Next-Generation MacBook Pros Rumored to Feature 'Very High-Bandwidth' RAM

MacRumors

MacRumors

macrumors bot
Original poster
Apr 12, 2001
68,240
39,044


Apple's next-generation 14-inch and 16-inch MacBook Pro models with M2 Pro and M2 Max chips will be equipped with "very high-bandwidth, high-speed RAM," according to information shared by MacRumors Forums member Amethyst, who accurately revealed details about the Mac Studio and Studio Display before those products were announced.


The current 14-inch and 16-inch MacBook Pro models are equipped with LPDDR5 RAM from Samsung, with the M1 Pro chip providing up to 200 GB/s of memory bandwidth and the M1 Max chip topping out at 400 GB/s. On a speculative basis, it is possible that the next MacBook Pro models could be equipped with Samsung's latest LPDDR5X RAM for up to 33% increased memory bandwidth with up to 20% less power consumption. This would result in up to 300 GB/s memory bandwidth for the M2 Pro and up to 600 GB/s for the M2 Max.

Bloomberg's Mark Gurman expects the next MacBook Pros to have few other changes beyond the M2 Pro and M2 Max chips. At this point, it seems likely that the laptops will be announced in November at the earliest with press releases on the Apple Newsroom site. Apple has launched new Macs in November multiple times in recent years, including the original 16-inch MacBook Pro in 2019 and the first three Macs with the M1 chip in 2020.

The current 14-inch and 16-inch MacBook Pro models with the M1 Pro and M1 Max chips were released in October 2021 and featured a complete redesign with a notch in the display and additional ports like HDMI, MagSafe, and an SD card reader.

Article Link: Next-Generation MacBook Pros Rumored to Feature 'Very High-Bandwidth' RAM

Article Link
https://www.macrumors.com/2022/10/24/macbook-pro-very-high-bandwidth-ram-rumor/
  • Love
  • Like
Reactions: Saipher and DeepIn2U
Is it possible for the current state of Apple Silicon to have a different configuration also, such as more memory channels? Such as instead of dual and quad channel its like 3 and 6 channel? Would increase that bandwidth even more.

Good ol' Intel Nehalem of 2009 was Triple Channel DDR3 back in the day, and there are some 6 channel Xeon and Epyc servers out there. Anything is possible but I wonder if @Amethyst has any ideas about it?

Some notes on memory bandwidth of the Apple Silicon machines (which is already extremely high) vs the new Ryzen / Intel CPUs that were released a few days / weeks ago:

Ran a simple benchmark on a new Ryzen 7950x desktop build (64GB RAM) here in the lab (the build will be returned to the supplier) vs my M1 Max laptop (64GB RAM).

Task: Take about 10000 parquet files (10.6GB total) and append them into 1 dataframe (> 400 million observations) in memory.

Hypothesis: The Ryzen 7950x should be way faster - at first thought - because it has 16 cores (versus 8 M1 Max performance cores) that are also clocked way higher.

Result: They are equally as fast because the Ryzen CPU is bottlenecked by memory bandwidth (very fast cores but just 2 memory channels on the CPU).

The files:

Screen Shot 2022-10-20 at 09.06.20.png



The task is most efficiently done in parallel using all cores available, used both polars (Rust ) and pandas-modin (C++) to do this as fast as possible.

When using all 8 performance cores on my M1 Max, memory bandwidth to CPU is at about 120 GB/s (theoretical max is 200Gb/s).

Screen Shot 2022-10-20 at 09.08.48.png



Yet the Ryzen 7950x can do 81 GB/s memory bandwidth at most as the memory runs at 5200MT/s (* 8 bytes * 2 memory channels)/1024 = 81.25 GB/s (you can stretch this to about 100 GB/s if you heavily overclock). Thus despite the 7950x's 16 faster cores it's as fast as my M1 Max with 10 cores in this task because about 6 Ryzen cores are enough to reach that 81GB/s of bandwidth. The other 10 cores are starved from input and just idling.

This is not new; others have ran similar tasks with similar results. E.g. https://tlkh.dev/benchmarking-the-apple-m1-max who finds that

"... adding more cores on the 5600X does not help (2 cores are enough to maximize memory bandwidth), while 10 cores on the M1 Max is the optimal configuration".

The M1 Ultra has 20 cores and 400GB/s of memory bandwidth and thus runs way faster than the Ryzen 7950X as none of its 20 cores are starved. This is even more so when the Ryzen 7950X is decked out with 128GB of DDR5 RAM instead (4 DIMM slots) and therefore runs at a slower 3600 MT/s instead which is a meager 56.25 GB/s memory bandwidth. 5 Ryzen cores can fully consume that; the other 11 cores will just idle.

This is also iterated at http://hrtapps.com/blogs/20220427/ which similarly highlights the importance of memory bandwidth (in computational fluid dynamics in this case) and finds that:

"M1 Ultra has an extremely high 800 GB/sec memory bandwidth.... which leads to a level of CPU performance scaling that I don’t even see on supercomputers, and is the result of a SoC (system on a chip) design"

The new Intel Raptor Lake CPUs also only have 2 memory channels and top out at about 120GB/s max memory bandwidth (heavily overclockded) as well so there won't be a difference here.

So just a heads up: the new Ryzen/Intel CPUs are good for gaming and workflows which are not so much memory dependent, but if you're doing data analysis or other scientific HPC work of some sort that is CPU-and-memory bound (thus not GPU machine learning) you'll very quickly run into memory bandwidth limits. Then you better stick to Apple's M1 / M2 chips or the AMD / Intel CPUs with more than 2 memory channels and thus more memory bandwidth (which are also way more expensive, e.g. the AMD ThreadRipper Pro 5965WX with 26 cores and 8 memory channels at 200GB/s memory bandwidth max for which you have to pay $2400 just for the chip itself and $1000 for a compatible motherboard).

Last edited:
  • Like
  • Love
  • Haha
Reactions: caribbeanblue, BogiTheTomtom, Infodataset and 70 others
roach1245 said:
Some notes on memory bandwidth of the Apple Silicon machines (which is already extremely high) vs the new Ryzen / Intel CPUs that were released a few days / weeks ago:

Ran a simple benchmark on a new Ryzen 7950x desktop build (64GB RAM) here in the lab (the build will be returned to the supplier) vs my M1 Max laptop (64GB RAM).

Task: Take about 1000 parquet files (10.6GB total) and append them into 1 file (> 400 million observations).

Hypothesis: The Ryzen 7950x should be way faster - at first thought - because it has 16 cores (versus 8 M1 Max performance cores) that are also clocked way higher.

Result: They are equally as fast because the Ryzen CPU is bottlenecked by memory bandwidth (very fast cores but just 2 memory channels on the CPU).

The files:

Screen Shot 2022-10-20 at 09.06.20.png



The task is most efficiently done in parallel using all cores available, used both polars (Rust ) and pandas-modin (C++) to do this as fast as possible.

When using all 8 performance cores on my M1 Max, memory bandwidth to CPU is at about 120 GB/s (theoretical max is 200Gb/s).

Screen Shot 2022-10-20 at 09.08.48.png



Yet the Ryzen 7950x can do 81 GB/s memory bandwidth at most as the memory runs at 5200MT/s (* 8 bytes * 2 memory channels)/1024 = 81.25 GB/s (you can stretch this to about 100 GB/s if you heavily overclock). Thus despite the 7950x's 16 faster cores it's as fast as my M1 Max with 10 cores in this task because about 6 Ryzen cores are enough to reach that 81GB/s of bandwidth. The other 10 cores are starved from input and just idling.

This is not new; others have ran similar tasks with similar results. E.g. https://tlkh.dev/benchmarking-the-apple-m1-max who finds that

"... adding more cores on the 5600X does not help (2 cores are enough to maximize memory bandwidth), while 10 cores on the M1 Max is the optimal configuration".

Or what was referred to earlier: http://hrtapps.com/blogs/20220427/.

The M1 Ultra has 20 cores and 400GB/s of memory bandwidth and thus runs way faster than the Ryzen 7950X as none of its 20 cores are starved. This is even more so when the Ryzen 7950X is decked out with 128GB of DDR5 RAM instead (4 DIMM slots) and therefore runs at a slower 3600 MT/s instead which is a meager 56.25 GB/s memory bandwidth. 5 Ryzen cores can fully consume that; the other 11 cores will just idle.

The new Intel Raptor Lake CPUs also only have 2 memory channels and top out at about 100GB/s max memory bandwidth as well so there won't be a difference here.

So just a heads up: the new Ryzen/Intel CPUs are good for gaming and workflows which are not so much memory dependent, but if you're doing data analysis or other scientific HPC work of some sort that is CPU-and-memory bound (thus not GPU machine learning) you'll very quickly run into memory bandwidth limits. Then you better stick to Apple's M1 / M2 chips or the AMD / Intel CPUs with more than 2 memory channels and thus more memory bandwidth (which are also way more expensive, e.g. the AMD ThreadRipper Pro 5965WX with 26 cores and 8 memory channels at 200GB/s memory bandwidth max for which you have to pay $2400 just for the chip itself and $1000 for a compatible motherboard).
Click to expand...
You do realize this forum is for fanboys and not tech nerds, right? I'll read this on Anand Tech and Tom's Hardware, my friend ;)

Oh, and much appreciated. Nice post :)

Last edited:
  • Like
  • Haha
  • Love
Reactions: a104375, AFPBoy, Lwii2boo and 14 others
roach1245 said:
Some notes on memory bandwidth of the Apple Silicon machines (which is already extremely high) vs the new Ryzen / Intel CPUs that were released a few days / weeks ago:

[snip]
Click to expand...
Are you Known-Dentist on reddit? I saw your post on /r/Apple last week. This mostly goes over my head because I know nothing about Parquet, but I assume this isn't just appending the files together (which would be mostly IO bound), but actually shuffling the data around in memory in order to combine it, right?

More cores on the M2 so more bandwidth is obviously helpful. And if M2 Pro/Max is based on A15 cores, boosting the memory is important given the minor changes to the cores.

Adreitz said:
Are you Known-Dentist on reddit? I saw your post on /r/Apple last week. This mostly goes over my head because I know nothing about Parquet, but I assume this isn't just appending the files together (which would be mostly IO bound), but actually shuffling the data around in memory in order to combine it, right?
Click to expand...
Yes indeed. It's shuffling data around in memory indeed (loading them into memory and appending them to a larger DataFrame in memory - the larger the DataFrame becomes - up to 100 millions of rows - the longer it takes).

  • Like
Reactions: BigMcGuire, G5isAlive and Two Appleseeds
MacRumors said:
The current 14-inch and 16-inch MacBook Pro models are equipped with LPDDR5 RAM from Samsung, with the M1 Pro chip providing up to 200 GB/s of memory bandwidth and the M1 Max chip topping out at 400 GB/s. On a speculative basis, it is possible that the next MacBook Pro models could be equipped with Samsung's latest LPDDR5X RAM for up to 33% increased memory bandwidth with up to 20% less power consumption. This would result in up to 300 GB/s memory bandwidth for the M2 Pro and up to 600 GB/s for the M2 Max.
Click to expand...

A 33% increase from 200GB/s is 266GB/s not 300GB/s

There is also the slower and not as new 7.5Gbps LPDDR5X that could make these chips 233GB/s which feels a bit more likely as the 8.5Gbps chips were just announced last week, but it'd be cool if they got those.

  • Like
Reactions: Lwii2boo, Max_G, Ener Ji and 2 others
MacRumors must have been reading my posts, since I have been going on about LPDDR5X in the ASi Mac Pro for the last year...!

reallynotnick said:
A 33% increase from 200GB/s is 266GB/s not 300GB/s
Click to expand...

LOL, math is hard sometimes, but why no just bust out the calculator MR...? ;^p

reallynotnick said:
There is also the slower and not as new 7.5Gbps LPDDR5X that could make these chips 233GB/s which feels a bit more likely as the 8.5Gbps chips were just announced last week, but it'd be cool if they got those.
Click to expand...

Maybe the 7.5Gbps stuff is for the MBP laptops & Mac Studio headless desktops, with the 8.5Gbps stuff is reserved for the Mac Pro headless desktop...?

ThisBougieLife said:
A part of me thinks the Mac Mini will remain an "entry-level" product with no "Pro" options. I hope not, but I wouldn't be surprised.
Click to expand...
You’re probably right.

It’s already $900 for the 8 core CPU/GPU mini. Select 16GB of RAM, and 512 GB of storage and you’re at $1100. If they added an M1 Max you’re looking at maybe a $700 price bump, which is very near to the cost of the base Studio minus additional benefits.

So the $1999 Studio is kind of like the Mac Mini Pro.

  • Like
  • Haha
Reactions: JWSpaceMan, JMStearnsX2, krakenrelease and 5 others
