Whoa. Seriously? $3k? I just.. wow. Doing some fast and unreliable math:
Graphics:
AMD FirePro 9000 6GB VRAM ~$1500/per, ~$3000
Processor(s) - Single 12-Core Intel Xeon E5 v2* (les powerful processors may be available):
- Xeon E5-2680 v2 – $1,944
- Xeon E5-2667 v2 – $2,321
- Xeon E5-2687W v2 – $2,414
- Xeon E5-2690 v2 – $2,356
- Xeon E5-2695 v2 - $2675**
- Xeon E5-2697 v2 – $2,950
Memory***:
E5's may support quad-channel DDR3-1866, 2133, 2400, 3200
64GB Configuration (16GBx4):
Crucial $179 per DIMM, $716 64GB
Hynix $140 per DIMM (used) $560 64GB
PCIe Flash based 1250MB/s Storage:
OCZ PCIe 480GB ~$1500
High End BTO:
- $3000 Graphics
- $2950 Xeon E5-2697 v2 Processor
- $716 64GB DDR3 1866MHz RAM
- $1500 PCIe 480 SSD
Total: $8166
Entry Level BTO:
- $3000 Graphics
- $1944 Xeon E5-2680 v2
- $140 [used] 16GB DDR3-1866
- $700 PCIe 128GB SSD
Total $5784
Where to begin...
First of all the FirePro W9000s are $3,000+ each, not combined, but they will surely not be the only graphics choice as many power users do not need graphics performance. Secondly "FirePro" is branding for better support, better - optimized - drivers and ECC video RAM. They have such a high price as add in cards in the PC world because it is a small market using them for efficiency in business and research i.e. those prices are not extreme to the audience they are intended for. Hardware performance wise the W9000 is similar to a Radeon 7970 as they share the same GPU.
Apple are placing a custom order for several hundred thousand graphics processors and I doubt they will be paying more than $800 to AMD per system with dual W9000s and I would expect a base model to have dual W5000s as many users of these systems don't need graphics performance which would likely cost Apple no more than $300 per system.
CPU wise the logical choices would be:
Xeon E5-1620 V2: 3.7GHz, 4-cores and ~$300
Xeon E5-1650 V2: 3.4GHz, 6-cores and ~$550
Xeon E5-2697 V2: 2.7GHz, 12-cores - I was able to find a pre-order for $2,299 by searching with the box code bx80635e52697v2, but we will have to wait to see what Intel are pricing this at. $2,500 upgrade from Apple could well be on the cards - maybe even $3,000.
None of the 8-core E5-2600 V2 Xeons make any sense on their own because of their prices, maybe a 10-core but again not great value.
The 128GB SSD isn't an off the shelf part for a tiny niche market. It is a design going in to hundreds of thousands of units; it won't add a huge amount to Apple's costs compared to if they were using an off the shelf 2.5" SSD. RAM is probably $4-$5 per GB for Apple and a 4-core system would likely start with 8GB.
So Xeon and FirePro do not mean high starting costs. Apple could have a box for $1,999 if they wanted to really be aggressive. Sure prices on the high end will be steep, but how steep will depend on how Apple price their graphics choices like the PC workstation market or more akin to the consumer cards they are as powerful as.
