Mac Pro 4,1 to 5,1 upgrade... New CPU causing kernel panic

C. Alan

macrumors 6502
Original poster
Jan 23, 2009
309
5
Ok, so I am trying to upgrade my early 2009 Mac Pro that came with 2.66 quad core to a 5,1 with a 3.46 hex core processor.

I have downloaded and upgraded the EFI to a 5.1 and went ahead and installed the processor, and then went to boot it.

Now it won't boot in either 10.9 or 10.8, nor the recovery discs, and each time I try, I get the same kernel panic (see attached). Sorry for the huge picture, I'm working on my iphone here.

I'm about out of ideas how to get my mac up and running again. Any ideas?


Attachments


DPUser

macrumors 6502a
Jan 17, 2012
864
198
Rancho Bohemia, California
If all else fails, pull the new CPU, inspect the CPU socket carefully and if no damage is visible, reinstall old CPU. If everything works, check to be sure your Mac shows as a 5,1 (to be sure the EFI upgrade worked) and, if so, reinstall the new CPU. If it doesn't work, it may be bad.


crjackson2134

macrumors 601
Mar 6, 2013
4,497
1,626
Charlotte, NC
After you upgraded the firmware, did it boot normally with the old processor?

If it did, I would reinstall the old processor to verify the system.

EDIT: Looks like DPUser beet me to the punch.

Last edited:

C. Alan

macrumors 6502
Original poster
Jan 23, 2009
309
5
Well I did reinstall the old processor, and it did boot normally. I then put the new 3.46 hex core in it, and it still panics. However, it will boot in console mode. I can get into /var/log/, and browse the logs with VI, but I'm not sure what I am looking for yet. Being able to get into console mode is making me wonder if it a software issue, it maybe I should try a fresh install of mavericks.

Btw, if you look at my screenshot, it is identifying as a 5,1. Should I also check the firmware edition? I wonder if it logged somewhere, so I don't have to swap the processor again.


ScottishCaptain

macrumors 6502a
Oct 4, 2008
872
467
Your screenshot is truncating the most important bits to the right hand side. If you want to post the complete kernel panic, maybe someone can help you- otherwise, you might be able to google the machine check codes and figure out why the machine is panicking.

-SC


Korican100

macrumors 6502a
Oct 9, 2012
881
187
Maybe a bad CPU. if you purchased off ebay, take advantage of your buyer protection asap.

I did this upgrade, and followed the path of, 4,1 -> flashed to 5,1 -> installed new cpu. Boot and ta-da.
There should be no OSx conflicts, no software conflicts. If 4,1 worked, 5,1 should work without a hitch.

Make sure your ram is seated properly, gpu etc all that stuff. If that looks good, and your old cpu boots no problem. REturn that new CPU asap.


MacVidCards

Suspended
Nov 17, 2008
7,506
1,029
Hollywood, CA
I second Korican

Should work, if not likely a bad CPU

As this is single CPU machine, really no way to screw it up.

I would be 100% certain that all the little gold dots on bottom of CPU are clean


omvs

macrumors 6502
May 15, 2011
478
10
Slight possibility it could be the ram trying to do 1333 and failing?

Did you zap the PRAM after the install? If not, then it should be running the old speed, which would be safer. To be more sure, you could pull out all but one DIMM, try it, and if it fails, try another dimm. If still fails, its gotta be the CPU


keringalhi

macrumors newbie
Jul 22, 2014
2
0
you might be able to google the machine check codes and figure out why the machine is panicking.


666sheep

macrumors 68040
Dec 7, 2009
3,623
211
Poland
Check if hex CPU doesn't have any missing parts (micro resistors specifically).
If your machine boots with old CPU, then CPU socket is OK.
You may also reset PRAM to clear boot args, because it looks like your MP tries to boot from recovery partition.


C. Alan

macrumors 6502
Original poster
Jan 23, 2009
309
5
Im sending it back

Well after reseating the chip three times, and checking and cleaning the bottom, there is still no change in the behavior. From all reports, it should not be this hard. So I am sending the chip back. Hopefully I can get another 3.46 chip soon.

Im now using the machine again with the old 2.66 quad core processor in it again. For those who are curious, here is what the panic log looked like. From what I can tell from my Google Searches, the Machine Check error means the panic is hardware related. So it may very well be the chip.:

Code:
Anonymous UUID:       6029F6D5-2CB8-DEE8-5542-46FA969426AA

Mon Jul 21 19:50:57 2014
Machine-check capabilities: 0x0000000000001c09
 family: 6 model: 44 stepping: 2 microcode: 15
 signature: 0x206c2
 Intel(R) Xeon(R) CPU           W3690  @ 3.47GHz
 9 error-reporting banks
Processor 6: IA32_MCG_STATUS: 0x0000000000000004
 IA32_MC2_STATUS(0x409): 0xf602108000040150
 IA32_MC2_ADDR(0x40a):   0x00007fff8d6daa19
Processor 7: IA32_MCG_STATUS: 0x0000000000000004
 IA32_MC2_STATUS(0x409): 0xf602108000040150
 IA32_MC2_ADDR(0x40a):   0x00007fff8d6daa19
panic(cpu 11 caller 0xffffff800c8dcad9): "Machine Check at 0xffffff800c8e2881, registers:\n" "CR0: 0x000000008001003b, CR2: 0xffffff815e595000, CR3: 0x000000000f144000, CR4: 0x00000000000206e0\n" "RAX: 0x0000000000000000, RBX: 0x0000000000000025, RCX: 0x000000004a07ff6f, RDX: 0x0000000000000001\n" "RSP: 0xffffff818614bcf0, RBP: 0xffffff818614bcf0, RSI: 0x0000000000000002, RDI: 0x0000000000000250\n" "R8:  0x0000000000000000, R9:  0x000000000000000b, R10: 0xffffff8186140000, R11: 0x0000000000000200\n" "R12: 0x0000000000000003, R13: 0x7fffffffffffffff, R14: 0x0000000000000001, R15: 0xffffff7f8e73ec98\n" "RFL: 0x0000000000000006, RIP: 0xffffff800c8e2881, CS:  0x0000000000000008, SS:  0x0000000000000010\n" "Error code: 0x0000000000000000\n"@/SourceCache/xnu/xnu-2422.110.17/osfmk/i386/trap_native.c:168
Backtrace (CPU 11), Frame : Return Address
0xffffff817e6ade80 : 0xffffff800c822f79
0xffffff817e6adf00 : 0xffffff800c8dcad9
0xffffff817e6ae060 : 0xffffff800c8f3fef
0xffffff818614bcf0 : 0xffffff800c8e25f4
0xffffff818614bd10 : 0xffffff7f8e72089b
0xffffff818614bd40 : 0xffffff7f8e72094f
0xffffff818614bd80 : 0xffffff7f8e71a261
0xffffff818614be70 : 0xffffff7f8e7198d9
0xffffff818614bf30 : 0xffffff800c8ddb0c
0xffffff818614bf50 : 0xffffff800c83758a
0xffffff818614bf90 : 0xffffff800c8378d8
0xffffff818614bfb0 : 0xffffff800c8d7417
      Kernel Extensions in backtrace:
         com.apple.driver.AppleIntelCPUPowerManagement(217.92.1)[CF28958D-CA8A-3A79-911C-78217F5DDAF2]@0xffffff7f8e717000->0xffffff7f8e741fff

BSD process name corresponding to current thread: kernel_task

Mac OS version:
13E28

Kernel version:
Darwin Kernel Version 13.3.0: Tue Jun  3 21:27:35 PDT 2014; root:xnu-2422.110.17~1/RELEASE_X86_64
Kernel UUID: BBFADD17-672B-35A2-9B7F-E4B12213E4B8
Kernel slide:     0x000000000c600000
Kernel text base: 0xffffff800c800000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 4362246976
last loaded kext at 1013628771: com.apple.driver.AppleUSBHIDKeyboard	170.15 (addr 0xffffff7f8e78a000, size 16384)
loaded kexts:
com.apple.iokit.SCSITaskUserClient	3.6.6
com.apple.driver.AppleFileSystemDriver	3.0.1
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless	1.0.0d1
com.apple.AppleFSCompression.AppleFSCompressionTypeLZVN	1.0.0d1
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib	1.0.0d1
com.apple.BootCache	35
com.apple.driver.XsanFilter	404
com.apple.iokit.IOAHCIBlockStorage	2.6.0
com.apple.driver.AppleUSBHub	683.4.0
com.apple.driver.AppleFWOHCI	5.0.2
com.apple.driver.Intel82574L	2.6.2b1
com.apple.driver.AirPortBrcm43224	700.36.24
com.apple.driver.AppleAHCIPort	3.0.5
com.apple.driver.AppleUSBEHCI	660.4.0
com.apple.driver.AppleUSBUHCI	656.4.1
com.apple.driver.AppleRTC	2.0
com.apple.driver.AppleHPET	1.8
com.apple.driver.AppleACPIButtons	2.0
com.apple.driver.AppleSMBIOS	2.1
com.apple.driver.AppleACPIEC	2.0
com.apple.driver.AppleAPIC	1.7
com.apple.driver.AppleIntelCPUPowerManagementClient	217.92.1
com.apple.nke.applicationfirewall	153
com.apple.security.quarantine	3
com.apple.driver.AppleIntelCPUPowerManagement	217.92.1
com.apple.driver.AppleUSBHIDKeyboard	170.15
com.apple.driver.AppleHIDKeyboard	170.15
com.apple.iokit.IOUSBHIDDriver	660.4.0
com.apple.driver.AppleUSBMergeNub	650.4.0
com.apple.driver.AppleUSBComposite	656.4.1
com.apple.iokit.IOSCSIMultimediaCommandsDevice	3.6.6
com.apple.iokit.IOBDStorageFamily	1.7
com.apple.iokit.IODVDStorageFamily	1.7.1
com.apple.iokit.IOCDStorageFamily	1.7.1
com.apple.iokit.IOAHCISerialATAPI	2.6.1
com.apple.iokit.IOSCSIArchitectureModelFamily	3.6.6
com.apple.iokit.IOFireWireFamily	4.5.5
com.apple.iokit.IOUSBUserClient	660.4.2
com.apple.iokit.IO80211Family	640.36
com.apple.iokit.IONetworkingFamily	3.2
com.apple.iokit.IOAHCIFamily	2.6.5
com.apple.iokit.IOUSBFamily	683.4.0
com.apple.driver.AppleEFINVRAM	2.0
com.apple.driver.AppleEFIRuntime	2.0
com.apple.iokit.IOHIDFamily	2.0.0
com.apple.iokit.IOSMBusFamily	1.1
com.apple.security.sandbox	278.11.1
com.apple.kext.AppleMatch	1.0.0d1
com.apple.security.TMSafetyNet	7
com.apple.driver.AppleKeyStore	2
com.apple.driver.DiskImages	371.1
com.apple.iokit.IOStorageFamily	1.9
com.apple.iokit.IOReportFamily	23
com.apple.driver.AppleFDEKeyStore	28.30
com.apple.driver.AppleACPIPlatform	2.0
com.apple.iokit.IOPCIFamily	2.9
com.apple.iokit.IOACPIFamily	1.4
com.apple.kec.pthread	1
com.apple.kec.corecrypto	1.0

Last edited:

flowrider

macrumors 603
Nov 23, 2012
5,543
1,966
^^^^The OP is modifying a Single CPU Mac Pro 4,1. The lidless CPU problem only affects dual CPU 4,1 Mac Pros, not single CPU Models. The questions you are asking are not apropos to this thread.

Lou


mikeboss

macrumors 65816
Aug 13, 2009
1,274
451
switzerland
I also had bought a faulty Xeon a few months back (this was the first time ever that I had to deal with a defective CPU). same symptoms: OS X and Windows 7 crashed almost immediately while trying to boot. interesting thing was that Apple Service Diagnostics (or was it Apple Hardware Test? not sure anymore) did NOT show any errors at all! according to the log, only CPU-0 is tested, all other five cores were untested...


C. Alan

macrumors 6502
Original poster
Jan 23, 2009
309
5
Update: Its running again

Well, I went ahead and returned the processor last week, and I finally got around to ordering another W3690 yesterday. The vendor was local to me, so the new chip got delivered today. I dropped it in, and rebooted. The machine came up with no issues. So there was definitely an issue with the last chip I ordered.

Now my 2009 Mac Pro is happily humming along on a 3.46ghz Xeon W3690. I have also added a USB 3.0 card, and a PC version of the HD 7950. So I should be good for a couple of more years.


DPUser

macrumors 6502a
Jan 17, 2012
864
198
Rancho Bohemia, California
Well, I went ahead and returned the processor last week, and I finally got around to ordering another W3690 yesterday. The vendor was local to me, so the new chip got delivered today. I dropped it in, and rebooted. The machine came up with no issues. So there was definitely an issue with the last chip I ordered.

Now my 2009 Mac Pro is happily humming along on a 3.46ghz Xeon W3690. I have also added a USB 3.0 card, and a PC version of the HD 7950. So I should be good for a couple of more years.
Bravo!


C. Alan

macrumors 6502
Original poster
Jan 23, 2009
309
5
I just noticed that the OWC memory I purchased last year for this machine is now running at 1333Mhz. That was a pleasant surprise. I purchased it as 1066Mhz memory.


Max_Mustermann

macrumors newbie
Dec 15, 2017
4
2
Hello everyone,

i am new to this forum, but I have a question related to this topic.

I did the Firmware update on a 2009 mac pro. Afterwards everything was working fine so I changed to a 6-core X5690 CPU. Next I updated the ram and installed a USB 3.0 card and a NVMe SSD. To get the ssd working i installed a driver from mac vidcards. The problem I am having now is that the mac pro does not shut down properly. Near the end of the shutdown procedure there seems to be a kernal panic. I get the "your computer restarted because of a problem" message. The report says the following:

Code:
*** Panic Report ***
panic(cpu 6 caller 0xffffff80129ce6fa): Kernel trap at 0xffffff7f9419a984, type 14=page fault, registers:
CR0: 0x000000008001003b, CR2: 0x0000000000000000, CR3: 0x0000000016608000, CR4: 0x00000000000226e0
RAX: 0xffffff7f941a6aa8, RBX: 0xffffff804edcee00, RCX: 0x0000000001000000, RDX: 0xffffff804cda6b60
RSP: 0xffffff93fd65bf30, RBP: 0xffffff93fd65bf30, RSI: 0x00000000e0000310, RDI: 0x0000000000000000
R8: 0x0000000000000000, R9: 0xffffff804ee88f40, R10: 0x0000000000000001, R11: 0x0000006d3cf86983
R12: 0xffffff80604d5fc0, R13: 0x0000006d3cf87b04, R14: 0x00000000e0000310, R15: 0xffffff801302cec0
RFL: 0x0000000000010246, RIP: 0xffffff7f9419a984, CS: 0x0000000000000008, SS: 0x0000000000000010
Fault CR2: 0x0000000000000000, Error code: 0x0000000000000000, Fault CPU: 0x6, PL: 0

Backtrace (CPU 6), Frame : Return Address
0xffffff93fd65bbc0 : 0xffffff80128dab52
0xffffff93fd65bc40 : 0xffffff80129ce6fa
0xffffff93fd65be20 : 0xffffff80129ec563
0xffffff93fd65be40 : 0xffffff7f9419a984
0xffffff93fd65bf30 : 0xffffff7f94190559
0xffffff93fd65bf50 : 0xffffff8012f07154
0xffffff93fd65bf90 : 0xffffff8012f06eb8
0xffffff93fd65bfb0 : 0xffffff80129c9117
Kernel Extensions in backtrace:
com.apple.iokit.IONVMeFamily(1.2)[9468CCDF-AD0E-301C-8225-CDB081651AB8]@0xffffff7f9418e000->0xffffff7f941b0fff
dependency: com.apple.driver.AppleMobileFileIntegrity(1.0.5)[A1E91DE9-D69F-3E42-BDE8-4C4786993FE9]@0xffffff7f93643000
dependency: com.apple.iokit.IOPCIFamily(2.9)[5447B943-A94D-3BD4-A60F-98B24D19CE93]@0xffffff7f9312c000
dependency: com.apple.driver.AppleEFINVRAM(2.0)[DFA558FE-59F9-32AA-8C3A-82BD65ECC094]@0xffffff7f94184000
dependency: com.apple.iokit.IOStorageFamily(2.1)[DC1AAB7C-F417-3238-BB3F-2A5B84D67B90]@0xffffff7f9304c000
dependency: com.apple.iokit.IOReportFamily(31)[C89107EE-2DF2-3BC3-9F6D-3133D43ED7EF]@0xffffff7f94127000

BSD process name corresponding to current thread: kernel_task

Mac OS version:
15G1004

Kernel version:
Darwin Kernel Version 15.6.0: Mon Aug 29 20:21:34 PDT 2016; root:xnu-3248.60.11~1/RELEASE_X86_64
Kernel UUID: E349749B-3303-3DDF-959C-B5885A0E1F6E
Kernel slide: 0x0000000012600000
Kernel text base: 0xffffff8012800000
__HIB text base: 0xffffff8012700000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 469174429083
last loaded kext at 356777166374: com.apple.filesystems.msdosfs 1.10 (addr 0xffffff7f95e43000, size 69632)
last unloaded kext at 417404274625: com.apple.filesystems.msdosfs 1.10 (addr 0xffffff7f95e43000, size 61440)
loaded kexts:
de.rme-audio.driver.RMEFirefaceUSB 2.18
com.paceap.kext.pacesupport.snowleopard 5.9.1
com.MinnowStor.NVMeGeneric 1
com.apple.driver.AppleBluetoothMultitouch 90.3
com.apple.driver.AppleHWSensor 1.9.5d0
com.apple.driver.AppleTyMCEDriver 1.0.2d2
com.apple.driver.AGPM 110.22.0
com.apple.driver.AudioAUUC 1.70
com.apple.filesystems.autofs 3.0
com.apple.driver.AppleOSXWatchdog 1
com.apple.driver.AppleMikeyHIDDriver 124
com.apple.driver.AppleMikeyDriver 274.12
com.apple.driver.AppleHDA 274.12
com.apple.driver.pmtelemetry 1
com.apple.iokit.IOUserEthernet 1.0.1
com.apple.kext.AMDFramebuffer 1.4.2
com.apple.driver.AppleUpstreamUserClient 3.6.1
com.apple.driver.AppleMCCSControl 1.2.13
com.apple.iokit.IOBluetoothSerialManager 4.4.6f1
com.apple.AMDRadeonX3000 1.4.2
com.apple.GeForceTesla 10.0.0
com.apple.Dont_Steal_Mac_OS_X 7.0.0
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport 4.4.6f1
com.apple.driver.AppleHV 1
com.apple.driver.AppleLPC 3.1
com.apple.kext.AMD5000Controller 1.4.2
com.apple.driver.AppleIntelSlowAdaptiveClocking 4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin 1.0.0
com.apple.iokit.SCSITaskUserClient 3.7.7
com.apple.iokit.IOAHCIBlockStorage 2.8.5
com.apple.driver.AppleFWOHCI 5.5.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless 1.0.0d1
com.apple.driver.Intel82574L 2.7.0b1
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib 1.0.0
com.apple.BootCache 38
com.apple.driver.usb.AppleUSBEHCIPCI 1.0.1
com.apple.driver.AppleAHCIPort 3.1.8
com.apple.driver.usb.AppleUSBUHCIPCI 1.0.1
com.apple.driver.AppleRTC 2.0
com.apple.driver.AppleHPET 1.8
com.apple.driver.AppleACPIButtons 4.0
com.apple.driver.AppleSMBIOS 2.1
com.apple.driver.AppleACPIEC 4.0
com.apple.driver.AppleAPIC 1.7
com.apple.driver.AppleIntelCPUPowerManagementClient 218.0.0
com.apple.nke.applicationfirewall 163
com.apple.security.quarantine 3
com.apple.security.TMSafetyNet 8
com.apple.driver.AppleIntelCPUPowerManagement 218.0.0
com.apple.driver.IOBluetoothHIDDriver 4.4.6f1
com.apple.driver.AppleMultitouchDriver 304.12
com.apple.driver.AppleHIDTransport 5
com.apple.kext.triggers 1.0
com.apple.driver.DspFuncLib 274.12
com.apple.kext.OSvKernDSPLib 525
com.apple.iokit.IOSurface 108.2.3
com.apple.iokit.IOSerialFamily 11
com.apple.iokit.IOAcceleratorFamily2 205.11
com.apple.nvidia.classic.NVDANV50HalTesla 10.0.0
com.apple.nvidia.classic.NVDAResmanTesla 10.0.0
com.apple.driver.CoreCaptureResponder 1
com.apple.driver.corecapture 1.0.4
com.apple.driver.AppleSMBusController 1.0.14d1
com.apple.iokit.IONDRVSupport 2.4.1
com.apple.iokit.IOFireWireIP 2.2.6
com.apple.iokit.IOBluetoothHostControllerUSBTransport 4.4.6f1
com.apple.iokit.IOBluetoothFamily 4.4.6f1
com.apple.driver.AppleHDAController 274.12
com.apple.iokit.IOHDAFamily 274.12
com.apple.kext.AMDSupport 1.4.2
com.apple.AppleGraphicsDeviceControl 3.12.8
com.apple.iokit.IOGraphicsFamily 2.4.1
com.apple.driver.AppleSMBusPCI 1.0.14d1
com.apple.iokit.IOSlowAdaptiveClockingFamily 1.0.0
com.apple.driver.AppleSMC 3.1.9
com.apple.driver.IOPlatformPluginLegacy 1.0.0
com.apple.driver.IOPlatformPluginFamily 6.0.0d7
com.apple.driver.AppleHIDKeyboard 181
com.apple.driver.usb.IOUSBHostHIDDevice 1.0.1
com.apple.driver.AppleUSBAudio 303.3.1
com.apple.iokit.IOAudioFamily 204.4
com.apple.vecLib.kext 1.2.0
com.apple.iokit.IOSCSIBlockCommandsDevice 3.7.7
com.apple.iokit.IOUSBMassStorageDriver 1.0.0
com.apple.driver.usb.cdc 5.0.0
com.apple.driver.usb.networking 5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice 1.0.1
com.apple.driver.usb.AppleUSBHub 1.0.1
com.apple.iokit.IOSCSIMultimediaCommandsDevice 3.7.7
com.apple.iokit.IOBDStorageFamily 1.8
com.apple.iokit.IODVDStorageFamily 1.8
com.apple.iokit.IOCDStorageFamily 1.8
com.apple.iokit.IOAHCISerialATAPI 2.6.2
com.apple.iokit.IOSCSIArchitectureModelFamily 3.7.7
com.apple.iokit.IOFireWireFamily 4.6.1
com.apple.iokit.IONVMeFamily 1.2.0
com.apple.driver.usb.AppleUSBXHCIPCI 1.0.1
com.apple.driver.usb.AppleUSBXHCI 1.0.1
com.apple.iokit.IONetworkingFamily 3.2
com.apple.iokit.IOAHCIFamily 2.8.1
com.apple.driver.usb.AppleUSBUHCI 1.0.1
com.apple.driver.usb.AppleUSBEHCI 1.0.1
com.apple.iokit.IOUSBFamily 900.4.1
com.apple.iokit.IOUSBHostFamily 1.0.1
com.apple.driver.AppleUSBHostMergeProperties 1.0.1
com.apple.driver.AppleEFINVRAM 2.0
com.apple.driver.AppleEFIRuntime 2.0
com.apple.iokit.IOHIDFamily 2.0.0
com.apple.iokit.IOSMBusFamily 1.1
com.apple.security.sandbox 300.0
com.apple.kext.AppleMatch 1.0.0d1
com.apple.driver.AppleKeyStore 2
com.apple.driver.AppleMobileFileIntegrity 1.0.5
com.apple.driver.AppleCredentialManager 1.0
com.apple.driver.DiskImages 417.4
com.apple.iokit.IOStorageFamily 2.1
com.apple.iokit.IOReportFamily 31
com.apple.driver.AppleFDEKeyStore 28.30
com.apple.driver.AppleACPIPlatform 4.0
com.apple.iokit.IOPCIFamily 2.9
com.apple.iokit.IOACPIFamily 1.4
com.apple.kec.Libm 1
com.apple.kec.pthread 1
com.apple.kec.corecrypto 1.0
Model: MacPro5,1, BootROM MP51.007F.B03, 6 processors, 6-Core Intel Xeon, 3,46 GHz, 32 GB, SMC 1.39f5
Graphics: NVIDIA GeForce GT 120, NVIDIA GeForce GT 120, PCIe, 512 MB
Graphics: ATI Radeon HD 5770, ATI Radeon HD 5770, PCIe, 1024 MB
Memory Module: DIMM 1, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 2, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 3, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Memory Module: DIMM 4, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Bluetooth: Version 4.4.6f2, 3 services, 27 devices, 1 incoming serial ports
Network Service: Ethernet 2, Ethernet, en1
PCI Card: NVIDIA GeForce GT 120, Display Controller, Slot-2
PCI Card: ATI Radeon HD 5770, Display Controller, Slot-1
PCI Card: PXS4, USB eXtensible Host Controller, Slot-4
PCI Card: pci144d,a804, NVM Express Controller, Slot-3
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: WDC WD6400AAKS-41H2B0, 640,14 GB
Serial ATA Device: WDC WD1001FALS-41K1B0, 1 TB
USB Device: USB 2.0 Bus
USB Device: USB 2.0 Bus
USB Device: USB2.0 Hub
USB Device: Fireface UCX (23707810)
USB Device: USB Keystation 61es
USB Device: Keyboard Hub
USB Device: Apple Keyboard
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: BRCM2046 Hub
USB Device: Bluetooth USB Host Controller
USB Device: USB 3.0 Bus
USB Device: TransMemory
FireWire Device: built-in_hub, Up to 800 Mb/sec
Thunderbolt Bus:
Anonymous UUID:       934022AC-B384-4FC9-7572-934C1FAD76E7

Fri Dec 15 18:27:30 2017

*** Panic Report ***
panic(cpu 6 caller 0xffffff80129ce6fa): Kernel trap at 0xffffff7f9419a984, type 14=page fault, registers:
CR0: 0x000000008001003b, CR2: 0x0000000000000000, CR3: 0x0000000016608000, CR4: 0x00000000000226e0
RAX: 0xffffff7f941a6aa8, RBX: 0xffffff804edcee00, RCX: 0x0000000001000000, RDX: 0xffffff804cda6b60
RSP: 0xffffff93fd65bf30, RBP: 0xffffff93fd65bf30, RSI: 0x00000000e0000310, RDI: 0x0000000000000000
R8:  0x0000000000000000, R9:  0xffffff804ee88f40, R10: 0x0000000000000001, R11: 0x0000006d3cf86983
R12: 0xffffff80604d5fc0, R13: 0x0000006d3cf87b04, R14: 0x00000000e0000310, R15: 0xffffff801302cec0
RFL: 0x0000000000010246, RIP: 0xffffff7f9419a984, CS:  0x0000000000000008, SS:  0x0000000000000010
Fault CR2: 0x0000000000000000, Error code: 0x0000000000000000, Fault CPU: 0x6, PL: 0

Backtrace (CPU 6), Frame : Return Address
0xffffff93fd65bbc0 : 0xffffff80128dab52
0xffffff93fd65bc40 : 0xffffff80129ce6fa
0xffffff93fd65be20 : 0xffffff80129ec563
0xffffff93fd65be40 : 0xffffff7f9419a984
0xffffff93fd65bf30 : 0xffffff7f94190559
0xffffff93fd65bf50 : 0xffffff8012f07154
0xffffff93fd65bf90 : 0xffffff8012f06eb8
0xffffff93fd65bfb0 : 0xffffff80129c9117
      Kernel Extensions in backtrace:
         com.apple.iokit.IONVMeFamily(1.2)[9468CCDF-AD0E-301C-8225-CDB081651AB8]@0xffffff7f9418e000->0xffffff7f941b0fff
            dependency: com.apple.driver.AppleMobileFileIntegrity(1.0.5)[A1E91DE9-D69F-3E42-BDE8-4C4786993FE9]@0xffffff7f93643000
            dependency: com.apple.iokit.IOPCIFamily(2.9)[5447B943-A94D-3BD4-A60F-98B24D19CE93]@0xffffff7f9312c000
            dependency: com.apple.driver.AppleEFINVRAM(2.0)[DFA558FE-59F9-32AA-8C3A-82BD65ECC094]@0xffffff7f94184000
            dependency: com.apple.iokit.IOStorageFamily(2.1)[DC1AAB7C-F417-3238-BB3F-2A5B84D67B90]@0xffffff7f9304c000
            dependency: com.apple.iokit.IOReportFamily(31)[C89107EE-2DF2-3BC3-9F6D-3133D43ED7EF]@0xffffff7f94127000

BSD process name corresponding to current thread: kernel_task

Mac OS version:
15G1004

Kernel version:
Darwin Kernel Version 15.6.0: Mon Aug 29 20:21:34 PDT 2016; root:xnu-3248.60.11~1/RELEASE_X86_64
Kernel UUID: E349749B-3303-3DDF-959C-B5885A0E1F6E
Kernel slide:     0x0000000012600000
Kernel text base: 0xffffff8012800000
__HIB  text base: 0xffffff8012700000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 469174429083
last loaded kext at 356777166374: com.apple.filesystems.msdosfs    1.10 (addr 0xffffff7f95e43000, size 69632)
last unloaded kext at 417404274625: com.apple.filesystems.msdosfs    1.10 (addr 0xffffff7f95e43000, size 61440)
loaded kexts:
de.rme-audio.driver.RMEFirefaceUSB    2.18
com.paceap.kext.pacesupport.snowleopard    5.9.1
com.MinnowStor.NVMeGeneric    1
com.apple.driver.AppleBluetoothMultitouch    90.3
com.apple.driver.AppleHWSensor    1.9.5d0
com.apple.driver.AppleTyMCEDriver    1.0.2d2
com.apple.driver.AGPM    110.22.0
com.apple.driver.AudioAUUC    1.70
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.AppleMikeyHIDDriver    124
com.apple.driver.AppleMikeyDriver    274.12
com.apple.driver.AppleHDA    274.12
com.apple.driver.pmtelemetry    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.kext.AMDFramebuffer    1.4.2
com.apple.driver.AppleUpstreamUserClient    3.6.1
com.apple.driver.AppleMCCSControl    1.2.13
com.apple.iokit.IOBluetoothSerialManager    4.4.6f1
com.apple.AMDRadeonX3000    1.4.2
com.apple.GeForceTesla    10.0.0
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    4.4.6f1
com.apple.driver.AppleHV    1
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD5000Controller    1.4.2
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.iokit.SCSITaskUserClient    3.7.7
com.apple.iokit.IOAHCIBlockStorage    2.8.5
com.apple.driver.AppleFWOHCI    5.5.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.driver.Intel82574L    2.7.0b1
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.BootCache    38
com.apple.driver.usb.AppleUSBEHCIPCI    1.0.1
com.apple.driver.AppleAHCIPort    3.1.8
com.apple.driver.usb.AppleUSBUHCIPCI    1.0.1
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleACPIButtons    4.0
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    4.0
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    218.0.0
com.apple.nke.applicationfirewall    163
com.apple.security.quarantine    3
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    218.0.0
com.apple.driver.IOBluetoothHIDDriver    4.4.6f1
com.apple.driver.AppleMultitouchDriver    304.12
com.apple.driver.AppleHIDTransport    5
com.apple.kext.triggers    1.0
com.apple.driver.DspFuncLib    274.12
com.apple.kext.OSvKernDSPLib    525
com.apple.iokit.IOSurface    108.2.3
com.apple.iokit.IOSerialFamily    11
com.apple.iokit.IOAcceleratorFamily2    205.11
com.apple.nvidia.classic.NVDANV50HalTesla    10.0.0
com.apple.nvidia.classic.NVDAResmanTesla    10.0.0
com.apple.driver.CoreCaptureResponder    1
com.apple.driver.corecapture    1.0.4
com.apple.driver.AppleSMBusController    1.0.14d1
com.apple.iokit.IONDRVSupport    2.4.1
com.apple.iokit.IOFireWireIP    2.2.6
com.apple.iokit.IOBluetoothHostControllerUSBTransport    4.4.6f1
com.apple.iokit.IOBluetoothFamily    4.4.6f1
com.apple.driver.AppleHDAController    274.12
com.apple.iokit.IOHDAFamily    274.12
com.apple.kext.AMDSupport    1.4.2
com.apple.AppleGraphicsDeviceControl    3.12.8
com.apple.iokit.IOGraphicsFamily    2.4.1
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.driver.AppleSMC    3.1.9
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d7
com.apple.driver.AppleHIDKeyboard    181
com.apple.driver.usb.IOUSBHostHIDDevice    1.0.1
com.apple.driver.AppleUSBAudio    303.3.1
com.apple.iokit.IOAudioFamily    204.4
com.apple.vecLib.kext    1.2.0
com.apple.iokit.IOSCSIBlockCommandsDevice    3.7.7
com.apple.iokit.IOUSBMassStorageDriver    1.0.0
com.apple.driver.usb.cdc    5.0.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.0.1
com.apple.driver.usb.AppleUSBHub    1.0.1
com.apple.iokit.IOSCSIMultimediaCommandsDevice    3.7.7
com.apple.iokit.IOBDStorageFamily    1.8
com.apple.iokit.IODVDStorageFamily    1.8
com.apple.iokit.IOCDStorageFamily    1.8
com.apple.iokit.IOAHCISerialATAPI    2.6.2
com.apple.iokit.IOSCSIArchitectureModelFamily    3.7.7
com.apple.iokit.IOFireWireFamily    4.6.1
com.apple.iokit.IONVMeFamily    1.2.0
com.apple.driver.usb.AppleUSBXHCIPCI    1.0.1
com.apple.driver.usb.AppleUSBXHCI    1.0.1
com.apple.iokit.IONetworkingFamily    3.2
com.apple.iokit.IOAHCIFamily    2.8.1
com.apple.driver.usb.AppleUSBUHCI    1.0.1
com.apple.driver.usb.AppleUSBEHCI    1.0.1
com.apple.iokit.IOUSBFamily    900.4.1
com.apple.iokit.IOUSBHostFamily    1.0.1
com.apple.driver.AppleUSBHostMergeProperties    1.0.1
com.apple.driver.AppleEFINVRAM    2.0
com.apple.driver.AppleEFIRuntime    2.0
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.iokit.IOSMBusFamily    1.1
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.DiskImages    417.4
com.apple.iokit.IOStorageFamily    2.1
com.apple.iokit.IOReportFamily    31
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleACPIPlatform    4.0
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.Libm    1
com.apple.kec.pthread    1
com.apple.kec.corecrypto    1.0
Model: MacPro5,1, BootROM MP51.007F.B03, 6 processors, 6-Core Intel Xeon, 3,46 GHz, 32 GB, SMC 1.39f5
Graphics: NVIDIA GeForce GT 120, NVIDIA GeForce GT 120, PCIe, 512 MB
Graphics: ATI Radeon HD 5770, ATI Radeon HD 5770, PCIe, 1024 MB
Memory Module: DIMM 1, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 2, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 3, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Memory Module: DIMM 4, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Bluetooth: Version 4.4.6f2, 3 services, 27 devices, 1 incoming serial ports
Network Service: Ethernet 2, Ethernet, en1
PCI Card: NVIDIA GeForce GT 120, Display Controller, Slot-2
PCI Card: ATI Radeon HD 5770, Display Controller, Slot-1
PCI Card: PXS4, USB eXtensible Host Controller, Slot-4
PCI Card: pci144d,a804, NVM Express Controller, Slot-3
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: WDC WD6400AAKS-41H2B0, 640,14 GB
Serial ATA Device: WDC WD1001FALS-41K1B0, 1 TB
USB Device: USB 2.0 Bus
USB Device: USB 2.0 Bus
USB Device: USB2.0 Hub
USB Device: Fireface UCX (23707810)
USB Device: USB Keystation 61es
USB Device: Keyboard Hub
USB Device: Apple Keyboard
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: BRCM2046 Hub
USB Device: Bluetooth USB Host Controller
USB Device: USB 3.0 Bus
USB Device: TransMemory
FireWire Device: built-in_hub, Up to 800 Mb/sec
Thunderbolt Bus:
I am wondering if this is a problem of the CPU or some other thing else. Would be very grateful if someone could help me. Sorry for any spelling mistakes (not my native language).


LightBulbFun

macrumors 68020
Nov 17, 2013
2,127
1,942
London UK
Hello everyone,

i am new to this forum, but I have a question related to this topic.

I did the Firmware update on a 2009 mac pro. Afterwards everything was working fine so I changed to a 6-core X5690 CPU. Next I updated the ram and installed a USB 3.0 card and a NVMe SSD. To get the ssd working i installed a driver from mac vidcards. The problem I am having now is that the mac pro does not shut down properly. Near the end of the shutdown procedure there seems to be a kernal panic. I get the "your computer restarted because of a problem" message. The report says the following:

Code:
*** Panic Report ***
panic(cpu 6 caller 0xffffff80129ce6fa): Kernel trap at 0xffffff7f9419a984, type 14=page fault, registers:
CR0: 0x000000008001003b, CR2: 0x0000000000000000, CR3: 0x0000000016608000, CR4: 0x00000000000226e0
RAX: 0xffffff7f941a6aa8, RBX: 0xffffff804edcee00, RCX: 0x0000000001000000, RDX: 0xffffff804cda6b60
RSP: 0xffffff93fd65bf30, RBP: 0xffffff93fd65bf30, RSI: 0x00000000e0000310, RDI: 0x0000000000000000
R8: 0x0000000000000000, R9: 0xffffff804ee88f40, R10: 0x0000000000000001, R11: 0x0000006d3cf86983
R12: 0xffffff80604d5fc0, R13: 0x0000006d3cf87b04, R14: 0x00000000e0000310, R15: 0xffffff801302cec0
RFL: 0x0000000000010246, RIP: 0xffffff7f9419a984, CS: 0x0000000000000008, SS: 0x0000000000000010
Fault CR2: 0x0000000000000000, Error code: 0x0000000000000000, Fault CPU: 0x6, PL: 0

Backtrace (CPU 6), Frame : Return Address
0xffffff93fd65bbc0 : 0xffffff80128dab52
0xffffff93fd65bc40 : 0xffffff80129ce6fa
0xffffff93fd65be20 : 0xffffff80129ec563
0xffffff93fd65be40 : 0xffffff7f9419a984
0xffffff93fd65bf30 : 0xffffff7f94190559
0xffffff93fd65bf50 : 0xffffff8012f07154
0xffffff93fd65bf90 : 0xffffff8012f06eb8
0xffffff93fd65bfb0 : 0xffffff80129c9117
Kernel Extensions in backtrace:
com.apple.iokit.IONVMeFamily(1.2)[9468CCDF-AD0E-301C-8225-CDB081651AB8]@0xffffff7f9418e000->0xffffff7f941b0fff
dependency: com.apple.driver.AppleMobileFileIntegrity(1.0.5)[A1E91DE9-D69F-3E42-BDE8-4C4786993FE9]@0xffffff7f93643000
dependency: com.apple.iokit.IOPCIFamily(2.9)[5447B943-A94D-3BD4-A60F-98B24D19CE93]@0xffffff7f9312c000
dependency: com.apple.driver.AppleEFINVRAM(2.0)[DFA558FE-59F9-32AA-8C3A-82BD65ECC094]@0xffffff7f94184000
dependency: com.apple.iokit.IOStorageFamily(2.1)[DC1AAB7C-F417-3238-BB3F-2A5B84D67B90]@0xffffff7f9304c000
dependency: com.apple.iokit.IOReportFamily(31)[C89107EE-2DF2-3BC3-9F6D-3133D43ED7EF]@0xffffff7f94127000

BSD process name corresponding to current thread: kernel_task

Mac OS version:
15G1004

Kernel version:
Darwin Kernel Version 15.6.0: Mon Aug 29 20:21:34 PDT 2016; root:xnu-3248.60.11~1/RELEASE_X86_64
Kernel UUID: E349749B-3303-3DDF-959C-B5885A0E1F6E
Kernel slide: 0x0000000012600000
Kernel text base: 0xffffff8012800000
__HIB text base: 0xffffff8012700000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 469174429083
last loaded kext at 356777166374: com.apple.filesystems.msdosfs 1.10 (addr 0xffffff7f95e43000, size 69632)
last unloaded kext at 417404274625: com.apple.filesystems.msdosfs 1.10 (addr 0xffffff7f95e43000, size 61440)
loaded kexts:
de.rme-audio.driver.RMEFirefaceUSB 2.18
com.paceap.kext.pacesupport.snowleopard 5.9.1
com.MinnowStor.NVMeGeneric 1
com.apple.driver.AppleBluetoothMultitouch 90.3
com.apple.driver.AppleHWSensor 1.9.5d0
com.apple.driver.AppleTyMCEDriver 1.0.2d2
com.apple.driver.AGPM 110.22.0
com.apple.driver.AudioAUUC 1.70
com.apple.filesystems.autofs 3.0
com.apple.driver.AppleOSXWatchdog 1
com.apple.driver.AppleMikeyHIDDriver 124
com.apple.driver.AppleMikeyDriver 274.12
com.apple.driver.AppleHDA 274.12
com.apple.driver.pmtelemetry 1
com.apple.iokit.IOUserEthernet 1.0.1
com.apple.kext.AMDFramebuffer 1.4.2
com.apple.driver.AppleUpstreamUserClient 3.6.1
com.apple.driver.AppleMCCSControl 1.2.13
com.apple.iokit.IOBluetoothSerialManager 4.4.6f1
com.apple.AMDRadeonX3000 1.4.2
com.apple.GeForceTesla 10.0.0
com.apple.Dont_Steal_Mac_OS_X 7.0.0
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport 4.4.6f1
com.apple.driver.AppleHV 1
com.apple.driver.AppleLPC 3.1
com.apple.kext.AMD5000Controller 1.4.2
com.apple.driver.AppleIntelSlowAdaptiveClocking 4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin 1.0.0
com.apple.iokit.SCSITaskUserClient 3.7.7
com.apple.iokit.IOAHCIBlockStorage 2.8.5
com.apple.driver.AppleFWOHCI 5.5.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless 1.0.0d1
com.apple.driver.Intel82574L 2.7.0b1
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib 1.0.0
com.apple.BootCache 38
com.apple.driver.usb.AppleUSBEHCIPCI 1.0.1
com.apple.driver.AppleAHCIPort 3.1.8
com.apple.driver.usb.AppleUSBUHCIPCI 1.0.1
com.apple.driver.AppleRTC 2.0
com.apple.driver.AppleHPET 1.8
com.apple.driver.AppleACPIButtons 4.0
com.apple.driver.AppleSMBIOS 2.1
com.apple.driver.AppleACPIEC 4.0
com.apple.driver.AppleAPIC 1.7
com.apple.driver.AppleIntelCPUPowerManagementClient 218.0.0
com.apple.nke.applicationfirewall 163
com.apple.security.quarantine 3
com.apple.security.TMSafetyNet 8
com.apple.driver.AppleIntelCPUPowerManagement 218.0.0
com.apple.driver.IOBluetoothHIDDriver 4.4.6f1
com.apple.driver.AppleMultitouchDriver 304.12
com.apple.driver.AppleHIDTransport 5
com.apple.kext.triggers 1.0
com.apple.driver.DspFuncLib 274.12
com.apple.kext.OSvKernDSPLib 525
com.apple.iokit.IOSurface 108.2.3
com.apple.iokit.IOSerialFamily 11
com.apple.iokit.IOAcceleratorFamily2 205.11
com.apple.nvidia.classic.NVDANV50HalTesla 10.0.0
com.apple.nvidia.classic.NVDAResmanTesla 10.0.0
com.apple.driver.CoreCaptureResponder 1
com.apple.driver.corecapture 1.0.4
com.apple.driver.AppleSMBusController 1.0.14d1
com.apple.iokit.IONDRVSupport 2.4.1
com.apple.iokit.IOFireWireIP 2.2.6
com.apple.iokit.IOBluetoothHostControllerUSBTransport 4.4.6f1
com.apple.iokit.IOBluetoothFamily 4.4.6f1
com.apple.driver.AppleHDAController 274.12
com.apple.iokit.IOHDAFamily 274.12
com.apple.kext.AMDSupport 1.4.2
com.apple.AppleGraphicsDeviceControl 3.12.8
com.apple.iokit.IOGraphicsFamily 2.4.1
com.apple.driver.AppleSMBusPCI 1.0.14d1
com.apple.iokit.IOSlowAdaptiveClockingFamily 1.0.0
com.apple.driver.AppleSMC 3.1.9
com.apple.driver.IOPlatformPluginLegacy 1.0.0
com.apple.driver.IOPlatformPluginFamily 6.0.0d7
com.apple.driver.AppleHIDKeyboard 181
com.apple.driver.usb.IOUSBHostHIDDevice 1.0.1
com.apple.driver.AppleUSBAudio 303.3.1
com.apple.iokit.IOAudioFamily 204.4
com.apple.vecLib.kext 1.2.0
com.apple.iokit.IOSCSIBlockCommandsDevice 3.7.7
com.apple.iokit.IOUSBMassStorageDriver 1.0.0
com.apple.driver.usb.cdc 5.0.0
com.apple.driver.usb.networking 5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice 1.0.1
com.apple.driver.usb.AppleUSBHub 1.0.1
com.apple.iokit.IOSCSIMultimediaCommandsDevice 3.7.7
com.apple.iokit.IOBDStorageFamily 1.8
com.apple.iokit.IODVDStorageFamily 1.8
com.apple.iokit.IOCDStorageFamily 1.8
com.apple.iokit.IOAHCISerialATAPI 2.6.2
com.apple.iokit.IOSCSIArchitectureModelFamily 3.7.7
com.apple.iokit.IOFireWireFamily 4.6.1
com.apple.iokit.IONVMeFamily 1.2.0
com.apple.driver.usb.AppleUSBXHCIPCI 1.0.1
com.apple.driver.usb.AppleUSBXHCI 1.0.1
com.apple.iokit.IONetworkingFamily 3.2
com.apple.iokit.IOAHCIFamily 2.8.1
com.apple.driver.usb.AppleUSBUHCI 1.0.1
com.apple.driver.usb.AppleUSBEHCI 1.0.1
com.apple.iokit.IOUSBFamily 900.4.1
com.apple.iokit.IOUSBHostFamily 1.0.1
com.apple.driver.AppleUSBHostMergeProperties 1.0.1
com.apple.driver.AppleEFINVRAM 2.0
com.apple.driver.AppleEFIRuntime 2.0
com.apple.iokit.IOHIDFamily 2.0.0
com.apple.iokit.IOSMBusFamily 1.1
com.apple.security.sandbox 300.0
com.apple.kext.AppleMatch 1.0.0d1
com.apple.driver.AppleKeyStore 2
com.apple.driver.AppleMobileFileIntegrity 1.0.5
com.apple.driver.AppleCredentialManager 1.0
com.apple.driver.DiskImages 417.4
com.apple.iokit.IOStorageFamily 2.1
com.apple.iokit.IOReportFamily 31
com.apple.driver.AppleFDEKeyStore 28.30
com.apple.driver.AppleACPIPlatform 4.0
com.apple.iokit.IOPCIFamily 2.9
com.apple.iokit.IOACPIFamily 1.4
com.apple.kec.Libm 1
com.apple.kec.pthread 1
com.apple.kec.corecrypto 1.0
Model: MacPro5,1, BootROM MP51.007F.B03, 6 processors, 6-Core Intel Xeon, 3,46 GHz, 32 GB, SMC 1.39f5
Graphics: NVIDIA GeForce GT 120, NVIDIA GeForce GT 120, PCIe, 512 MB
Graphics: ATI Radeon HD 5770, ATI Radeon HD 5770, PCIe, 1024 MB
Memory Module: DIMM 1, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 2, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 3, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Memory Module: DIMM 4, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Bluetooth: Version 4.4.6f2, 3 services, 27 devices, 1 incoming serial ports
Network Service: Ethernet 2, Ethernet, en1
PCI Card: NVIDIA GeForce GT 120, Display Controller, Slot-2
PCI Card: ATI Radeon HD 5770, Display Controller, Slot-1
PCI Card: PXS4, USB eXtensible Host Controller, Slot-4
PCI Card: pci144d,a804, NVM Express Controller, Slot-3
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: WDC WD6400AAKS-41H2B0, 640,14 GB
Serial ATA Device: WDC WD1001FALS-41K1B0, 1 TB
USB Device: USB 2.0 Bus
USB Device: USB 2.0 Bus
USB Device: USB2.0 Hub
USB Device: Fireface UCX (23707810)
USB Device: USB Keystation 61es
USB Device: Keyboard Hub
USB Device: Apple Keyboard
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: BRCM2046 Hub
USB Device: Bluetooth USB Host Controller
USB Device: USB 3.0 Bus
USB Device: TransMemory
FireWire Device: built-in_hub, Up to 800 Mb/sec
Thunderbolt Bus:
Anonymous UUID:       934022AC-B384-4FC9-7572-934C1FAD76E7

Fri Dec 15 18:27:30 2017

*** Panic Report ***
panic(cpu 6 caller 0xffffff80129ce6fa): Kernel trap at 0xffffff7f9419a984, type 14=page fault, registers:
CR0: 0x000000008001003b, CR2: 0x0000000000000000, CR3: 0x0000000016608000, CR4: 0x00000000000226e0
RAX: 0xffffff7f941a6aa8, RBX: 0xffffff804edcee00, RCX: 0x0000000001000000, RDX: 0xffffff804cda6b60
RSP: 0xffffff93fd65bf30, RBP: 0xffffff93fd65bf30, RSI: 0x00000000e0000310, RDI: 0x0000000000000000
R8:  0x0000000000000000, R9:  0xffffff804ee88f40, R10: 0x0000000000000001, R11: 0x0000006d3cf86983
R12: 0xffffff80604d5fc0, R13: 0x0000006d3cf87b04, R14: 0x00000000e0000310, R15: 0xffffff801302cec0
RFL: 0x0000000000010246, RIP: 0xffffff7f9419a984, CS:  0x0000000000000008, SS:  0x0000000000000010
Fault CR2: 0x0000000000000000, Error code: 0x0000000000000000, Fault CPU: 0x6, PL: 0

Backtrace (CPU 6), Frame : Return Address
0xffffff93fd65bbc0 : 0xffffff80128dab52
0xffffff93fd65bc40 : 0xffffff80129ce6fa
0xffffff93fd65be20 : 0xffffff80129ec563
0xffffff93fd65be40 : 0xffffff7f9419a984
0xffffff93fd65bf30 : 0xffffff7f94190559
0xffffff93fd65bf50 : 0xffffff8012f07154
0xffffff93fd65bf90 : 0xffffff8012f06eb8
0xffffff93fd65bfb0 : 0xffffff80129c9117
      Kernel Extensions in backtrace:
         com.apple.iokit.IONVMeFamily(1.2)[9468CCDF-AD0E-301C-8225-CDB081651AB8]@0xffffff7f9418e000->0xffffff7f941b0fff
            dependency: com.apple.driver.AppleMobileFileIntegrity(1.0.5)[A1E91DE9-D69F-3E42-BDE8-4C4786993FE9]@0xffffff7f93643000
            dependency: com.apple.iokit.IOPCIFamily(2.9)[5447B943-A94D-3BD4-A60F-98B24D19CE93]@0xffffff7f9312c000
            dependency: com.apple.driver.AppleEFINVRAM(2.0)[DFA558FE-59F9-32AA-8C3A-82BD65ECC094]@0xffffff7f94184000
            dependency: com.apple.iokit.IOStorageFamily(2.1)[DC1AAB7C-F417-3238-BB3F-2A5B84D67B90]@0xffffff7f9304c000
            dependency: com.apple.iokit.IOReportFamily(31)[C89107EE-2DF2-3BC3-9F6D-3133D43ED7EF]@0xffffff7f94127000

BSD process name corresponding to current thread: kernel_task

Mac OS version:
15G1004

Kernel version:
Darwin Kernel Version 15.6.0: Mon Aug 29 20:21:34 PDT 2016; root:xnu-3248.60.11~1/RELEASE_X86_64
Kernel UUID: E349749B-3303-3DDF-959C-B5885A0E1F6E
Kernel slide:     0x0000000012600000
Kernel text base: 0xffffff8012800000
__HIB  text base: 0xffffff8012700000
System model name: MacPro5,1 (Mac-F221BEC8)

System uptime in nanoseconds: 469174429083
last loaded kext at 356777166374: com.apple.filesystems.msdosfs    1.10 (addr 0xffffff7f95e43000, size 69632)
last unloaded kext at 417404274625: com.apple.filesystems.msdosfs    1.10 (addr 0xffffff7f95e43000, size 61440)
loaded kexts:
de.rme-audio.driver.RMEFirefaceUSB    2.18
com.paceap.kext.pacesupport.snowleopard    5.9.1
com.MinnowStor.NVMeGeneric    1
com.apple.driver.AppleBluetoothMultitouch    90.3
com.apple.driver.AppleHWSensor    1.9.5d0
com.apple.driver.AppleTyMCEDriver    1.0.2d2
com.apple.driver.AGPM    110.22.0
com.apple.driver.AudioAUUC    1.70
com.apple.filesystems.autofs    3.0
com.apple.driver.AppleOSXWatchdog    1
com.apple.driver.AppleMikeyHIDDriver    124
com.apple.driver.AppleMikeyDriver    274.12
com.apple.driver.AppleHDA    274.12
com.apple.driver.pmtelemetry    1
com.apple.iokit.IOUserEthernet    1.0.1
com.apple.kext.AMDFramebuffer    1.4.2
com.apple.driver.AppleUpstreamUserClient    3.6.1
com.apple.driver.AppleMCCSControl    1.2.13
com.apple.iokit.IOBluetoothSerialManager    4.4.6f1
com.apple.AMDRadeonX3000    1.4.2
com.apple.GeForceTesla    10.0.0
com.apple.Dont_Steal_Mac_OS_X    7.0.0
com.apple.iokit.BroadcomBluetoothHostControllerUSBTransport    4.4.6f1
com.apple.driver.AppleHV    1
com.apple.driver.AppleLPC    3.1
com.apple.kext.AMD5000Controller    1.4.2
com.apple.driver.AppleIntelSlowAdaptiveClocking    4.0.0
com.apple.driver.ACPI_SMC_PlatformPlugin    1.0.0
com.apple.iokit.SCSITaskUserClient    3.7.7
com.apple.iokit.IOAHCIBlockStorage    2.8.5
com.apple.driver.AppleFWOHCI    5.5.4
com.apple.AppleFSCompression.AppleFSCompressionTypeDataless    1.0.0d1
com.apple.driver.Intel82574L    2.7.0b1
com.apple.AppleFSCompression.AppleFSCompressionTypeZlib    1.0.0
com.apple.BootCache    38
com.apple.driver.usb.AppleUSBEHCIPCI    1.0.1
com.apple.driver.AppleAHCIPort    3.1.8
com.apple.driver.usb.AppleUSBUHCIPCI    1.0.1
com.apple.driver.AppleRTC    2.0
com.apple.driver.AppleHPET    1.8
com.apple.driver.AppleACPIButtons    4.0
com.apple.driver.AppleSMBIOS    2.1
com.apple.driver.AppleACPIEC    4.0
com.apple.driver.AppleAPIC    1.7
com.apple.driver.AppleIntelCPUPowerManagementClient    218.0.0
com.apple.nke.applicationfirewall    163
com.apple.security.quarantine    3
com.apple.security.TMSafetyNet    8
com.apple.driver.AppleIntelCPUPowerManagement    218.0.0
com.apple.driver.IOBluetoothHIDDriver    4.4.6f1
com.apple.driver.AppleMultitouchDriver    304.12
com.apple.driver.AppleHIDTransport    5
com.apple.kext.triggers    1.0
com.apple.driver.DspFuncLib    274.12
com.apple.kext.OSvKernDSPLib    525
com.apple.iokit.IOSurface    108.2.3
com.apple.iokit.IOSerialFamily    11
com.apple.iokit.IOAcceleratorFamily2    205.11
com.apple.nvidia.classic.NVDANV50HalTesla    10.0.0
com.apple.nvidia.classic.NVDAResmanTesla    10.0.0
com.apple.driver.CoreCaptureResponder    1
com.apple.driver.corecapture    1.0.4
com.apple.driver.AppleSMBusController    1.0.14d1
com.apple.iokit.IONDRVSupport    2.4.1
com.apple.iokit.IOFireWireIP    2.2.6
com.apple.iokit.IOBluetoothHostControllerUSBTransport    4.4.6f1
com.apple.iokit.IOBluetoothFamily    4.4.6f1
com.apple.driver.AppleHDAController    274.12
com.apple.iokit.IOHDAFamily    274.12
com.apple.kext.AMDSupport    1.4.2
com.apple.AppleGraphicsDeviceControl    3.12.8
com.apple.iokit.IOGraphicsFamily    2.4.1
com.apple.driver.AppleSMBusPCI    1.0.14d1
com.apple.iokit.IOSlowAdaptiveClockingFamily    1.0.0
com.apple.driver.AppleSMC    3.1.9
com.apple.driver.IOPlatformPluginLegacy    1.0.0
com.apple.driver.IOPlatformPluginFamily    6.0.0d7
com.apple.driver.AppleHIDKeyboard    181
com.apple.driver.usb.IOUSBHostHIDDevice    1.0.1
com.apple.driver.AppleUSBAudio    303.3.1
com.apple.iokit.IOAudioFamily    204.4
com.apple.vecLib.kext    1.2.0
com.apple.iokit.IOSCSIBlockCommandsDevice    3.7.7
com.apple.iokit.IOUSBMassStorageDriver    1.0.0
com.apple.driver.usb.cdc    5.0.0
com.apple.driver.usb.networking    5.0.0
com.apple.driver.usb.AppleUSBHostCompositeDevice    1.0.1
com.apple.driver.usb.AppleUSBHub    1.0.1
com.apple.iokit.IOSCSIMultimediaCommandsDevice    3.7.7
com.apple.iokit.IOBDStorageFamily    1.8
com.apple.iokit.IODVDStorageFamily    1.8
com.apple.iokit.IOCDStorageFamily    1.8
com.apple.iokit.IOAHCISerialATAPI    2.6.2
com.apple.iokit.IOSCSIArchitectureModelFamily    3.7.7
com.apple.iokit.IOFireWireFamily    4.6.1
com.apple.iokit.IONVMeFamily    1.2.0
com.apple.driver.usb.AppleUSBXHCIPCI    1.0.1
com.apple.driver.usb.AppleUSBXHCI    1.0.1
com.apple.iokit.IONetworkingFamily    3.2
com.apple.iokit.IOAHCIFamily    2.8.1
com.apple.driver.usb.AppleUSBUHCI    1.0.1
com.apple.driver.usb.AppleUSBEHCI    1.0.1
com.apple.iokit.IOUSBFamily    900.4.1
com.apple.iokit.IOUSBHostFamily    1.0.1
com.apple.driver.AppleUSBHostMergeProperties    1.0.1
com.apple.driver.AppleEFINVRAM    2.0
com.apple.driver.AppleEFIRuntime    2.0
com.apple.iokit.IOHIDFamily    2.0.0
com.apple.iokit.IOSMBusFamily    1.1
com.apple.security.sandbox    300.0
com.apple.kext.AppleMatch    1.0.0d1
com.apple.driver.AppleKeyStore    2
com.apple.driver.AppleMobileFileIntegrity    1.0.5
com.apple.driver.AppleCredentialManager    1.0
com.apple.driver.DiskImages    417.4
com.apple.iokit.IOStorageFamily    2.1
com.apple.iokit.IOReportFamily    31
com.apple.driver.AppleFDEKeyStore    28.30
com.apple.driver.AppleACPIPlatform    4.0
com.apple.iokit.IOPCIFamily    2.9
com.apple.iokit.IOACPIFamily    1.4
com.apple.kec.Libm    1
com.apple.kec.pthread    1
com.apple.kec.corecrypto    1.0
Model: MacPro5,1, BootROM MP51.007F.B03, 6 processors, 6-Core Intel Xeon, 3,46 GHz, 32 GB, SMC 1.39f5
Graphics: NVIDIA GeForce GT 120, NVIDIA GeForce GT 120, PCIe, 512 MB
Graphics: ATI Radeon HD 5770, ATI Radeon HD 5770, PCIe, 1024 MB
Memory Module: DIMM 1, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 2, 8 GB, DDR3 ECC, 1333 MHz, 0x802C, 0x33364B534631473732505A2D314734443120
Memory Module: DIMM 3, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Memory Module: DIMM 4, 8 GB, DDR3 ECC, 1333 MHz, 0x80CE, 0x4D33393342314B37304348302D5948392020
Bluetooth: Version 4.4.6f2, 3 services, 27 devices, 1 incoming serial ports
Network Service: Ethernet 2, Ethernet, en1
PCI Card: NVIDIA GeForce GT 120, Display Controller, Slot-2
PCI Card: ATI Radeon HD 5770, Display Controller, Slot-1
PCI Card: PXS4, USB eXtensible Host Controller, Slot-4
PCI Card: pci144d,a804, NVM Express Controller, Slot-3
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: HL-DT-ST DVD-RW GH41N
Serial ATA Device: WDC WD6400AAKS-41H2B0, 640,14 GB
Serial ATA Device: WDC WD1001FALS-41K1B0, 1 TB
USB Device: USB 2.0 Bus
USB Device: USB 2.0 Bus
USB Device: USB2.0 Hub
USB Device: Fireface UCX (23707810)
USB Device: USB Keystation 61es
USB Device: Keyboard Hub
USB Device: Apple Keyboard
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: USB Bus
USB Device: BRCM2046 Hub
USB Device: Bluetooth USB Host Controller
USB Device: USB 3.0 Bus
USB Device: TransMemory
FireWire Device: built-in_hub, Up to 800 Mb/sec
Thunderbolt Bus:
I am wondering if this is a problem of the CPU or some other thing else. Would be very grateful if someone could help me. Sorry for any spelling mistakes (not my native language).

your panics on reboot are caused by the 3rd party NVMe driver, I dont recommend using its quite out of date and buggy, if you can update to High Sierra which works OOTB with most NVMe SSDs without the need for a 3rd party driver.


Max_Mustermann

macrumors newbie
Dec 15, 2017
4
2
your panics on reboot are caused by the 3rd party NVMe driver, I dont recommend using its quite out of date and buggy, if you can update to High Sierra which works OOTB with most NVMe SSDs without the need for a 3rd party driver.
Thanks for the tip! I did a bit of research and its worth a try. But there is still no way to use the nvme ssd as a boot drive?


h9826790

macrumors G5
Apr 3, 2014
12,785
5,598
Hong Kong
Thanks for the tip! I did a bit of research and its worth a try. But there is still no way to use the nvme ssd as a boot drive?
You can, there is a post about this. It require boot redirection. However, the problem is no way to update the OS at this moment.

Also, there is virtually zero benefit to use NVMe as boot drive. So, why make it so complicated?


Max_Mustermann

macrumors newbie
Dec 15, 2017
4
2
Ah okay. I will check this. The benefit I am hoping for is to have the incredible read/write speed of the m.2 ssd with thhe system drive. Faster startup, working in programs, etc.. Maybe I am missing something? I did get it to work as an external drive and the speeds were as I was expecting.

Currently I am having trouble installing 10.13. I have deleted the driver from /Library/Extensions but still get the kernal panic on shutdown. For HS the mac pro needs the Firmware update first which requires the computer to shutdown. Problem is that the kernal panic seems to force a restart. Does anyone have a tip on how best to proceed?
