Hi all, I
upgraded/updated my Late 2013 15" MBP from Big Sur 11.7.11 to Ventura 13.7.8 via OCLP version 2.4.1 last night (which turned into a very late night). Specs:
- 2.3 GHz Core i7
- 16 GB
- 512 GB SSD (350 GB MacOS partition & 150 GB Bootcamp partition)
- nVidia GT 750M
The post-install process was frustrating with EFI/USB-Free boot and boot picker screen issues so I'm explaining things here in case it helps anyone and I still have a couple of lingering issues I need to fix (if anyone can help that'd be great).
Pre-Install: I went through the documentation on Github and watched a few videos to understand the process (I never seem to have luck when tinkering with computers so wanted to make sure I knew what I was doing).
Installation: The install process went alright. Unexpectedly when the MBP restarted a few times during install it showed a boot picker screen like in
this video (watch closely as the video is sped up). I didn't touch it at all when this occurred and the installation eventually finished on its own. I didn't encounter the issue where the loading bar stops at 40% due to driver problems with the GT 750M (I read online before installation that people had this issue).
Post-install problems:
1. EFI/USB-Free boot issues: When the OCLP prompt appeared asking if I'd like to not boot via USB (why would anyone not want that as default?) I clicked Yes/OK and installed OCLP to my internal SSD and disk0s1 EFI. The problem is this didn't work. During reboot I held the Option key and no "EFI Boot" (with SSD symbol) appeared, only the "EFI Boot" (with external disk symbol) appeared. At that point I still had my USB plugged in, the videos I watched didn't say when to unmount the USB and the documentation
here doesn't advise to unmount USB before restarting.
I troubleshot the problem and
read that supposedly the EFI Boot install can stuff up, so I created a new 200 MB MS-DOS (FAT16) partition (for some reason there was no FAT32 option) on my MacOS partition and built-and-installed OCLP again via the prompt, this time selecting the 200 MB FAT16 partition instead of the disk0s1 EFI. This allowed me to boot without the USB drive. A problem that occurred here is a 16.8 MB "Microsoft Reserved" partition disappeared when I created the FAT16 partition, I didn't delete it.
TL;DR Couldn't boot without USB, needed to create 200 MB FAT16 partition to install OCLP EFI onto.
2. Boot picker screen issues: I restarted a few times to ensure I didn't need the USB to boot but realised the boot picker screen appeared every restart which was annoying. Advice online said to uncheck the "Show OpenCore Boot Picker" setting in OCLP and then "Build and Install OpenCore" which I did (again, onto internal SSD and FAT16 partition), but for some reason the MBP booted into Windows by default instead of MacOS. Even when I restarted and held Option and selected "EFI Boot" (the icon with the SSD symbol) it weirdly booted into Windows (WTF!).
I could not boot into MacOS at all, no option worked (MacOS SSD would show the 🚫 symbol). So I shutdown, booted into Ventura using the USB EFI
again then went to sleep because it was really late, regretting that I cared that much about bypassing the boot picker screen.
Today I got back to it and deleted the 200 MB FAT16 partition and re-created it, then built-and-installed OCLP -- again to the internal SSD and FAT16 partition to try and fix the issue. I tried this a few times to no avail. Then I realised maybe the issue was that I didn't
re-tick the "Show OpenCore Boot Picker" option when building, so after creating a fresh 200 MB FAT16 partition I ticked that option, built-and-installed OCLP to it and I was finally able to boot without USB again (but the boot picker screen came back, as expected).
TL;DR After unchecking "Show OpenCoreBoot Picker" in OCLP settings then build-and-installing to SSD and FAT16 partition, MBP boots into Bootcamp by default. Even holding Option and selecting EFI Boot (with SSD symbol) it boots into Windows. Needed USB to boot and rechecked "Show OpenCore Boot Picker" then built-and-installed to SSD and fresh FAT16 partition again. Can boot into Ventura but boot picker screen still appears.
Lingering issues:
1. The first "diskutil list" I ran after upgrading showed a 16.8 MB "Microsoft Reserved" disk0s3 on my disk0 (internal, physical). When I created the first 200 MB FAT16 partition this disappeared, I absolutely did not willingly delete it. I need to figure out how critical this was. I can still boot into Windows when I select it during startup.
2. I still dislike the boot picker screen appearing so want to fix it but I'm scared I'll have to go through the "Boot picker screen issues" process again if something messes up. I don't know why the EFI Boot (with SSD symbol) option booted into Windows instead of MacOS, that was really strange.
