Mac mini 2011 - 3 beeps

Discussion in 'Mac mini' started by sgiera, May 16, 2015.

  1. sgiera macrumors member

    Joined:
    Mar 25, 2014
    #1
    i have upgraded my Mac mini 2011 with the correct ram type with (8gigs total, 4gigs per stick.). When I turn it on, I get 3 beeps. When i only put in the top slot, I get 1 beep. When I put it in the lower slot, I get 3 beeps. Is the memory I bought bad or are the ram slots bad?

  2. MagicBoy macrumors 68040

    MagicBoy

    Joined:
    May 28, 2006
    Location:
    Manchester, UK
    #2
    Does the original Apple memory still work?

    If so, there's your answer.

  3. sgiera thread starter macrumors member

    Joined:
    Mar 25, 2014
    #3
    This was a logic board I received off hand and this is the first time I have tried to power it on.

    ----------

    Went to microcenter and got the crucial ram for mac

  4. MagicBoy macrumors 68040

    MagicBoy

    Joined:
    May 28, 2006
    Location:
    Manchester, UK
    #4
    Here's the article decoding the beep codes at POST : https://support.apple.com/en-gb/ht1547

    Assuming you purchased the correct type of memory ... without another set of memory or another Mac to test the memory in it's guesswork at this stage.

  5. sgiera thread starter macrumors member

    Joined:
    Mar 25, 2014
    #5
    3 beeps = no good banks. What does no good banks? Rom slots?

  6. MagicBoy macrumors 68040

    MagicBoy

    Joined:
    May 28, 2006
    Location:
    Manchester, UK
    #6
    Banks of memory. Could the be the RAM, could be the CPU or Logic board.

  7. gixxerfool macrumors 6502a

    gixxerfool

    Joined:
    Jun 7, 2008
    #7
    Is the ram installed all the way? Seems simple but easy to miss.

  8. Fishrrman macrumors G3

    Joined:
    Feb 20, 2009
    #8
    Process of elimination is in order.

    Try this, step-by-step.

    Take both RAM modules out.

    Reinstall module 1 into the lower bank.
    Boot.
    What happens?

    Move module 1 into the upper bank.
    Boot.
    What happens?

    Remove module 1 and install module 2 into lower bank.
    Boot.
    What happens?

    Move module 2 into the upper bank.
    Boot.
    What happens?

  9. sgiera thread starter macrumors member

    Joined:
    Mar 25, 2014
    #9
    Process of elimination is in order.

    Try this, step-by-step.

    Take both RAM modules out.

    Reinstall module 1 into the lower bank.
    Boot.
    What happens? 1 beep

    Move module 1 into the upper bank.
    Boot.
    What happens? 3 beep

    Remove module 1 and install module 2 into lower bank.
    Boot.
    What happens? 1 beep

    Move module 2 into the upper bank.
    Boot.
    What happens? 3 beep
