ATI Radeon HD 5870 vs GTX570 for dual 24 inch displays

Discussion in 'Mac Pro' started by headkick33, Jul 9, 2012.

  1. headkick33 macrumors newbie

    Joined:
    Jul 9, 2012
    #1
    I am looking to upgrade my graphics card and have a few questions.

    My Mac Pro desktop setup is as follows:

    Mac Pro 4,1 (8-core Xeon 5500 Series) 2.26Ghz 3rd Gen. Early 2009
    OS 10.6.8
    10GB Ram (upgrading to 24GB)

    I have 2 - 24inch Cinema displays running from 2 NVIDIA GeForce GT 120 cards.

    I want to upgrade my 2 GEForce cards to one Apple ATI Radeon HD 5870 and use the 2 mini-display ports for my two 24inch Cinema Displays. Does anyone know of conflicts or issues with this setup? After doing some research, looks like it should work fine but thought I would ask before shelling out the $450 for the new card. Also, any info on performance improvement would be appreciated.

    I have also heard that the GeForce GTX570 is pretty rad but uses DVI ports and not sure I can run my Cinema Displays because of the mini-display connectors they use.

    I am a motion graphics artist and use After Effects and C4D quite extenisively and am looking for better render times and overall performance. I run several plug-ins that utilize OpenGL and am hoping my upgrades will speed this process up.

    Suggestions and input is greatly apprectiated.

    Cheers,
    Dylan

  2. jav6454 macrumors P6

    jav6454

    Joined:
    Nov 14, 2007
    Location:
    1 Geostationary Tower Plaza
    #2
    I'll tell you this much. An HD 5870 is a 3 year old card already. It will serve its purpose to an extent, but I'd recommend you use a GTX 570 and try to get monitors that can connect to it.

  3. thelink macrumors regular

    thelink

    Joined:
    Jun 29, 2012
  4. jav6454 macrumors P6

    jav6454

    Joined:
    Nov 14, 2007
    Location:
    1 Geostationary Tower Plaza
    #4
    Are you suggesting throwing away a perfectly functional Mac Pro (worth a pretty penny) and just dropping $3k?

  5. headkick33 thread starter macrumors newbie

    Joined:
    Jul 9, 2012
    #5
    New computer not happening

    Yeah - um No. My computer is great and not time to upgrade yet. So looking for better video performance. Any useful suggestions for video cards is appreciated . Thanks again.


    Attached Files:

  6. thelink macrumors regular

    thelink

    Joined:
    Jun 29, 2012
    #6
    No. I just suggested for him to get a new computer. You could just keep the old one for a back up.

  7. jav6454 macrumors P6

    jav6454

    Joined:
    Nov 14, 2007
    Location:
    1 Geostationary Tower Plaza
    #7
    Have you tried looking into a HD 6000 series?


    Worthless advice due to the price of a new set up. A cheaper alternative would be a new GFX unit.

  8. thelink macrumors regular

    thelink

    Joined:
    Jun 29, 2012
    #8
    I suggest you get the ATI Radeon HD 5870 Graphics. It looks very nice and should run well with what you've got.

  9. headkick33 thread starter macrumors newbie

    Joined:
    Jul 9, 2012
    #9
    That's what I am thinking. Still should be way faster than the stock 120s I have even if 3 years old. Would go for the 570 if I new that I could use adapters for the mini display connections. Thanks

  10. jav6454 macrumors P6

    jav6454

    Joined:
    Nov 14, 2007
    Location:
    1 Geostationary Tower Plaza
    #10
    I don't think there are any adapters atm. Which is why I also told you to look into the HD 6000 series. It is a generation higher than the 5000 series and are Mac Pro compatible.

  11. headkick33 thread starter macrumors newbie

    Joined:
    Jul 9, 2012
    #11
    Cool - I will look into that option.

  12. paulrbeers macrumors 68040

    Joined:
    Dec 17, 2009
    #12
    6870 sees to be the popular pick for the AMD chips. There are even threads about running a PC 6870 in a Mac Pro (albeit without the initial boot screens) such as below:

    http://forums.macrumors.com/showthread.php?t=1393451

    I myself am going the Nvidia route, but then I am not using mini/displayport based monitors which Nvidia is only starting to embrace.

    ----------

    What advantage would s/he have getting a new computer? The 2009 8 core 2.27ghz Mac Pro still beats the entry level Mac Pro 2012.

    http://browser.primatelabs.com/mac-benchmarks

    If you would like to fund the difference between the OP's GPU upgrade and a new Mac Pro, I'm sure the OP would be more than happy to take your money.

    Now be quiet and let the grownups talk.

  13. GermanyChris macrumors 601

    GermanyChris

    Joined:
    Jul 3, 2011
    Location:
    Here
    #13
    lol

  14. headkick33 thread starter macrumors newbie

    Joined:
    Jul 9, 2012
    #14
    Yeah - thinking Radeon it is. Should be good for a year or 2. Then on to a hopefully new breed of mac. Cheers

  15. lixuelai macrumors 6502a

    Joined:
    Oct 29, 2008
    #15
    HD5870 is faster than HD6870. HD5870 is roughly on par with HD6950 in terms of performance. I don't know how well HD69xx works in OSX since neither are a worthwhile upgrade from a HD5870 (unless you plan on using Crossfire in Windows which I doubt) but a quick look online seems to show that kext support is still immature. IMO a HD5870 is your best bet.

  16. headkick33 thread starter macrumors newbie

    Joined:
    Jul 9, 2012
    #16
    No Windows running on my machine. EVER!!! hehe

    Mainly the reason for upgrade is AE/CD4 and Premiere/Final Cut. Need faster render times.

    Thanks for the input. HD5870 looks like the winner. Amazing how difficult it was to answer this question. Not many options it seems for my particular setup. Apple needs to support way more cards and options. But hey, I still love my Mac. It works pretty much flawlessly.

    HK

  17. jav6454 macrumors P6

    jav6454

    Joined:
    Nov 14, 2007
    Location:
    1 Geostationary Tower Plaza
    #17
    Indeed. Apple definitely needs more GPU support when it comes to the Mac Pro...

  18. BenClement1978 macrumors member

    BenClement1978

    Joined:
    Sep 10, 2011
    Location:
    Antwerp Belgium
    #18
    Upgraded my GT120 for a 5870 Running a 24" panel 1920x1200 and a 21" 1920x1080 panel.

    was contemplating getting a second GT120 but happy i did not and purchase a 5870 (it runs circles around the GT120)

  19. MrCheesecake macrumors newbie

    Joined:
    Jul 9, 2012
    #19
    Why such old cards?

    Are the HD 6000 and 7000 series not compatible? And as for the DVI video out, you could always use a cheap minDP adapter. Audio would be your only downside. Personally, I'd go with a 7000 series or higher. You get the same performace for less than you would from Nvidia.

  20. paulrbeers macrumors 68040

    Joined:
    Dec 17, 2009
    #20
    Ummm what adapter goes from DVI to displayport? Last I knew there were no "cheap" adapters.... Displayport to DVI yes, but not the other way.

    Further, the reason 7000 series isn't being mentioned is because (last I knew) they weren't compatible with Macs yet (at least not out of the box like some of the 5000 and 6000 series)....

  21. Mr Ski 73 macrumors regular

    Joined:
    Dec 11, 2007
    #21
    I am running an ATI 5770 with 2x24" ACD plus 1x23" Cinema Display without adapters and it's a lot cheaper

  22. BenClement1978 macrumors member

    BenClement1978

    Joined:
    Sep 10, 2011
    Location:
    Antwerp Belgium
    #22
    and slower....

  23. Asgorath macrumors 65816

    Joined:
    Mar 30, 2012
    #23
    Except I've seen no reports that the 7000 series cards actually work yet, while the GTX 680 works with both 10.7.5 and 10.8 for example? The GTX 570 is pretty cheap these days and is faster than the 5870 as well.

  24. bax2003, Jul 10, 2012
    Last edited: Jul 10, 2012

    bax2003 macrumors 6502a

    bax2003

    Joined:
    Dec 25, 2011
    Location:
    Belgrade, Serbia
    #24
    For easy install, no flashing, no NOT-WORKING ports, problems with quartz and slow interface in general, get 5870. 5770 will drive you two monitors as well without any problems.

    From experience of user from this forum (and some other) many of them have some kind of problems with GTX570. 5870 is still great card, faster than 6870, little slower than 6950.....it will happily drive 3 (1920x1080/1920x1200) monitors.

  25. theSeb macrumors 604

    theSeb

    Joined:
    Aug 10, 2010
    Location:
    Poole, England
    #25
    There are adaptors, but they are an expensive option. You would have to use something like a Kanex XD to input into a miniDP port on the 24" ACD.

    ----------

    Indeed. Kanex XD will take HDMI to miniDP. You would need two of those and last time I checked they were around $100 each. You would also need DVI or Displayport to HDMI adaptors, if the graphics card did not have 2 HDMI ports, and I haven't seen one that does, but I freely admit that I haven't really been looking.
