user interface and spaces between icons.

    When the iPhone 4 with Retina display came out, Apple made it easier for our developers by letting our apps (and theirs) utilize the same user interface size on the new screens, only scaled up by 2x, this resulted in the same experience of the user interface across different devices. It was 320 points by 480 points at the moment, then extended to 320p by 568p on the iPhone 5/5c/5s.

    The iPhone 6 will have a user interface of 375p by 667p, scaled 2x to the real resolution of the physical screen. However IF the iPhone 6 Plus is 1080p as Apple claimed, it should have a user interface of 360p by 640p, thus resulting in a slightly "smaller" user interface size than the iPhone 6, and their should be less spaces between icons.

    As you can see from the media hands-on photos, that is not the case:

    [​IMG]

    In these photos The iPhone 6 Plus actually show significantly bigger user interface size than the smaller iPhone 6, and there are more spaces between the icons. In fact the scale of user interface in these photos matches the behavior of the iOS simulator for developer. Thus I believe it was a false claim from Apple that the iPhone 6 Plus has a 1080p display, the screen is, in fact, 2208 pixels by 1242 pixels, or some would say, slightly above 2K.

    More screenshots from the simulator:

    http://i900.photobucket.com/albums/ac203/tonyunreal/6plus1.png
    http://i900.photobucket.com/albums/ac203/tonyunreal/6plus2.png

  2. WorldTravelBro macrumors member

    Joined:
    Nov 29, 2012
    #2
    The iPhone 6+ renders internally using @3x assets at a virtual resolution of 2208×1242 (with 736x414 points), then samples that down for display. The same as using a scaled resolution on a Retina MacBook — it lets them hit an integral multiple for pixel assets while still having e.g. 12pt text look the same size on the screen.

    So, yes, the launch screens need to be that size.

    The maths:

    The 6, the 5s, the 5, the 4s and the 4 are all 326 pixels per inch, and use @2x assets to stick to the approximately 160 points per inch of all previous devices.

    The 6+ is 401 pixels per inch. So it'd hypothetically need roughly @2.46x assets. Instead Apple uses @3x assets and scales the complete output down to about 84% of its natural size.

    In practice Apple has decided to go with more like 87%, turning the 1080 into 1242. No doubt that was to find something as close as possible to 84% that still produced integral sizes in both directions — 1242/1080 = 2208/1920 exactly, whereas if you'd turned the 1080 into, say, 1286, you'd somehow need to render 2286.22 pixels vertically to scale well.


    On Apple.com the display resolutions are given 1080 x 1920 and 750 x 1334 which is different from the simulator results above. Here is the code I used to check this out:

    Code:
    // Get available screens
    NSArray *screenArray = [UIScreen screens];

    for (UIScreen *screenObject in screenArray){
        NSLog(@"Screen availableModes: %@, scale: %f, nativeScale: %f, coordinateSpace: %@, Screen bounds: %@, ApplicationFrame: %@",
             screenObject.availableModes, screenObject.scale, screenObject.nativeScale, screenObject.coordinateSpace,
             NSStringFromCGRect(screenObject.bounds), NSStringFromCGRect(screenObject.applicationFrame));
    }

  3. sr1329 macrumors member

    Joined:
    Apr 1, 2009
    #3
    If true no complaints here. But why would they announce 1080p?

  4. nnacrumors macrumors 6502

    Joined:
    Jun 12, 2014
    #4
    Class! Action! Lawsuit!
    Class! Action! Lawsuit!
    Class! Action! Lawsuit!

    [​IMG]

    :p

  5. tonyunreal thread starter macrumors regular

    tonyunreal

    Joined:
    Feb 25, 2010
    #5
    Thank you WorldTravelBro, I believe you're right, that Apple is downscaling to 1080p on the user size. I've updated the original post.

    So instead of continuing to provide pixel perfect solutions for us developers, Apple did this to maintain virtually the same size of UI elements (like buttons and icons) across screen sizes, understandable but still seems a bit unnecessary to me. I would rather have a 360p @3x UI size, much easier to design UIs around it, not to mention super easy to port between iOS and Android (since most Android phones are virtually 360p by 640p).

  6. citivolus macrumors 6502a

    Joined:
    Sep 19, 2008
    #6
    If this is true, would remote desktop apps like Splashtop be able to take advantage of this and display resolutions greater than 1920x1080?
