Other XS' camera sensor is 32% larger than X's.

EugW

macrumors G3
Original poster
Jun 18, 2017
8,237
5,615
Confirmed by Apple: The XS camera sensor is a whopping 1/3rd larger than the sensor in the X.

https://daringfireball.net/2018/09/the_iphones_xs

The iPhone X’s wide-angle lens had an equivalent focal length of 28 mm. Its actual focal length was 4.0 mm.

When I first started comparing side-by-side shots from the iPhone XS and iPhone X using the wide-angle lens, I noticed that the shots from the iPhone XS had a slightly larger field of view. They were a little bit wider. Look at the photos of the clown photo booth above and you can see it clearly. I didn’t move at all between those shots — both phones were roughly the same distance from the subjects, but the iPhone XS captured more of the scene. Apple confirmed to me that this is true — the iPhone XS wide-angle lens has an equivalent focal length of 26 mm. Not a lot wider, but enough to be noticeable. But when you look at the actual focal length of the lens in Photos (or any other app that can display the EXIF data of the image files), it is 4.25 mm.

0.25 mm may sound tiny but consider that the “telephoto” lens is only 6 mm. The equivalent focal length is wider, but the actual focal length is longer. This made no sense to me at first. Then I realized it would make sense if the camera sensor were a lot larger. And lo, here’s what Apple’s iPhone XS camera page says:

More low‑light detail. The camera sensor features deeper, larger pixels. Deeper to improve image fidelity. And larger to allow more light to hit the sensor. The result? Even better low‑light photos.

“Larger” is all they say. Not how much larger. That left me with the assumption that it was only a little bit larger, because if it were a lot larger, they’d be touting it, right? There are “field of view” calculators you can use to compute the sensor size given the other variables, so I used one, and by my calculations, the sensor would be over 30 percent larger.

I repeat: over 30 percent larger.

That seemed too good to be true. But I checked, and Apple confirmed that the iPhone XS wide-angle sensor is in fact 32 percent larger. That the pixels on the sensor are deeper, too, is what allows this sensor to gather 50 percent more light. This exemplifies why more “megapixels” are not necessarily better. One way to make a sensor bigger is to add more pixels. But what Apple’s done here is use the same number — 12 megapixels — and make the pixels themselves bigger. 12 megapixels are plenty — what phone cameras need are bigger pixels.

I think what makes this 32 percent increase in sensor size hard to believe, especially combined with a slightly longer lens, is that by necessity, this combination means the sensor must be further way from the lens. This basic necessity of moving the lens further from the sensor (or film) is why DSLRs are so big compared to a phone. But the iPhone XS is exactly the same thickness as the iPhone X, including the camera bump. (Apple doesn’t publish the bump thickness but I measured with precision calipers.) So somehow Apple managed not only to put a 32 percent larger sensor in the iPhone XS wide-angle camera, but also moved the sensor deeper into the body of the phone, further from the lens.

And to geek out even more, even though the XS has a wider field of view, because the actual lens element on the XS is longer than the X, it gets this wider field of view without introducing additional wide-angle lens barrel distortion — in fact, because the actual lens is longer, I suspect there’s less barrel distortion. Slightly less of that generally undesirable fisheye effect, even though the field of view is slightly wider.

Why isn’t Apple touting this larger sensor? Well, look at how long it took me to get to the end of this section. It’s a rabbit hole. They got out of this whole digression by just saying the sensor gathers 50 percent more light. On the one hand, that’s really all that matters. But on the other hand, to my ears at least, “50 percent more light” seems a bit hand-wavy.

“32 percent larger sensor”, however, means something very specific, and it should perk up the ears of any photographer — even one who’s skeptical of Apple’s “computational photography” claims. You could sell an upgrade to the XS to iPhone X-owning photo enthusiasts just by telling them the sensor is so much larger.

The other explanation I can think of is that this almost certainly isn’t Apple’s own sensor. Camera sensors aren’t something Apple designs on its own (yet?). So maybe they don’t want to call extra attention to something that is bound to appear in other high-end phones soon.

Apple isn’t celebrating this new sensor, but photographers will be.


KrisYYC

macrumors member
Sep 26, 2017
68
48
This is good news to me. That and the improved audio recording while taking video. Should be quite the upgrade from my iPhone 8 and a good competitor to the Android phones I've used (Pixel 2, Huawei P20 Pro).


Ortiz83

macrumors 6502
Mar 9, 2018
429
234
Confirmed by Apple: The XS camera sensor is a whopping 1/3rd larger than the sensor in the X.

https://daringfireball.net/2018/09/the_iphones_xs

The iPhone X’s wide-angle lens had an equivalent focal length of 28 mm. Its actual focal length was 4.0 mm.

When I first started comparing side-by-side shots from the iPhone XS and iPhone X using the wide-angle lens, I noticed that the shots from the iPhone XS had a slightly larger field of view. They were a little bit wider. Look at the photos of the clown photo booth above and you can see it clearly. I didn’t move at all between those shots — both phones were roughly the same distance from the subjects, but the iPhone XS captured more of the scene. Apple confirmed to me that this is true — the iPhone XS wide-angle lens has an equivalent focal length of 26 mm. Not a lot wider, but enough to be noticeable. But when you look at the actual focal length of the lens in Photos (or any other app that can display the EXIF data of the image files), it is 4.25 mm.

0.25 mm may sound tiny but consider that the “telephoto” lens is only 6 mm. The equivalent focal length is wider, but the actual focal length is longer. This made no sense to me at first. Then I realized it would make sense if the camera sensor were a lot larger. And lo, here’s what Apple’s iPhone XS camera page says:

More low‑light detail. The camera sensor features deeper, larger pixels. Deeper to improve image fidelity. And larger to allow more light to hit the sensor. The result? Even better low‑light photos.

“Larger” is all they say. Not how much larger. That left me with the assumption that it was only a little bit larger, because if it were a lot larger, they’d be touting it, right? There are “field of view” calculators you can use to compute the sensor size given the other variables, so I used one, and by my calculations, the sensor would be over 30 percent larger.

I repeat: over 30 percent larger.

That seemed too good to be true. But I checked, and Apple confirmed that the iPhone XS wide-angle sensor is in fact 32 percent larger. That the pixels on the sensor are deeper, too, is what allows this sensor to gather 50 percent more light. This exemplifies why more “megapixels” are not necessarily better. One way to make a sensor bigger is to add more pixels. But what Apple’s done here is use the same number — 12 megapixels — and make the pixels themselves bigger. 12 megapixels are plenty — what phone cameras need are bigger pixels.

I think what makes this 32 percent increase in sensor size hard to believe, especially combined with a slightly longer lens, is that by necessity, this combination means the sensor must be further way from the lens. This basic necessity of moving the lens further from the sensor (or film) is why DSLRs are so big compared to a phone. But the iPhone XS is exactly the same thickness as the iPhone X, including the camera bump. (Apple doesn’t publish the bump thickness but I measured with precision calipers.) So somehow Apple managed not only to put a 32 percent larger sensor in the iPhone XS wide-angle camera, but also moved the sensor deeper into the body of the phone, further from the lens.

And to geek out even more, even though the XS has a wider field of view, because the actual lens element on the XS is longer than the X, it gets this wider field of view without introducing additional wide-angle lens barrel distortion — in fact, because the actual lens is longer, I suspect there’s less barrel distortion. Slightly less of that generally undesirable fisheye effect, even though the field of view is slightly wider.

Why isn’t Apple touting this larger sensor? Well, look at how long it took me to get to the end of this section. It’s a rabbit hole. They got out of this whole digression by just saying the sensor gathers 50 percent more light. On the one hand, that’s really all that matters. But on the other hand, to my ears at least, “50 percent more light” seems a bit hand-wavy.

“32 percent larger sensor”, however, means something very specific, and it should perk up the ears of any photographer — even one who’s skeptical of Apple’s “computational photography” claims. You could sell an upgrade to the XS to iPhone X-owning photo enthusiasts just by telling them the sensor is so much larger.

The other explanation I can think of is that this almost certainly isn’t Apple’s own sensor. Camera sensors aren’t something Apple designs on its own (yet?). So maybe they don’t want to call extra attention to something that is bound to appear in other high-end phones soon.

Apple isn’t celebrating this new sensor, but photographers will be.


doboy

macrumors 68020
Jul 6, 2007
2,478
962
Actually if you look at some photos on the Mashable site, XS Max photos seem more distorted.


Arni99

macrumors 6502a
Feb 26, 2011
542
258
Vienna, Austria
Apples 1/2,55" sized sensor still has room for improvement.
Am sure Apple could have used the same 1/1,7" sized sensor Huawei is using in the "P20 Pro" but keeps this one for next years iPhone XI or XII or XIII.

Sensor size comparison:
