Apple's New Dynamic 40W to 60W Charger Has a Key Advantage
- Thread starter MacRumors
- Start date
- Sort by reaction score
At this time, do we in fact know that the maximum charging speed of an iPhone 17 Pro is 40W? Perhaps the vapor chamber cooling technology on the iPhone 17 Pro (and 17 Pro Max) will enable the device to temporarily charge at 60W?
Based on testing by ChargerLab, it appears that an iPhone 17 Pro Max has a peak charging level of about 36W (not 60W). Thus, consistent with the Apple specifications, it appears that any 40W+ charger is sufficient for fast charging - and, the new Apple 40W Dynamic Power Adapter with 60W Max is not required.
The website ChargerLAB today published a teardown of Apple's new 40W Dynamic Power Adapter with 60W Max, which has a key advantage over one of its other chargers.
Specifically, the teardown shows the new 40W to 60W charger is roughly the same size as Apple's 20W charger, despite its higher wattage for faster charging speeds. In other words, you are getting more power from a smaller charger, although the 40W to 60W model costs $39 in the U.S., while the 20W option costs $19.
Apple's 40W-60W charger on left and 20W charger on right (Image: ChargerLAB)
To achieve this, the charger supports USB-C Power Delivery 3.2 with SPR AVS (Standard Power Range Adjustable Voltage Supply), according to ChargerLAB.
The teardown confirms the charger can approach its 60W limit, but this will only be in short bursts, due to the thermal limitations of its compact design.
In addition to the U.S., the 40W Dynamic Power Adapter with 60W Max is available to order in Canada, China, Japan, Mexico, Taiwan, and the Philippines. It appears to be the spiritual successor to Apple's discontinued 30W adapter, which is still included with the base-model 13-inch MacBook Air and the Apple Vision Pro for now.
iPhone 17, iPhone 17 Pro, and iPhone 17 Pro Max models can be charged up to 50% in 20 minutes with a compatible charger, including the 40W to 60W one.
Article Link: Apple's New Dynamic 40W to 60W Charger Has a Key Advantage
What about a MagSafe charger with a fast charging cable ?
Are there any MagSafe chargers with a high speed charging cable attached ?
Is the standard Apple MagSafe charger with vinyl wrapped cable sufficient ?
There doesn't seem to be any other options.
I see that Apple has a " New " MagSafe Charger but it doesn't look any different than the one I have that came with ( Or came out around the time of ) my iPhone 15 Pro.
Should I buy the " New " Apple MagSafe Charger or am I okay with the iPhone 15 Pro era MagSafe Charger ?
Any input would be greatly appreciated.
Thanks
Looks like IKEA also came out with a 45/65 W dynamic charger called SJÖSS recently. It's not widely available yet, but the price is really competitive (12.99 EUR at the store).
It does not support the latest USB PD 3.2 AVS standard though, only 3.0 with PPS. I'm not sure if that is a big disadvantage.
It does not support the latest USB PD 3.2 AVS standard though, only 3.0 with PPS. I'm not sure if that is a big disadvantage.
Last edited:
I really have to ask now: how come nobody else is building a USB-C charger that supports the Power Delivery 3.2 SPR AVS standard? Despite the fact PD 3.2 SPR AVS is an open standard.
It's still a pretty new standard. According to ChargerLab it was only finalized in early 2024. Since AVS is part of the standard now, I would expect other manufacturers to their charging products soon.
It's not even clear, if the new iPhones are already using this new protocol. Recent test have shown that all 17 series iPhones charge fine (and fast) with all generic USB-C chargers.
I believe that the iPhone 17, iPhone 17 Pro and iPhone 17 Pro Max does support Power Delivery 3.0 PPS charging at up to 45 watts. Apple's new charger starts at 40 watts but can have short bursts of charging speed up to 60 watts if it's connected to any iPhone 17 model except the iPhone Air.
I haven't seen any test specifically using the new dynamic charger and a new iPhone 17. Chargerlab has tested the iPhone 17 series with existing chargers from different brands. The iPhone 17 peaked at 28 Watts, while the Pro peaked at 36 Watts.
