Don't get me wrong here, but most, if not all, normally buy a case. So, why does it matter if the reception does decline, when you are getting a case. The case will prevent your skin from bridging the gap, right? When I heard about this, I tried my phone. It won't drop bars. So, I am relieved, but I did not like the lack of a case. So, I bought the Belkin grip vue case. I don't have to worry about my phone get scratched.

Don't get me wrong here, but most, if not all, normally buy a case. So, why does it matter if the reception does decline, when you are getting a case. The case will prevent your skin from bridging the gap, right? When I heard about this, I tried my phone. It won't drop bars. So, I am relieved, but I did not like the lack of a case. So, I bought the Belkin grip vue case. I don't have to worry about my phone get scratched.

It has been stated by many that the bumper does not solve this issue as well.

It has been stated by many that the bumper does not solve this issue as well.

Well, I am not using the bumper. I got a separate case. I am not sure, if the bumper would keep moisture in. It may not be the best case.

I snipped some out of the quote to save page space.

Problem with all of the above statements. After i boxed one of my iphone 4's to send back for full refund to at&t, they put my 3gs back on that number ,which is running ios4, and guess what?
i can put that 3gs running ios4 between my legs and squeeze to all hel, meaning it is covered enitrely by skin and speed test only drops to 650k ,
in free air or held in hand speed test averages 800

if i even hold the iphone 4 lightly in the palm of my hand(my second phone) speed test stops dead.

so if it is all software, why doesnt my 3gs running ios4 do it? You just stated it would!

as i said before, i didnt mean to make it sound like everyone will have the problem. sorry for the confusion. looks like half the people will have the problem. just depends on what band you are using.

iOrlando, have you seen the front page? Have you seen the story that shows the 3G running 2.0 display one bar when palmed? Did you see the story where several other cell phones display the same behavior? Your little 3GS test - it's the same thing. It's fairly common to all cell phones depending on location-specific cell signal.

The issue with skin contacting the the iPhone 4 near the seam is an entirely different phenomenon.

Now, try to touch the 3GS anywhere with a single fingertip and reproduce the issue. Won't happen.

If you can understand that, then you will realize this is not a software issue.

are you being serious or trying to be funny?

the antenna location was changed for the IPhone 4. yes. and yes you can now block the antenna with one finger. is there something else that needs further explaining? this doenst impact my reasoning that it is software related one bit. the antenna was moved and can be covered by one finger. wonderful.

the problem is the software is not telling the antenna to power up as interference is applied (thumb, finger, etc). doesnt matter that the antenna is located differently from 3GS or if a finger can pinpoint the exact location.


Sorry, but that says (and I quote):

"In order to salvage the situation and maintain the popularity of iPhone 4, Apple has announced that it will launch a new version of the iOS, which will be iOS 4.01. It is a move to tackle the problem of the antenna reception."

Is there some official notice on Apple.com about this so-called official announcement? If not, this is just like every other news article:

Pure speculation at this point.

No official word from Apple has yet been released, no press release, no statements, no videos, no emails, nothing from Apple itself.

It would do you and many others well to understand this and the non-official nature of the non-official article making non-official claims. When and if something appears on Apple.com about this so-called fix then it's believable.

Until then it's speculation and best left alone.

its a software problem............

I could be wrong but I don't see how a software change could fix this problem. Apparently, your hand is shorting out the antenna. I am left-handed and find this a major problem. When I hold the iPhone in my left hand the way I normally do, I drop down to zero bars and no service.

its a software problem............

I could be wrong but I don't see how a software change could fix this problem. Apparently, your hand is shorting out the antenna. I am left-handed and find this a major problem. When I hold the iPhone in my left hand the way I normally do, I drop down to zero bars and no service.

From my experiments with my microcell it seems that given even a little attenuation the phone tries to switch from the strongest signal to the most reliable signal, even if it is much weaker. That seems to be a software change.


From my experiments with my microcell it seems that given even a little attenuation the phone tries to switch from the strongest signal to the most reliable signal, even if it is much weaker. That seems to be a software change.

What does that mean? How can you tell which signal its using? What attenuation?

Basically describe the test you did and how you came up with this statement. You haven't provided anything to backup the statement.

What does that mean? How can you tell which signal its using? What attenuation?

Basically describe the test you did and how you came up with this statement. You haven't provided anything to backup the statement.

Well, first of all, it's not incumbent on me to "backup the statement." I was telling you my theory.

if you must know, I have a microcell. I have two 3GS's and a 3G that I've used with the microcell. None exhibit any weird behavior.

I received two iphone 4's on wednesday. Both switched from 5 bars microcell to 0 bars and no microcell within 20 seconds of touching the lower left-hand corner. This happens even 3 feet from the microcell. I had one iphone 4 replaced (it had other problems - no sound from earpiece). It exhibits the same problem with the microcell. You can tell whether you are using the microcell or not because the phone switches its status from "AT&T M-Cell" to "AT&T."

At my house, with the microcell off, I get 1 bar, typically, with the 3gs's. With the 4's I get 2 bars. If I touch the bottom corner of the 4's it drops to 1 bar, but keeps the connection.

With the microcell on, when I lose bars, it also drop calls.

It has been published that the prioritization method changed in OS 4.0 so that it favors reliable cells over strong cells. (Don't bother asking me to supply a link. Google is your friend).

I don't know what metric it uses to determine reliability (perhaps it keeps track. perhaps it has a database. perhaps the cell tells it - in some of those scenarios it's easy to imagine that it doesn't realize that microcells are reliable because someone forgot to tell the software that's the case), but if I choose to believe this change in prioritization, the behavior I see is consistent with the phone not realizing that microcells are reliable. If it sees a nice consistent connection on the microcell it has no reason to switch away. Touching the antenna causes a slight signal attenuation. This is consistent with behavior I see in other locations, such as at my office or on university avenue in palo alto, where touching the corner causes about 1 bar drop and about a 10-15% data speed reduction.

The attenuation is interpreted by iOS 4.0 as meaning "this may be a strong signal, but it smells unreliable to me. I'll keep dropping bars and comparing to other cells until I find a signal whose weighted strength + reliability is higher than the signal I have now.

The problem is that the weighting of the formula is all screwed up.

Anyway, that's my theory. And while I have a Ph.D. in electrical engineering, I have no expertise in antenna design or RF communications, so it's just a theory based on my experimentation with three iphone 4's, 2 iphone 3gs's, and one iphone 3g.

There are two issues at work here that a lot of people are getting confused.

1) any cellphone will experience a degradation of signal when you wrap your hands around it, this is why 3G and 3GS users can seemingly replicate the problem

2) what's going on with the iPhone 4 is not just simple signal degradation due to wrapping your hands around the phone, it's introducing interference into the cellular antenna from the other antenna when your hand or finger bridge the gap between the two. This is a design issue and causes a much more severe signal degradation than what's caused on a normal cellphone by wrapping your hands around it

What people are experiencing on the iPhone 4 and previous iPhone models may look the same, but they're two totally different issues one much more severe and easily caused than the other. The iPhone 4 issue is not a software issue no matter what apple says. They may release an update that masks the issue by simply increasing the amount of bars the phone displays for a given db level but it's not going go be a real "fix".

Also, want to know why some people have the problem and others claim not to? It's because the distribution of db levels amongst the signal strength bars is not even. For example, let's suppose you rate signal strength on a scale of 1-100. 5 bars represents a signal strength of 60-100, 4 bars is 40-60, 3 bars is 30-40, 2 is 20-30, 1 is 10-20 and anything below 10 is no signal. Now suppose shorting the antenna drops the signal strength by 40 points. If you're in an area where your strength is 100 to begin with you're going to see no change in bars even though you're hurting your signal, whereas if you're in an area where your signal is a 49 to begin with you're going to see it drop from 4 bars to no service. Every iPhone 4 has this design flaw, some people just don't realize what they're doing to their signal by holding the phone with their left hand because of how good their signal is to begin with.

I've got other cell phones that I can put inside metal boxes that don't exhibit the kind of degradation my iPhone 4 does when it's in my hand, and if I do bridge that gap between the antenna bands, forget it, "It's dead, Jim."

While a lot of people are "new" to this and more by the minute, there are a lot of us that have been on this issue since Wednesday so... as the post linked in my sig demonstrates, I'm line-of-sight with a cell tower only a few hundred feet away with zero obstructions and I can KILL the service with a fingertip and lessen it fairly drastically (5 bars to 2) with the normal left hand hold I use when I'm operating the iPhone 4 with my right index finger.

So while more and more people are discovering this issue, a great many of us are in situations where we can test it and reproduce it 100% of the time even in spite of being in an area that is about as strong as you can get in terms of signal strength without actually tapping into the antenna array with a piece of coax.

Defective by design...

Anyone seen this yet?

They better hope it doesn't magically get fixed.


Attachments

  • imgad.gif
    35.5 KB · Views: 408
If bumpers don't help then how is it a conductive issue?

Because there's two issues:

a) signal degradation (the "normal type") because of proximity to the antenna - no actual contact being made with skin-on-metal, but the very presence of your skin/hand is enough to attenuate (read: block) some of the signal not only being received by the phone but also the signal being transmitted. This happens more so with cell phones because they operate in microwave frequency ranges and microwaves have a natural tendency to be "caught" by living tissue more readily than other types of material like rubber, etc. That stuff passes it without issues, but human skin/bone/muscle, it wicks the energy away and absorbs it so you "lose" some of the signal coming in and going out.

b) signal degradation (the "skin-on-metal type") is worse because it's a direct contact issue. Microwave energy firing off the resonator (aka the antenna) into the air is one thing, but direct physical contact with that antenna is an electrical connection, just as readily as sticking your finger in a light socket is - only it's millions of times less effective since the energy being sent along the antenna into the skin is millions of times smaller.

Regardless, there are two big issues at hand (no pun intended):

- the iPhone 4 seems to be attenuating the signal more so than other phones because of the direct contact with the metal antenna band (the right side antenna is actually the cellular antenna, it's about 50% larger/longer) - this is what the so-called "fix" may address by altering the power levels based on the frequency bands your cellular provider may be using in your area, and...

- the direct skin contact on that seam on the lower left side becomes an electrical bridge between the cellular antenna and the Wi-Fi/Bluetooth antenna and could be a potential short which is killing the cellular circuit on a great many iPhones

I personally have both issues, and I can cause my phone to "die" for 3G use with a fingertip on that seam, that's all it takes is a fingertip and I lose service completely in less than a minute, and I live right next to an AT&T cell site only a few hundred feet away.

It's a real issue, happening to real people, and more all the time. Just because not every single iPhone owner is reporting it or noticing it with their particular iPhones doesn't mean it's not happening to a great many of us.

The bumper prevents the skin-on-metal contact, but it also creates a "bumper" zone of about 1/8" or so that helps lessen the effect of the attenuation. My belief is that this whole situation is well known by Apple (much to other people telling me I'm insane) and that bumper was created specifically to prevent the skin-on-metal contact period, which it does. But people using the bumper are still having 3G problems as many videos and reports have stated, hence the bumper isn't a "fix" but a temporary workaround for a much more serious issue that needs to really be fixed.

That's about it.

the antenna location was changed for the IPhone 4. yes. and yes you can now block the antenna with one finger. is there something else that needs further explaining?

The antenna can not be blocked by a single finger.

First of all, two-thirds of the external casing is part of the UTMS/GSM antenna - it's too large to cover the antenna with a fingertip.

Secondly, antennas radiate in all directions. So, even if the finger absorbs all the radiation directed towards it, it will still radiate in every other direction.

Why don't you try replicating the signal loss by simply hovering your finger over the seam without actually touching it. Nothing will happen, but your finger will be covering just as much of the signal as when it rests on the casing.

By the way, have you tried to replicate the signal loss on the 3GS with a single finger touch? It won't happen.

From my experiments with my microcell it seems that given even a little attenuation the phone tries to switch from the strongest signal to the most reliable signal, even if it is much weaker. That seems to be a software change.

If attenuation is the issue, why doesn't it behave the same when smothered in the palms of one's hands, in large buildings, or in other places that block cell signals?

Reception issue

Just got back from exchanging my iPhone at local Apple store because of a cluster of dead pixels in middle of screen, and replacement has same reception problem.
Guy at Apple store would not give me a free bumper coz they had not heard anything from above about it yet, :rolleyes:

if I hold mine long enough (few minutes+), it jumps back to 4 bars. I did drop to 1 bar 10-15 sec after i hold the bottom left corner at first.

The problem it seems it was rushed out the door. Reading about Mr Job's personality, he is probably surrounded by yes people and worshipers.Not good when no one will say you are wrong. I was excited about getting the new one. I will wait with os4 on my iphone 3gs its like having a new phone. Also I love my iphone, its an amazing internet device but its a crappy phone. My nokia before it never dropped a call and it was on the same att network . Now that I own the iphone, the ipad and the macbook . Ive come to the realization,the problem with apple is they create amazing designs then make it just good enough but not the best. Like a $1000 laptop with only 2 gig of ram, everything has just enough features but its still alittle behind the curve so they can sell you another one real soon.

So has Apple won this battle? Are they just too powerful company to sweep this issue under the carpet?

So Steve´s little Jedi mind trick did work after all?
