I don't understand the iMac resolution

Discussion in 'iMac' started by jonatious, Apr 5, 2019.

  1. jonatious macrumors member

    jonatious

    Joined:
    Sep 29, 2016
    #1
    So this is my first iMac and yes it is 5k. But Apple mentions that It looks best at half the resolution, lets say 2.5k, downscaling it by 2. So I don't get how 4 pixels forced to display the same color of a dot is better than 4 pixel being able to display 4 variants of the same color for the dot? Isn't that the whole point of high res displays?

    The second question is what happens to my media at native 2.5k resolution? My desk background image? The videos I watch and the images/photos I edit? Are they all downscaled by 2?

    I am pretty sure there is a valid reason for this. But I am just not getting it. Any insight is appreciated :)

    For people who don't get it, the iMac ships and runs with 2560x1440 resolution by default and not the 5k resolution of the display

  2. SkiHound2 macrumors regular

    Joined:
    Jul 15, 2018
    #2
    5k is basically 2 x the 2560 x 1440 resolution in both dimensions. But think about how small text would be if displayed at that resolution on a 27" monitor. I'm writing this on a 2560 x 1440 monitor and the fonts and icons are about the right size for me. The 27" iMac monitor displays text and icons at the same size, but with with 4 pixels for every 1 displayed by my monitor. Just looks nicer and sharper. Because it's doubled it scales easily. The 4k 21.5" has pretty much the same screen quality, but 2560 x 1440 would make things too small for most of us on a 27" screen. 4k is essentially a doubling of 1080p in both dimensions (4 x the pixels). Scaling at resolutions that aren't native to the monitor (e.g, 4 k on a 5k monitor) can really tax the gpu and often doesn't look very good.

  3. Zandros macrumors member

    Joined:
    Sep 1, 2010
    #3
    No, the 27" iMac ships with a Hi-DPI mode setting that makes things look the same size as a traditional 2560x1440 monitor. Applications that are not aware of this will indeed be rendered by using four pixels of the same colour on the display for each pixel the app thinks it's using which looks kind of bad (but makes the app an usable size at least), but nowadays almost everything is aware and will use the full resolution available to them.

    How videos and photos are rendered by default is up to the app (I think Preview will pixel-double everything when you tell it to zoom to native resolution, which is kind of weird), but be assured you are viewing all the data available.

    With some trickery you can set the display to a 5160x2880 non-Hi-DPI mode, but everything will look really small.

  4. scottrichardson macrumors 6502

    Joined:
    Jul 10, 2007
    Location:
    Ulladulla, NSW Australia
    #4
    The whole hi-DPI thing can be confusing at first.

    Allow me to help.

    Think of there being two actual resolutions at play now. One is the pixel resolution, and one is the logical or perceived resolution measures in “points”.

    So your iMac has a pixel resolution of 5120 x 2880 pixels.

    And a logical point resolution is 2560 x 1440.

    It renders elements on screen the same physical size as a non retina 2560 x 1440 monitor but with four times the density of pixels.

    So the user interface elements and text will be twice as sharp, as there’s now four pixels available in the space where there would normally be one pixel.

    Images or photos viewed at 100% will now occupy a quarter of the desktop space they used to.

    So interface designers like myself now need to create artwork assets and images that are double the pixel count in both dimensions to ensure they take up the right amount of space when viewed at 100% on retina displays. So an icon that I want to “look like” a 100 x 100 pixel icon needs to be created at 200 x 200 pixels in photoshop. That 200 x 200 icon will take up the “space” of a 100 x 100 point icon.

  5. macduke macrumors G4

    macduke

    Joined:
    Jun 27, 2007
    Location:
    Central U.S.
    #5
    All that is happening is that it makes everything look sharper at the same UI scale. Just like the iPhone and iPad. It’s basically a retina display.

    Otherwise if you run at 1:1 5K scale your windows and text will be very small for only a 27” display.

  6. TheyCallMeBT macrumors regular

    TheyCallMeBT

    Joined:
    Jan 9, 2013
    #6
    I'll be going from a non retina 27" iMac to the 2019 27". When using Photoshop and setting up a canvas-- how does it appear? Like say I want to make an icon for a website at 250 x 250 px, 72 dpi. Is it going to appear like the 2560 x 1440 "logical" resolution, or is it going to be the actual pixel count at 5K?

  7. Fried Chicken macrumors 6502

    Fried Chicken

    Joined:
    Jun 11, 2011
    #7
    Read anand’s article on the first Retina Macbook Pro.

    He breaks it down.

  8. Crotonmark macrumors regular

    Crotonmark

    Joined:
    Jul 22, 2011
    Location:
    Westchester County, NY
    #8
    So what is the best display setting to see the best images on a 5k retina iMac?

  9. Zdigital2015 macrumors 65816

    Joined:
    Jul 14, 2015
    Location:
    East Coast, United States
    #9
    "Best for Display" or 2560X1440, which will be the most crisp resolution as it is @2x of 5120x2880, meaning divisible by two (2).
    --- Post Merged, Apr 28, 2019 ---
    You have to choose between Points or Pixels, each pixel is two points when running @2x Retina resolution.

  10. Fried Chicken macrumors 6502

    Fried Chicken

    Joined:
    Jun 11, 2011
    #10
    four*

  11. Fishrrman macrumors P6

    Fishrrman

    Joined:
    Feb 20, 2009
    #11
    Zdigital wrote:
    "You have to choose between Points or Pixels, each pixel is two points when running @2x Retina resolution."

    Is not "retina" actually 2x2 ?
    Double the pixels vertically, AND double horizontally?

    Seems to me that "looks like" 2560x1440 would use 4 pixels for each "virtual pixel"...

  12. Zdigital2015 macrumors 65816

    Joined:
    Jul 14, 2015
    Location:
    East Coast, United States
    #12
    Yes, I had a complete brain fart on that one...I was watching TV and answered in haste.

    1 point = 2pixels, so a 1 point x1 point square on a Retina = 2 pixels x 2pixels. You are both correct, my apologies.

    Here is a post that describes things in more detail for those that wish to explore the subject further - https://medium.com/@pnowelldesign/pixel-density-demystified-a4db63ba2922
