The Crucial M4 SSD thread

Discussion in 'MacBook Pro' started by Hexley, Dec 19, 2012.

  1. Hexley macrumors 6502a

    Joined:
    Jun 10, 2009
    #1
    I noticed that no thread for the Crucial M4 has been made so here it is.

    Share with us your experience with this very reasonably priced Crucial SSD.

    ===============================


    A request!

    Kindly post the following info

    1) Screen grab of BlackMagic Design's Disk Speed Test of your original HDD (before) and Crucial M4 SSD (after)

    2) Hardware overview from "System Information" namely
    - Screen Size and Model Year
    - Model Identifier
    - Processor Name
    - Processor Speed
    - Memory
    - Bus Speed
    - Serial-ATA's Link Speed & Negotiated Link Speed
    - TRIM: On/Off
    - OS X version

    4) Info on the Crucial M4 SSD.
    - Capacity
    - Disk bay installed: Main or Superdrive bay
    - Firmware version (this is rather important as some firmware really screws up the SSD)

    3) Other notable modifications like RAID 0, battery life (with HDD and with SSD) etc.

  2. FuNGi macrumors 65816

    FuNGi

    Joined:
    Feb 26, 2010
    Location:
    California
    #2
    Well, there is a few...but I agree we could focus the information a bit..

    1) Coming from my Momentus 7200rpm/4GB SSD hybrid drive, with an atrocious write speed of 60, I got write speed increases of 275% and read speed increases of 631% with my Crucial M4. Think works great and is easily updateable.

    2) Hardware overview:
    - 15" hi-res glossy from early 2011
    - MacBookPro8,2
    - 2 GHz Intel Core i7
    - 8 GB Ram
    - 5 Gt/s
    - 6 Gigabit, 6 Gigabit negotiated
    - TRIM: On
    - OS X 10.8.2

    4) Info on the Crucial M4 SSD.
    - 512 GB
    - Disk bay installed: Main bay
    - Firmware version 000F (I haven't felt justified to update the subsequent two minor firmware revisions because they were mainly to optimize the drive for Window's 8 machines)

    3) Sleep HD mode turned off, turned Hibernation Mode turned off, Sudden Motion Sensor turned off , no problems

  3. Hexley thread starter macrumors 6502a

    Joined:
    Jun 10, 2009
    #3
    FuNGi any benchmarks? :) I am curious as to the performance of the drive on your Mac. Also how is the battery life? Is it better than the Seagate you replaced? How many hours battery life did you get before with the HDD and after with the SSD.

  4. T5BRICK, Dec 19, 2012
    Last edited: Dec 19, 2012

    T5BRICK macrumors 604

    T5BRICK

    Joined:
    Aug 3, 2006
    Location:
    Oregon
    #4
    1) I don't have a screen shot of the "before" benchmark, but it was 40MB/s read and 35MB/s write. The M4 is 265MB/s read and 205MB/s write.

    2) Hardware overview
    - 13" mid 2009
    - Core2 Duo
    - 2.53GHz
    - 8GB 1333MHz
    - Bus Speed
    - SATA link speed 3.0Gb/s, negotiated link speed 3.0Gb/s
    - TRIM: On
    - OS X 10.8.2

    3) Info on the Crucial M4 SSD.
    - 256GB
    - installed in Main bay
    - Firmware version 000F, 010G and 040H; with no issues to report on any one.

    4) Other notable modifications: No noticeable change in battery life. The computer is 3+ years old now, so the battery isn't in perfect health anyway.

    *edit* Corrected iPhone induced technical errors.

  5. daneoni macrumors G4

    daneoni

    Joined:
    Mar 24, 2006
    #5
    2) Hardware overview:
    - 15" HR/AG - Early '11
    - MacBookPro8,2
    - 2.2 GHz Intel Core i7
    - 16 GB Ram
    - 5 Gt/s
    - 6 Gigabit, 6 Gigabit negotiated
    - TRIM: On
    - OS X 10.8.2

    4) Info on the Crucial M4 SSD.
    - 256 GB
    - Disk bay installed: Main bay
    - Firmware version 010G (tried to update to 040H but utility wouldn't find the drive...so i just left it as is)

    3) Sleep HD mode on, Hibernation Mode on, SMS on, no issues

    1) I don't have BlackImage and i'm too lazy to start going to the MAS. So here's an AJA test from Snow Leopard days. Still get similar speeds today. Came from a regular Hitachi 7200RPM drive.


    Attached Files:

  6. richnyc, Dec 19, 2012
    Last edited: Dec 19, 2012

    richnyc macrumors regular

    richnyc

    Joined:
    Nov 8, 2012
    Location:
    NYC
    #6
    1) Don't have speeds before install. I already had Samsung 256GB 830 installed in my HDD bay as a main disk, added Crucial 512GB m4 for data storage in superdrive day.

    2) Hardware overview:
    - 13" cMBP mid-2012
    - MacBookPro9,2
    - 2.5 GHz Intel Core i5
    - 16 GB Ram
    - 5 Gt/s
    - 6 Gigabit, 6 Gigabit negotiated
    - TRIM: On
    - OS X 10.8.2

    4) Info on the Crucial M4 SSD.
    - 512 GB
    - Disk bay installed: Superdrive with OWC Data Doubler
    - Firmware version 010G

    3) Sleep HDD mode: OFF, Hibernation Mode: OFF, Sudden Motion Sensor: OFF


    Attached Files:

  7. jvpython macrumors 6502

    Joined:
    Aug 25, 2011
    Location:
    New Zealand
    #7
    I have a 128GB Crucial M4 installed in my 15" 2012 MBP. Hoping to upgrade to 512GB soon.

    1) I've been using it for a while and it seems I only get about 200MB/s write speeds and about 490MB/s read.

    2) Hardware overview
    - 15" MacBook Pro, Mid 2012
    - MacBookPro9,1
    - 2.3 GHz Intel Core i7
    - 4GB 1600Mhz RAM
    - 5Gt/s
    - 6 Gigabit Link Speed & 6 Gigabit Negotiated Link Speed
    - TRIM: On
    - OS X 10.8.2

    4) Info on the Crucial M4 SSD.
    - 128GB
    - Installed in main bay
    - Firmware version: 010G

    3) No other notable modifications. Great battery life.

    ----------

    - SATA link speed 3.0GB/s, negotiated link speed 3.0GB/s

    Link speed is in Gigabits not Gigabytes :rolleyes:

  8. TheSpeaker macrumors member

    Joined:
    Nov 30, 2012
    #8
    I've had 4 M4s die on me in the last 18 months. Never again.

  9. T5BRICK macrumors 604

    T5BRICK

    Joined:
    Aug 3, 2006
    Location:
    Oregon
    #9
    I assume you're talking to me. I know the difference between GB and Gb. Unfortunately, my iPhone doesn't and it insists on autocorrecting to "GB" every time. I didn't feel like arguing with it today. :)

    ----------

    That's awesome! I haven't had any issues with any of the ones I've purchased. Since you had multiple failures of a drive that's actually considered to be very reliable, it sounds like something is wrong with your setup.

  10. darkmaxdevil macrumors member

    Joined:
    Aug 28, 2011
    Location:
    Bangkok, Thailand
    #10
    1) I installed SSD since day 1 so I don't have a screen grab on HDD.

    [​IMG]

    2) Hardware overview from "System Information" namely
    - 15.4" Macbook Pro late 2011
    - Model Identifier: MacBookPro8,2
    - Processor Name: Intel Core i7
    - Processor Speed: 2.5 GHz
    - Memory: 8 GB
    - Bus Speed: 1333MHz
    - Link Speed: 6 Gigabit
    Negotiated Link Speed: 6 Gigabit
    - TRIM: On
    - OS X 10.8.2

    4) Info on the Crucial M4 SSD.
    - Capacity 512 GB
    - Disk bay installed: Main
    - Firmware version 040H

    3) Sleep HDD mode: OFF, Hibernation Mode: OFF, Sudden Motion Sensor: OFF Battery life around 5-6 programming+iTunes hours.

  11. clyde2801 macrumors 601

    clyde2801

    Joined:
    Mar 6, 2008
    Location:
    In the land of no hills and red dirt.
    #11

    Oh, I thought it sent three Great Britain's per second. My bad.:eek:

  12. TheSpeaker macrumors member

    Joined:
    Nov 30, 2012
    #12
    That's awesome! Nope, several machines.

  13. spoonie1972 macrumors 6502a

    Joined:
    Aug 17, 2012
    Location:
    Toronto
    #13
    M4, 512gigs.

    000F firmware. no issues, so i'm not upgrading it.

    Approx 520 read, and iirc, varied between 220-260 write on black magic.

    Zero issues, been great and fantastic in the laptop.

  14. dmk1974 macrumors 68000

    dmk1974

    Joined:
    Sep 16, 2008
    #14
    I just bought a 2012 15" MBP yesterday and promptly installed a 256gb M4 SSD and 16gb RAM. I can attach a screen shot later, but when I ran the BlackMagic speed test, I got about 261 write and 502 read.

  15. yusukeaoki macrumors 68030

    yusukeaoki

    Joined:
    Mar 22, 2011
    Location:
    Tokyo, Japan
    #15
    I dont like to use BM much since it puts a lot of stress on my SSD.
    But far as I remember,

    1) -500GB@7200rpm stock: 60mbps write, 110 mbps read
    -Crucial M4 128GB: 198mbps write, 512mbps read

    2) -2011 17in MacBook Pro
    -MacBookPro8,3
    -2.2GHz Intel Core i7 Quad Core 2720QM
    -16GB DDR3 1333MHz
    -Link & Negotiation: 6Gigabit
    -TRIM Off
    -Mac OS X 10.8.2

    3) 1TB Samsung Spinpoint HDD@5400rpm inside optibay
    No change in battery time
    4) -128GB
    -Main bay
    -OFW: 309

  16. BeeJee, Dec 20, 2012
    Last edited: Dec 20, 2012

    BeeJee macrumors 6502

    Joined:
    Nov 27, 2011
    Location:
    Long Island/North Jersey
    #16
    My early 2011 13 inch. Has a 256GB running 000F, had it since end of April and never really gave me problems. My GeekBench score is only 6 points lower than the Retina 13! I would most likely get an 840 now though. Back when I bought mine there was still about a $40 dollar difference in price and I'm cheap. :D BTW THE RAM IS PNY Brand, its eh.
    [​IMG]
    [​IMG]
    [​IMG]

  17. Pentad macrumors 6502a

    Pentad

    Joined:
    Nov 26, 2003
    Location:
    Indiana
    #17

    I'm not sure where you got that information but that newer firmware(s) does much more than that. I have been working with Crucial's tech support folks and the last two revisions have been changes to the internal drive operations, Windows 8, some chipset issues, and data optimization.

    A company I do consulting for had some of the 512 GB M4's and a machine developed the sleep issue with one of the firmwares (I think the one before the current one, but I don't remember). Anyway, while working with tech support they talked about the changes the firmware was going to include.

    I was surprised at how much house keeping the drive does internally. That is why the was recommending people do 20 mins - 30 secs - 20 mins drive resets for the sleep issue. By powering the drive and letting it sit, it could resolve most issues.

    The newer firmware (especially the latest one) really improves this function of the drive.

    With regard to the sleep issue, it became apparent that the more time you give the drive the better chance it will resolve itself. I did 20-30-20, then 40-30-40, and on my own I did 60-30-60 and that solved the problem. When I told tech support what I did, they said they had people do 24 hour - 30 sec - 24 hour before.

    I thought the SSDs were sophisticated before but this really helped me to understand how sophisticated they really are.

    The latest firmware solved the sleep issue.


    -P

  18. FuNGi, Dec 20, 2012
    Last edited: Dec 20, 2012

    FuNGi macrumors 65816

    FuNGi

    Joined:
    Feb 26, 2010
    Location:
    California
    #18
    That's great if it solved issues you were having with sleep. The current and past updates mentioned Windows 8 optimization along with other minor improvements that I deemed unworthy of risking upgrade. Such as this passage from Crucial's current 040H revision:

    "Like firmware version 010G, version 040H has improvements
    over versions 000F and earlier which are specific for
    Windows 8 and new UltraBook systems, although systems
    running Windows 7 and other operating systems may also
    see improvements. Any m4 firmware version will function
    normally in Windows 8, even without these performance
    improvements.
    "

    ----------

    The performance is excellent. Apps and huge photo libraries open instantly. Black magic was around 275/490 last checked (not on MBP now) EDIT:see pics before on Momentus XD and after on Crucial M4. Don't notice battery life improvements much as my MBP is mainly run in clamshell mode hooked up to my 24" ACD. Plus I've found battery life a slippery thing to clock.


    Attached Files:

  19. telequest, Dec 21, 2012
    Last edited: Dec 21, 2012

    telequest macrumors regular

    Joined:
    Feb 1, 2010
    Location:
    NJ
    #19
    sleep issue?

    My Mac Pro tower is suddenly having problems waking from sleep. Boot drive is a 256GB Crucial M4 in the 2nd optical bay. I'm visiting the MBP forum since no answers yet on MP forum.

    Could you explain what you mean by 20-30-20 or 40-30-40 etc? What exactly are you doing during those time periods to reset the drive? And does that somehow resolve sleep issues? Thanks!

    Or ... should I just go ahead with the 040H firmware upgrade?

  20. FuNGi macrumors 65816

    FuNGi

    Joined:
    Feb 26, 2010
    Location:
    California
    #20
    You may solve your issues with the update. I would try that before trying the sleep cycles.

    I went ahead and updated and everything seems fine. After rebooting there was an initial delay in tracking my clicks but it soon went away.

  21. Blue604 macrumors regular

    Joined:
    Mar 6, 2012
    #21
    2009 mbp 13" 2.53 in HDD bay. 040H firmware Trim enabled.


    Attached Files:

  22. J.Appleseed macrumors regular

    J.Appleseed

    Joined:
    May 27, 2012
    Location:
    The Netherlands
    #22
    1. HDD vs SSD
    HDD: 60 MB/s write, 60 MB/s read
    SSD: 262 MB/s write, 493 MB/s read

    2. Hardware overview
    Screen size, model year: 13-inch, late 2011
    Model identifier: MacBookPro8,1
    Processor name: Intel Core i5
    Processor speed: 2.4 GHz
    Memory: 8 GB DDR3 @ 1333 MHz (Corsair Mac)
    Bus speed: Intel Direct Media Interface 5 GT/s
    Serial-ATA link speed: 6 Gigabit
    Serial-ATA negotiated link speed: 6 Gigabit
    TRIM: On
    OS X version: 10.8.2 (12C60)

    3. Crucial M4 info
    Capacity: 256.06 GB
    Disk bay installed: Main bay
    Firmware version: original 000F, upgraded to 040H

    4. Comments
    No noticeable improved battery life
    Shutdown takes quite long (10-15 seconds)
    Sleep HD mode turned on*
    Hibernation mode turned on*
    Sudden motion sensor turned off
    No actual problems thus far

    ------

    * I turned them on just now to see if it makes any difference regarding shutdown. Will post results in a few days.

  23. Joseph Farrugia macrumors regular

    Joined:
    Jul 31, 2011
    Location:
    Malta (EU)
    #23
    Thanks for sharing the info, I am about to get a 512GB M4 for my early 2011 15" MBP; & am a bit concerned about your long shutdown time, is it normal?

  24. karsten, Jan 2, 2013
    Last edited: Jan 2, 2013

    karsten macrumors 6502a

    karsten

    Joined:
    Sep 3, 2010
    #24
    early 2009 MBP 17", 64GB M4 in HDD bay, trim enabled, 040h firmware


    Attached Files:

  25. Tenashus1 macrumors 6502

    Joined:
    Jul 27, 2011
    #25
    2012 13" MBP i7: 8-10 second shutdown with M4 512gb installed.
