Trying to connect to a tv - are these two adapters the same thing?

Discussion in 'Mac Basics and Help' started by ozreth, Mar 16, 2010.

  1. ozreth macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #1
    Was wondering if this min displayport to dvi adapter is the same as this one? Other than the brand obviously.

    Also, after I've boughten one of those, will this dvi to component cable work with either of the above adapters?

    Thanks : )

  2. vchalupa macrumors member

    Joined:
    Jan 24, 2008
    #2
    They look the same to me. Just a thought, try buying from monoprice.com. You'll probably find a much better deal on pretty much everything related to cabling there. I buy all my cables from them. They're super cheap and work quite well. Only downside is you have to pay for shipping but still a lot cheaper than buying from apple directly.

    Hope it helps!

  3. ozreth thread starter macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #3
    Sweet thanks! Ill check it out. But that cable is only 5 bucks on amazon!

  4. vchalupa macrumors member

    Joined:
    Jan 24, 2008
    #4
    You should be able to find the adapter for much cheaper too. Possible somewhere around $10 if not cheaper.

  5. jodelli macrumors 65816

    jodelli

    Joined:
    Jan 6, 2008
    Location:
    Windsor, ON, Canada
    #5
    Looks like the third adapter with three A/V jacks is female. One of the other two adapters would have to be male.

  6. ozreth thread starter macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #6
    I have no idea what that means but you are probably right. Got both cables in the mail and it aint workin : /

  7. Bacong macrumors 68000

    Bacong

    Joined:
    Mar 7, 2009
    Location:
    Westland, Michigan
    #7
    think about it. basic organic design.

    Male RCA:

    [​IMG]

    Female RCA:

    [​IMG]

    Male into female.

    :p

  8. Koronis macrumors member

    Koronis

    Joined:
    Feb 16, 2009
    Location:
    Windsor,Ontario,Canada
    #8
    Those are actually different adaptors, one is mini-displayport, and the other is mini-dvi. You need to make sure you get the right one for your computer

  9. ozreth thread starter macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #9
    Any idea which I would need for the mid 09 mbp?

  10. ozreth thread starter macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #10
    Ah I see. But the one I bought has prongs.

  11. Koronis macrumors member

    Koronis

    Joined:
    Feb 16, 2009
    Location:
    Windsor,Ontario,Canada
  12. cderalow macrumors 6502

    cderalow

    #12
    no one has caught the the two adapters are not the same.

    The first is MiniDISPLAYPORT to DVI, the second is MiniDVI to regular DVI.

    Two very different things.

    If you have a MacBook or old PowerBook, you would need #2. If you have a newer (late 2008+) MacBook or MacBook Pro, you will need #1.

  13. ozreth thread starter macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #13
    Alrighty, thanks : ) the dvi to component cables I got should be ok though?

  14. cderalow macrumors 6502

    cderalow

    #14
    Yes

  15. Makosuke macrumors 603

    Joined:
    Aug 15, 2001
    Location:
    The Cool Part of CA, USA
    #15
    Actually, unless I'm very mistaken, no it won't. I've read complaints here from people who attempted to do this with a VGA monitor and it didn't work.

    Note that the component adapter says DVI-I, because it requires that DVI signal to include the analog VGA signal wires to do anything with it. To my knowledge no Displayport-DVI adapters support an analog, VGA-style signal. Displayport is capable of adjusting its output signal to match HDMI/DVI, if (I assume) the adapter tells it to, but that has nothing to do with the analog signal that DVI-I includes on a separate set of pins.

    What you need is a Displayport to VGA adapter, then a VGA to component adapter. This will work because Displayport-VGA adapters are active--they have circuitry inside that is powered by the power available from the Displayport connector (yep, there's power in there, like USB), and converts the digital signal to analog. Here's Apple's:

    http://store.apple.com/us/product/MB572Z/A

    ...though I bought a cheaper 3rd party one for about $20 (I think from Monoprice, but I can't remember right now and I'm at work so I can't check), which worked perfectly with a VGA monitor.

    Note that it still might not work, depending on what you're plugging the component cables into and how the VGA adapter works--I have read that unless the device is specifically configured to output a component signal (some video cards do), a "dumb" VGA-component adapter won't do anything. You need a transcoder that actually converts the VGA signal to a component one.

    It's possible that the displayport-VGA adapter does this for you, or maybe that your TV/projector/whatever can handle it, but for $29 I seriously doubt it, and it's a gamble if you can't return the cables. Thread with some info:

    http://www.avsforum.com/avs-vb/showthread.php?t=840626

    And a thread at Apple asking about the same thing confirming it probably won't work even when they're sold together, as you'll find on eBay and discount retailers:

    http://discussions.apple.com/thread.jspa?messageID=10551966

    ...so unless your TV/projector will accept a VGA input on its component inputs (unlikely, I think), you'll need the above-linked Displayport to VGA adapter plus a VGA to component converter, like this StarTech one, which are relatively spendy. You'd be in much better shape if your device includes either a VGA (or better yet HDMI) input--many do.

  16. ozreth thread starter macrumors 65816

    ozreth

    Joined:
    Nov 5, 2009
    #16

    Youre right , Ill need the converted. Its been verified by several genius bar guys. This is crazy to me. First time I've been very dissapointed in apple : /

  17. Makosuke macrumors 603

    Joined:
    Aug 15, 2001
    Location:
    The Cool Part of CA, USA
    #17
    Why? Most non-Apple computers don't have component output, either, and many of the ones with VGA out wouldn't work any better with the "dumb" VGA-Component cables than a Mac. The issue is with the differences in analog formats, not Apple.

    Now, if you're complaining that Apple doesn't make a DisplayPort to Component converter, that's legit.

    The root problem is that TVs with component in but no HDMI haven't been manufactured (to my knowledge) for years, and are comparatively rare.
